COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
Page 2
HT-R960 3 7 6 3 1 5 1 5 0 EXPLODED VIEWS-1 A061 x 6 pcs. A102 P2801 P901 A037 A096 x 7 pcs. A097 A052 MPP type only x 30 pcs. A103 P6601A A019 A060 x 14 pcs.
Page 4
HT-R960 3 7 6 3 1 5 1 5 0 BLOCK DIAGRAMS-1 AUDIO ANALOG AUDIO SECTION FRONT L TUNER UNIT Q5501 FRONT R R2S15211FP SELECTOR / TONE / VOLUME PHONES AUDIO DIGITAL POWER AMPLIFIER RL6600 MIC AMP TONE +29dB...
L322 470/10 Refer to following table about the parts displayed by mark " LIST ". LM182 C305 47/25 P307 R353 C353 C307 104Z MODEL No.---> TX-SR576 HT-R667 HT-R960 TX-SR606 TX-SA606X MODEL No. ---> TX-SR576 HT-R667 HT-R960 TX-SR606 TX-SA606X R319 L309...
HT-R960 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS-4 (SD-4) VIDEO SECTION P3007A NAVD-9467 Refer to following table about the parts displayed by mark " LIST ". LIST +12V MODEL No. ---> TX-SR506 HT-R518 HT-R560 TX-SR576...
HT-R960 3 7 6 3 1 5 1 5 0 SCHEMATIC DIAGRAMS-5 (SD-5) LIST NATRM-9428 SPEAKER TERMINAL / POWER SUPPLY SECTION ZONE 2 SPEAKER NAETC-9435 TERMINAL PC BOARD HEADPHONE JACK <Note> NAPS-9432 PC BOARD 1. NC = No mount of parts.
HT-R960 3 7 63 1515 0 SCHEMATIC DIAGRAMS-10 WAVEFORM SECTION-1/3 Digital Audio Waveform Part <Notes> 1. WF01 is short for Waveform-01 . 2. Refer to SD-3 (SCHEMATIC DIAGRAMS-3) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
HT-R960 3 7 63 1515 0 SCHEMATIC DIAGRAMS-11 WAVEFORM SECTION-2/3 Video Waveform Part Video source color and pattern <Notes> 1. WF21 is short for Waveform-21 . 2. Refer to SD-4 (SCHEMATIC DIAGRAMS-4) for the location of each waveform on circuit.
HT-R960 3 7 63 1515 0 SCHEMATIC DIAGRAMS-12 WAVEFORM SECTION-3/3 FL Driver IC Control Waveform Part <Notes> 1. WF61 is short for Waveform-61 . 2. Refer to SD-6 (SCHEMATIC DIAGRAMS-6) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 PRINTED CIRCUIT BOARD VIEWS-3 THERMAL SENSOR PC BOARD (NAETC-9426) Component side Soldering side C6630 Q6380A Q6380 NCETC-9426 25139426 TRANS. SEC. TERMINAL PC BOARD (NAPS-9425) Component side JL6952A NCPS-9425 25139425 L 13942296513 ZONE 2 SPEAKER TERMINAL PC BOARD (NATRM-9428) Component side JL6604C C6647...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-3 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-3/5 TERMINAL DESCRIPTION External Memory Interface (EMIF) Address and Control Pin Name Pin No. Type Description EM_A[0] EMIF Address Bus EM_A[1] EM_A[2] EM_A[3] EM_A[4]...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-4 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-4/5 TERMINAL DESCRIPTION McASP0, McASP1, McASP2, and SPI1 Serial Ports Pin Name Pin No. Type Description AHCLKR0/AHCLKR1 McASP0 and McASP1 Receive Master Clock ACLKR0 McASP0 Receive Bit Clock AFSR0...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-6 Q281 : M12L64164A-7TG ( 1M x 16 Bit x 4 Banks Synchronous DRAM ) BLOCK DIAGRAM PIN LAYOUT TOP VIEW Clock Generator DQ15 Bank D VDDQ VSSQ Bank C DQ14 Bank B...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-10 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-3/4 TERMINAL DESCRIPTION Name Pin No. Function AD0/CS Address Bit 0 (I2C)/Control Port Chip Select (SPI) (INput) - AD0 is a chip address pin in I2C mode; CS is the chip select signal in SPI mode.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-11 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-4/4 TERMINAL DESCRIPTION Name Pin No. Function CL_SDOUT CODEC Serial Data Output (Output) - Output for two's complement serial audio data the internal and external ADCs.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-14 Q3001 : AN15880A(Video SW for Receiver with Multi-signal)-3/3 TERMINAL DESCRIPTION (2/2) Pin No. Pin name Type Description No connection CYOUT1 signal output CYOUT1 Output Ground GND4 Ground COUT3 signal output COUT3 Output...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-15 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Bass &...