Instructions for Using
DOMINATOR
G3151 Fusion Range
G3150 Fusion Boiling Top
INSTALLATION and
SERVICING INSTRUCTIONS
This appliance must be installed and serviced by a competent person as stipulated by the
Gas Safety (Installation & Use) Regulations.
IMPORTANT
The installer must ensure that the installation of the appliance is in conformity with these instructions
and National Regulations in force at the time of installation. Particular attention MUST be paid to:
Gas Safety (Installation & Use) Regulations
Health And Safety At Work etc. Act
Local and National Building Regulations
Fire Precautions Act
The appliance has been CE-marked on the basis of compliance with the Gas Appliance Directive for
the Countries, Gas Types and Pressures as stated on the data plate.
WARNING
TO PREVENT SHOCKS, ALL APPLIANCES WHETHER GAS OR ELECTRIC,
:
MUST BE EARTHED.
On completion of the installation, these instructions should be left with the Engineer-in-Charge for
reference during servicing. Further to this, The Users Instructions should be handed over to the User,
having had a demonstration of the operation and cleaning of the appliance.
IT IS MOST IMPORTANT THAT THESE INSTRUCTIONS BE CONSULTED BEFORE INSTALLING
AND COMMISSIONING THIS APPLIANCE. FAILURE TO COMPLY WITH THE SPECIFIED
PROCEDURES MAY RESULT IN DAMAGE OR THE NEED FOR A SERVICE CALL.
PREVENTATIVE MAINTENANCE CONTRACT
In order to obtain maximum performance from this unit we would recommend that a maintenance
contract be arranged with SERVICELINE. Visits may then be made at agreed intervals to carry out
adjustments and repairs. A quotation will be given upon request to the contact numbers below.
WEEE Directive Registration No. WEE/DC0059TT/PRO
At end of unit life, dispose of appliance and any replacement
parts in a safe manner, via a licenced waste handler.
Units are designed to be dismantled easily and recycling of all
material is encouraged whenever practicable.
Falcon Foodservice Equipment
HEAD OFFICE AND WORKS
Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland.
SERVICELINE CONTACT
Phone: 01438 363 000
PLUS
Fax: 01438 369 900
Detailed recommendations are contained in
Institute of Gas Engineers published documents:
IGE/UP1, IGE/UP/2
BS6173 and BS5440
T100850 Ref. 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Falcon Dominator Plus G3151
Summary of Contents for Falcon Dominator Plus G3151
-
Page 1: Installation And Servicing Instructions
Units are designed to be dismantled easily and recycling of all material is encouraged whenever practicable. Falcon Foodservice Equipment T100850 Ref. 2 HEAD OFFICE AND WORKS Wallace View, Hillfoots Road, Stirling. FK9 5PY. Scotland. - Page 2 IMPORTANT INFORMATION Warranty Policy Shortlist Warranty does not cover :- • Correcting faults caused by incorrect installation of a product. • Where an engineer cannot gain access to a site or a product. • Repeat commission visits. • Replacement of any parts where damage has been caused by misuse. •...
-
Page 3: Section 1 - Installation
SECTION 1 - INSTALLATION UNLESS OTHERWISE STATED, PARTS WHICH HAVE BEEN PROTECTED BY THE MANUFACTURER ARE NOT TO BE ADJUSTED BY THE INSTALLER. 1.1 MODEL NUMBERS, NETT WEIGHTS and DIMENSIONS 1.4 GAS SUPPLY Width Depth Height Weight Model The incoming service must be of sufficient size to supply (mm) (mm) (mm) - Page 4 1.8 INJECTOR DIAMETERS Model Natural Propane Open top Ø1.93mm Ø1.2mm Fusion Burner Ø1.0 mm Ø 0.5mm Ovens Ø2.2mm Ø 1.33mm 1.8.1 Fusion Burner pilot Injectors Natural Gas Propane Gas G27.2 G22.1 1.9 GAS PRESSURE ADJUSTMENT NATURAL and PROPANE GAS The following supply pressures apply to both all units. Gas type mbar Natural...
-
Page 5: Section 2 - Assembly And Commissioning
SECTION 2 - ASSEMBLY and COMMISSIONING Fixings 2.1 ASSEMBLY Figure 3 Note The following paragraphs should be read as applicable to the unit being assembled. a) Unpack appliance and place it in position using feet adjusters to level appliance. b) Units with castors should be fitted with accessories supplied according to separate instructions provided. - Page 6 2.2 CONNECTION TO GAS SUPPLY 2.5.3 Lighting Sequence Connect appliance to gas supply and ensure that the Important governor supplied is fitted on NATURAL gas installations. Prior to operation, ensure ALL packing material has been Test for gas tightness. removed from appliance. The integral gas supply downstream of gas valve may be Open Top checked by applying leak detection spray with burner lit.
-
Page 7: Section 3 - Servicing And Conversion
3.1.2 Open Top Low setting SECTION 3 - Screw - To Replace SERVICING AND CONVERSION (Figure 7) Important a) Remove control panel. BEFORE ATTEMPTING ANY SERVICING, ENSURE b) Unscrew and remove existing low position screw ISOLATING COCK IS TURNED OFF AND CANNOT BE from open top tap. - Page 8 3.1.5 Solid Top Burner - To Replace Injector 3.3 REMOVAL OF DROP-DOWN DOOR (Figure 9) Open door completely and insert a suitable pin into a) Remove solid top castings. marked hole on both hinges. b) Release pilot assembly from burner. c) Remove burner.
- Page 9 Solid top low flame adjustment screw Figure 12 Solid top burner test point 3.6.4 Oven Thermocouple 3.5.2 Injectors Injectors are best cleaned with a wooden splinter or soft To Remove Thermocouple fuse wire. Metal reamers may distort or increase orifice Remove facia panel as detailed in Section 3.2.1.
-
Page 10: Section 4 - Spares And Accessories
Fig 12. return faulty thermostat to Falcon Quality Department. Note: If after adjusting the electrode to the correct dimensions (fig 12), a spark is not present, or is 3.9 OPEN TOP and SOLID TOP GAS TAPS...
