Each LED representation can report one of four states:
–: A dash means the LED is off.
R: The letter "R" means the LED is red.
G: The letter "G" means the LED is green.
Y: The letter "Y" means the LED is yellow.
The section "Netopia R910 Ethernet Router status lights" on page 3-16
for each LED.
Note: Although the Quick VIew LED Status section lists the Channel 2 (CH2) LED, it is not used on the R910.
Statistics & Logs
Main
Menu
When you are troubleshooting your Netopia R910, the Statistics & Logs screens provide insight into the recent
event activities of the router.
From the Main Menu go to Statistics & Logs and select one of the options described in the sections below.

General Statistics

To go to the General Statistics screen, select General Statistics and press Return. The General Statistics
screen appears.
Phys I/F---------Rx Bytes---Tx Bytes---Rx Pkts---Tx Pkts----Rx Err----Tx Err
Ethernet Hub
Ethernet Wan1
Network----------Rx Bytes---Tx Bytes---Rx Pkts---Tx Pkts----Rx Err----Tx Err
IP
The General Statistics screen displays information about data traffic on the Netopia R910's data ports. This
information is useful for monitoring and troubleshooting your LAN. Note that the counters roll over at their
maximum field width, that is, they restart again at 0.
Statistics & Logs
General Statistics
123456789 123456789
123456789 123456789
123456789 123456789
describes the meanings of the colors
• General Statistics
12345678 12345678
12345678 12345678
12345678 12345678
Monitoring Tools 12-111
