TABLE OF CONTENTS Slim Hide Away Type Indoor Unit – NA1E5 1. Safety Precautions ..........4 Series ............62 Low Static Pressure Hide Away Type Indoor 2. Features...............6 Unit – MA1E5 Series........64 3. Product Specification ........11 Outdoor Unit – LA1E5 Series ....66 Wall Mounted Type Indoor Unit –...
Page 3
15.5 Auto Operation ...........90 15.6 Indoor Fan Motor Operation.......91 15.7 Airflow Direction .........95 15.8 Odor Cut control .........98 15.9 Drain Pump Control........98 15.10 Filter Check Control........99 16. Indoor Unit Protection Control .....100 16.1 Odor Remove control .......100 16.2 Freeze Prevention control ......100 16.3 Dew Prevention control ......100 16.4...
1. Safety Precautions • Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing. • Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model installed. •...
Page 5
19. During installation, before run the compressor, confirm the refrigerant pipes are fixed. Operation of compressor without fixing the piping, setting the valves at open condition, a burst may occur and cause injury. 20. After completion of installation or service, confirm there is no leakage or refrigerant gas. It may generate toxic gas when the refrigerant contacts with fire or spark.
2. Features • Highly Efficient Inverter Technology Uses Panasonic advanced inverter technology, intelligent and flexible control ability to achieve energy saving; Meanwhile, the outdoor unit is capable to drive multiple indoor units. • More Variety of Indoor Unit Types There are 6 different Indoor unit types available 2.2kW...
Page 7
Wired Remote Control CZ-RT1 1. Includes an easily-visible red pilot indicator. The power can be turned on and off at a single touch, without opening the cover. 2. The build-in thermistor allows indoor temperature detection in accordance with indoor conditions by switching with indoor unit thermistor.
Page 8
Interface Module for External Control / Integration CZ-CAP1 • Demand Control With Demand Control, it is possible to limit maximum electrical current to air conditioner. This usually used to integrate with central control system, building automation system or etc. From external device, it is required to use a volt free contact (relay) for integration.
Page 9
• Heat / Cool Mode selection Must use together with Cooling / Heating Selector Switch (CZ-RD1) With the heat cool selector switch, operation mode (Heat / Cool / Fan) can be set & fixed by higher authority user. If OFF selected, Unit will operate freely base on remote setting. If ON &...
Page 10
Group control equipment Remote side Group Control by one remote control • Optional wired remote control. • All air conditioner units are controlled as a Wired Remote Control whole by the remote control. Local Side • All indoor units operate in the same mode. •...
3. Product Specification Wall Mounted Type Indoor Unit – KA1E5 / KA1E5S Series S-22KA1E5 S-28KA1E5 S-36KA1E5 Indoor Unit S-22KA1E5S S-28KA1E5S S-36KA1E5S Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply...
Page 12
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type...
Page 13
S-45KA1E5 Indoor Unit S-56KA1E5 S-45KA1E5S Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO5151 Phase Power Supply 220/230/240 220/230/240 4.50 5.60 Capacity BTU/h 15400 19100 Running Current 0.40 0.40 Input Power dB-A (H / L) 43 / 35 44 / 38 Noise level...
Page 14
External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat Exchanger Row x Stage x FPI 2 x 15 x 21 2 x 15 x 19 Size (W x H x L) 610.0 x 315.0 x 25.4 810.0 x 315.0 x 25.4 Material...
Page 15
Indoor Unit S-63KA1E5 S-71KA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO5151 Phase Power Supply 220/230/240 220/230/240 6.30 7.10 Capacity BTU/h 21500 24200 Running Current 0.45 0.50 Input Power dB-A (H / L) 46 / 39 48 / 40 Noise level...
Page 16
External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat Exchanger Row x Stage x FPI 2 x 15 x 21 2 x 15 x 21 Size (W x H x L) 810.0 x 315.0 x 25.4 810.0 x 315.0 x 25.4 Fin material...
60 x 60 Cassette Type Indoor Unit – YA1E5 Series Indoor Unit S-22YA1E5 S-28YA1E5 S-36YA1E5 Panel CZ-KPY1 Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 220/230/240 220/230/240 220/230/240 2.20 2.80 3.60 Capacity...
Page 18
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type...
Page 19
Indoor Unit S-45YA1E5 S-56YA1E5 Panel CZ-KPY1 Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO5151 Phase Power Supply 220/230/240 220/230/240 4.50 5.60 Capacity BTU/h 15400 19100 Running Current 0.35 0.35 Input Power dB-A (H / L) 39 / 35 40 / 36 Noise level...
Page 20
External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat Exchanger Row x Stage x FPI 1285 x 210 x 12.7 1285 x 210 x 12.7 Size (W x H x L) 1225 x 210 x 12.7 1225 x 210 x 12.7 Material...
95 x 95 Cassette Type Indoor Unit – UA1E5 Series Indoor Unit S-63UA1E5 S-71UA1E5 S-90UA1E5 Panel CZ-BT03P Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 6.30 7.10 9.00 Capacity BTU/h 21500 24200...
Page 22
Gas side mm (inch) 12.70 (1/2) 15.88 (5/8) 15.88 (5/8) Diameter Liquid side mm (inch) 6.35 (1/4) 9.52 (3/8) 9.52 (3/8) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type...
Slim Hide-Away Type Indoor Unit – NA1E5 Series Indoor Unit S-22NA1E5 S-28NA1E5 Panel Wired CZ-RT1 Remote Control Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 2.20 2.20 2.20 2.80 2.80 2.80 Capacity BTU/h 7500 7500 7500 9600 9600 9600...