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-21 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-3/12 TERMINAL DESCRIPTION <Note> I/O Legend : A = Analog, I = Input, O = Output, P = Power, G = Ground, D = Digital Analog input port Pin Name Pin #...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-22 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-4/12 TERMINAL DESCRIPTION Analog input port Pin Name Pin # Description Negative analog input ‘B’ for channels 1 through 4. This acts as the return Path for the Sources connected to channel-B Input.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-23 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-5/12 TERMINAL DESCRIPTION Low bandwidth ADC input port Pin Name Pin # Description VDDA33_LBADC Analog Powet (3.3V) for Low Bandwidth ADC Block.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-24 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-6/12 TERMINAL DESCRIPTION Digital video Input port Pin Name Pin # Description VID2_0/VID_DATA_IN_16 VID2_1/VID_DATA_IN_17 VID2_2/VID_DATA_IN_18 VID2_3/VID_DATA_IN_19 Video Input 2 in 8-bit with Embedded Sync / Separate Sync format OR R/V data in...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-25 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-7/12 TERMINAL DESCRIPTION System interface Pin Name Pin # Description GPIO11/PWM0 This Pin can be programmed to give out Pulse Width Modulated Output Pulses for eternal use.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-26 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-8/12 TERMINAL DESCRIPTION LVDS Display interface Pin Name Pin # Description PBIAS Panel Bias Control (backlight enable, tri-state output, 5 V tolerant). PPWR Panel Power Control (tri-state output, 5 V tolerant).
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-28 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-10/12 TERMINAL DESCRIPTION Parallel / Serial ROM interface Pin Name Pin # Description 256K x 8 PROM / SRAM Address. Some of these pins also have boot strap functionality. For serial SPI ROM interface : - ROM_ADDR17 is Serial Clock (ROM_SCLK) - ROM_ADDR16 is Serial Data Output (ROM_SDO)
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-29 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-11/12 TERMINAL DESCRIPTION Digital Power and Ground Pin Name Pin # Description RVDD_3.3 Ring VDD. Connect to digital 3.3 V. CVDD_1.8 Core VDD.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-30 Q8001 : FLI30502 (LCD TV Controller with Worldwide Standard Sound Processor and HDMI Receiver)-12/12 TERMINAL DESCRIPTION Audio Port Pin Name Pin # Description I2S_SPDIF_IN_DATA I2S/SPDIF Serial Data Input. I2S_IN_WCLK Left / Right Channel Select Signal.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-31 Q8002, Q8003 : TC74VCX162244FT (Low-Voltage 16-Bit Bus Buffer with 3.6-V Tolerant Inputs and Outputs) PIN LAYOUT IEC LOGIC SYMBOL TOP VIEW L 13942296513 TRUTH TABLE SYSTEM DIAGRAM Inputs Outputs 1A1-1A4...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-33 Q8162 : SiI9185ACTU (Three Input, Single Output Deep Color HDMI Switch)-2/3 TERMINAL DESCRIPTION System switching Pin Name Pin # Description DSDA0, Input / DDC I C Data for respective port. DSDA1, Output DSDA2...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-34 Q8162 : SiI9185ACTU (Three Input, Single Output Deep Color HDMI Switch)-3/3 TERMINAL DESCRIPTION Differential Signal Data Pins Pin Name Pin # Description RX0+ 20, 41, 62 Input TMDS input data pairs.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-37 Q8401 : SiI9134CTU (HDMI Deep Color Transmitter)-3/4 TERMINAL DESCRIPTION Video and Audio Input pins Pin Name Pin # Description D0 - D11 98 - 84 Input These are the lower 12 bits of the 36-bit pixel bus. These pins are highly configurable, and support multiple RGB and YCbCr formats.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-41 Q8501 : SiI9135ACTU ( HDMI Receiver)-3/5 TERMINAL DESCRIPTION Digital Video Output Pins Pin Name Pin # Description Output 36-Bit Output Pixel Data Bus. Q35:0 is highly configurable using the Output VDD_CONFIG register.
