12-110 User's Reference Guide

General status

Default IP Gateway:
Domain Name Server:
Domain Name: netopia.com
----------------MAC Address--------IP Address---------------------------------
Ethernet Hub:
Ethernet WAN1:
PWR-+------ENWAN---------+--EN--+--------LEDS---------------------------------
LNK RDY CH1 CH2
G -
Current Date: The current date; this can be set with the Date and Time utility (see
page 8-47).
Default IP Gateway: Actual IP address of the default gateway, if entered. 0.0.0.0 indicates automatic
addressing.
Domain Name Server: IP address of your DNS server.
Domain Name: Domain name you have entered, usually your ISP, such as netopia.com.
CPU Load: Percentage of the system's resources being used by all current transmissions.
Unused Memory: The total remaining system memory available for use.
Ethernet Address: The Netopia R910's hardware address.
IP Address: The Netopia R910's IP address, entered in the IP Setup screen.

Status lights

This section shows the current real-time status of the Netopia R910's status lights (LEDs). It is useful for
remotely monitoring the router's status. The Quick View screen's arrangement of LEDs corresponds to the
physical arrangement of LEDs on the router.
PWR-+------ENWAN----------+--EN--+--------LEDS------------------------------------
LNK RDY CH1 CH2
G - -
0.0.0.0
0.0.0.0
00-00-c5-70-03-48
00-00-c5-70-03-4a
DATA | '-'= Off 'G'= Green
- - - -
DATA | '-'= Off 'G'= Green
- - -
Quick View
CPU Load: 5%
192.168.1.1
0.0.0.0
LED Status
| 'R'= Red 'Y'= Yellow
| 'R'= Red 'Y'= Yellow
12/14/1998 01:13:52 PM
Unused Memory: 1017 KB
"Date and time" on
