CD
SOLDERING
STATION
Reference Guide
www.jbctools.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CD and is the answer not in the manual?

Questions and answers

Related Manuals for jbc CD

Summary of Contents for jbc CD

  • Page 1 SOLDERING STATION Reference Guide www.jbctools.com...

  • Page 2: Soldering Station

    CD / SOLDERING STATION CONTENTS SUPPLIED WITH SUPPLIED WITH CONTROL UNIT CD-2SB / CD-1SB / CD-9SB CD-2BB / CD-1BB / CD-9BB T210-A T245-A SOLDERING IRON SOLDERING IRON CL6210 Brass Wool C210001 C245003 C210008 C245007 CARTRIDGES CARTRIDGES S0331 Sponge MANUAL MANUAL...
  • Page 3 TOOL SUPORT ADJUSTEMENT CABLE COLLECTOR...
  • Page 4 TIPS CLEANING Depending on your needs you can choose between 3 diferent cleaning methods , Sponge, Metal wool (brass or Inox) and brush. CL6210 Brass Wool Very effective cleaning method. Leaves a small layer of solder on the tip so it prevents from oxidizing between cleaning and re- wetting...
  • Page 5 WIPER WIPING TAPING Use the slots to wipe any posible particle Tap smoothly the cartridge on the wiper profile sticked on the tip to remove the excess of solder OPTIONAL TIPS CLEANING CL6205 Inox Wool CL6220 Brushes A bit more agressive on the tip than the brass More agressive on the tip than the wool.

  • Page 6: Installation

    HEAT MANAGEMENT JBC stations intelligently manage the tool temperature: Work mode: When the tool is used, pre-set work temperature is 350º C. Sleep mode: When the tool is in the stand, the temperature goes down to 180º C ( depending of the configuration).
  • Page 7 WORKING Selected temp. 3 5 0 Tip temperature P o w e r 1 0 % % Instant power supplied to the tool Decrease & move down Increase & move up Access Menu & Confirm Selection SETTINGS M a i n m e n u Exit Reset settings Station settings...

  • Page 8: Technical Specifications

    Power: 75W. Safety transformer, mains separator and double isolation, with temperature protection fuse. CD-2BB / CD-2SB 230V control unit. Input: 230V 50/60Hz. Output: 24V. CD-1BB / CD-1SB 120V control unit. Input: 120V 50/60Hz. Output: 24V. CD-9BB / CD-9SB 100V control unit. Input: 100V 50/60Hz. Output: 24V.