HT-R960 3 7 63 1515 0 MICROPROCESSOR TERMINAL DESCRIPTIONS-1 Q701 : MPD70F3746 (Main Microprocessor) Pin No. Pin Name Act. Description AVREF Power supply. (A/D reference) AVSS Ground. FANCTRL Not used. VDLOCK INT signal input from Video signal processor (FLI30502).
HT-R960 3 7 63 1515 0 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol.
HT-R960 3 7 63 1515 0 SERVICE PROCEDURE-2 5. To check version of Main microprocessor, DSP and Video FW 1. Press and hold down DISPLAY button, then press ON/STANDBY button when the unit is power on. The main microprocessor version will be displayed on Front Display for about 3 seconds.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-1 GENERAL To check version of Main Microprocessor, DSP and Video FW 1. Press and hold down DISPLAY DISPLAY button, then press ON/STANDBY ON/STANDBY button when the unit is power on. The main microprocessor version will be displayed on Front Display for about 3 seconds. Ma in 1 .0 3 /0 8 6 3 0 A Version of Main Microprocessor FW *Number depends on the version.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-2 UPDATE OF MAIN MICROPROCESSOR-2/2 Update Procedure 1. Double click "Update.exe Update.exe" in the unzipped folder "Update_SR606Main1.2.zip” (Folder name depends on the version). The following window will appear. Updater COM Port(C) Log Visible Firmware Read Result 001.
2. Writing soft : “CD_SR6060_08213A.wav” (File name depends on the version.) <Note> Store it in a blank CD-R as a music CD in advance. For a writing soft, contact Onkyo or your local distributor. 3. CD player with Optical or Coaxial output terminal.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-5 UPDATE OF VIDEO-2/6 Update Procedure 1. Start GProbe by clinking the icon. 2. Turn on the unit and make sure that some information appears in the bottom right corner of the window. If nothing appears in this area, the PC does not communicate with the unit.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-6 UPDATE OF VIDEO-3/6 Troubleshooting Communication error Check the serial port setting by following 1 and 2 . <Note> Make sure that software applications installed after GProbe do not occupy the specified port. Connection Settings Commands Options...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-8 UPDATE OF VIDEO-5/6 Update Procedure (continue) 5. Make sure that “ Command Successful. Writing FLASH... Command Successful. Writing FLASH...” appears in the bottom right corner of the window. - Er a si ng fl ash .. - Bl a nk che cki n g ..
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 FIRMWARE UPDATE-9 UPDATE OF VIDEO-6/6 To install GProbe 1. Unzip “GProbe 5[1].4.0.3.zip” and click the extracted file “GProbe5.4.0.3.exe.” 2. Follow the instructions on the window as below. <Note> Not all the windows are shown in this procedure. Setup - Genesis GProve 5 Setup - Genesis GProve 5 Select Destination Location...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 OPERATION CHECK-1 SPEAKER PROTECT-1 Circuit configuration The unit go into protect mode when either of thermal detection, dc voltage detection or current detection circuit operates. Power amplifier VPRO : DC voltage detection IPRO : Current detection Q6070 Q6071 Thermal sensor...
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 OPERATION CHECK-3 SPEAKER PROTECT-3 Current detection check [When] 1. Exchange power transistors (Q6050 - Q6056, Q6060 - Q6066). 2. Exchange amplifier PC board ass'y (NAAF-9424). [Procedure] Notes : No input. Do not check two or more channels at the same time. Do not connect a dummy load to speaker terminal longer than 2 seconds.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 OPERATION CHECK-4 POWER SUPPLY CONTROL Configuration The power supply voltage of +/-B1 for power amplifier is changed by the relays (RL6901, 6902). Power amplifier Output sensor RL6901 S1H+ +22V S1H- Thermal sensor Q6380 RL6902 D6901 To Power amp.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 OPERATION CHECK-5 COOLING FAN Note : MWT, MWO, MWF type only Circuit configuration Power amplifier Output sensor Cooling fan Thermal sensor Fan drive Q6380 Q9101, 9102 THERMAL FANCTRL Q701 Main Microprocessor VOLH Q9111, 9112 Condition to operate The cooling fan will stop or rotate at high speed or low speed under the following condition.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-1 DSP DEBUG MODE-1 The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode. This information will help to analysing digital audio no sound trouble. To set in Debug mode 1.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-2 DSP DEBUG MODE-2 Content of Display (Continued) DSP Port DSP Decode This figure is displayed in hexadecimal form. o = Decode OK If this is transformed to binary form, each bit indicates x = Decode NG the following DSP port status.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-3 DSP DEBUG MODE-3 Trouble Shooting by DSP DEBUG MODE (Continued) Symptom on FL display Cause of trouble Remedy Digit No. on FL Continue to display "1" Interface between DSP and MPU is no good. The same remedy as 10 -b.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-4 SERVICE INFORMATION MODE Trouble Shooting by Displaying Service information This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off. Pay attention that the status will change if a button is pushed.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-5 HDMI DEBUG MODE-1/2 HDMI-related operations can be checked to some extent by displaying HDMI debug mode. To enter this mode Hold down DISPLAY DISPLAY button for 3 seconds. Information display will last for about 8 seconds. Content of Display FL Display Segment No.
http://www.xiaoyu163.com TX-SR606 3 7 63 1515 0 DEBUG MODE-6 HDMI DEBUG MODE-2/2 FL segment No. ---> Video Input Format Status Description Video signal route : Source Device HDMI Through Video resolution is not Determined Error State ---> Remedy Video signal route : Via Video Signal Processor Error State --->...
http://www.xiaoyu163.com TX-SR606 3 7 6 3 1 5 1 5 0 DEBUG MODE-7 HDMI TROUBLESHOOT-1/3 HDMI VIDEO SETUP TROUBLE This trouble shooting map focuses on the video setup errors regarding HDMI. For reference, read TX-SR606 Owner’s Manual. Analysis written below is of typical cases. So, more detailed check may need in actual cases. Video trouble Bad picture No picture...
http://www.xiaoyu163.com TX-SR606 3 7 6 3 1 5 1 5 0 DEBUG MODE-8 HDMI TROUBLESHOOT-2/3 HDMI AUDIO SETUP TROUBLE This trouble shooting map focuses on the audio setups and connections regarding HDMI. For reference, read TX-SR606 Owner’s Manual. Analysis written below is of typical cases. So, more detailed check may need in actual cases. Audio trouble No sound Bad sound...
HT-R960 3 7 63 1515 0 ADJUSTMENT PROCEDURE-1 IDLING CURRENT ADJUSTMENT [When] 1. Exchange Power transistor (Q6050 - Q6056, Q6060 - Q6066). 2. Amplifier PC board (NAAF-9419). [Procedure] Refer to "ADJUSTMENT PROCEDURE-2 " for the adjustment points and the test points.
HT-R960 3 7 63 1515 0 ADJUSTMENT PROCEDURE-2 IDLING CURRENT ADJUSTMENT Adjustment point Test point (Trimming resistor) Adjustment points and the test points R6046 Front side P6086 Surround Back Right ch R6045 P6086 P6085 Surround Back Left ch P6085...
3 7 6 3 1 5 1 5 0 1/85 PAGE HT-R960 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
240158 <MPP> EXPLODED U45 or TUNER UNIT FAE485-E11EU 240154 <MPP> EXPLODED HT-R960 PC BOARD PARTS LIST AMPLIFIER PC BOARD (NAAF-9419-1J/ 1K) PCB1 TRANS. SEC. TERMINAL PC BOARD (NAPS-9420-1J/ 1K) PCB1 THERMAL SENSOR PC BOARD (NAETC-9421-1J/ 1K) PCB1 PCB1 PART NAME DESCRIPTION Q'TY PART NO.