Page 24
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat...
Page 25
Indoor Unit S-32NA1E5 S-36NA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 3.20 3.20 3.20 3.60 3.60 3.60 Capacity BTU/h 10900 10900 10900 12300 12300 12300 Running Current 0.40 0.45 0.50...
Page 26
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat...
Page 27
Indoor Unit S-45NA1E5 S-56NA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 4.50 4.50 4.50 5.60 5.60 5.60 Capacity BTU/h 15400 15400 15400 19100 19100 19100 Running Current 0.45 0.50 0.55...
Page 28
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat...
Low Static Pressure Hide-Away Type Indoor Unit – MA1E5 Series Indoor Unit S-45MA1E5 S-56MA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 4.50 4.50 4.50 5.60 5.60 5.60 Capacity BTU/h 15400...
Page 30
Gas side mm (inch) 12.70 (1/2) 12.70 (1/2) Diameter Liquid side mm (inch) 6.35 (1/4) 6.35 (1/4) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat...
Page 31
Indoor Unit S-63MA1E5 S-71MA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 6.30 5.60 5.60 7.10 7.10 7.10 Capacity BTU/h 21500 19100 19100 24200 24200 24200 Running Current 0.55 0.60 0.75...
Page 32
Gas side mm (inch) 12.70 (1/2) 15.88 (5/8) Diameter Liquid side mm (inch) 6.35 (1/4) 9.52 (3/8) Max Length m (ft) 15.0 (49.20) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Aluminium (Pre Coat) Fin Type Slit Fin Slit Fin Indoor Heat...
Page 33
Indoor Unit S-90MA1E5 Panel Wired CZ-RT1 Remote Control CZ-RWS1 (Heat-pump models) Wireless CZ-RWC1 (Cooling models) Performance Test Condition ISO 5151 Phase Power Supply 9.00 9.00 9.00 Capacity BTU/h 30700 30700 30700 Running Current 0.75 0.80 0.85 Input Power dB-A (H / L) 44 / 37 44 / 38 Noise level...
Page 34
Gas side mm (inch) 15.88 (5/8) Diameter Liquid side mm (inch) 9.52 (3/8) Max Length m (ft) 15.0 (49.20) External diameter Drain hose Length Fin material Aluminium (Pre Coat) Fin Type Slit Fin Indoor Heat Exchanger Row x Stage x FPI 3 x 12 x 18 Size (W x H x L) 860 x 252 x 38.1...
Outdoor Unit – LA1E5 Series Outdoor Unit U-6LA1E5, U-6LA1E5- 1 U-5LA1E5, U-5LA1E5-1 U-4LA1E5, U-4LA1E5-1 Performance Test Condition ISO 5151 2 x S-32NA1E5 3 x S-32NA1E5 2 x S-32NA1E5 Indoor Unit Combination 1 x S-36NA1E5 1 x S-45NA1E5 1 x S-45NA1E5 1 x S-56NA1E5 Phase Power Supply...
Page 36
Gas side mm (inch) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) Diameter Liquid side mm (inch) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) Standard Length m (ft) 23 (75.4) 23 (75.4) 23 (75.4) Length Range (min – max) m (ft) 20 – 90 (65.6 – 295.2) 20 –...
4. Dimensions Wall Mounted Type Indoor Unit 4.1.1 S-22KA1E5, S-28KA1E5, S-36KA1E5, S-45KA1E5, S-22KA1E5S, S-28KA1E5S, S-36KA1E5S, S-45KA1E5S <Top View> <Side View> <Side View> Air intake <Front View> direction Left ping Air outlet Right ping hole hole direction <Bottom View> <Rear View>...
Page 38
4.1.2 S-56KA1E5, S-63KA1E5, S-71KA1E5 <Top View> <Side View> <Side View> Air intake <Front View> direction Left ping Air outlet Right ping hole 1070 hole direction <Bottom View> <Rear View> (41-61) Relative position between the indoor unit and the installation plate <Front View> 16.5 Installation plate...
60 x 60 Cassette Type Indoor Unit 4.2.1 S-22YA1E5, S-28YA1E5, S-36YA1E5, S-45YA1E5, S-56YA1E5 down-slopw drain port (1/50 ~ 1/100) elbow indoor unit elbow 500 or 500 or more more Beam Obstacles Wireless remote controller Photo receiver unit position...
95 x 95 Cassette Type Indoor Unit 4.3.1 S-63UA1E5, S-71UA1E5, S-90UA1E5 down-slopw drain port (1/50 ~ 1/100) elbow indoor unit elbow 500 or 500 or more more Beam Obstacles Wireless remote controller Photo receiver unit position...
Outdoor Unit 4.6.1 U-4LA1E5, U-5LA1E5, U-6LE1E5, U-4LA1E5-1, U-5LA1E5-1, U-6LE1E5-1 or more or more Air intake side Space for piping, wiring and maintenance or more Air outlet side Gravity point...
60 x 60 Cassette Type Indoor Unit – YA1E5 Series 9.2.1 Main PCB INDOOR OUTDOOR JEM-A CN-TH1 CN-TH2 CN-REM ADDRESS ADDRESS CN-FM CN-STM1 CN-STM2 CN-EV LED CN-DISP CN-OPT3 CN-UN CN-TIMER...
95 x 95 Cassette Type Indoor Unit – YA1E5 Series 9.3.1 Main PCB INDOOR OUTDOOR CN-TIMER CN-TH1 CN-TH2 CN-REM ADDRESS ADDRESS CN-STM1 CN-STM2 CN-EV CN-DISP CN-OPT3 CN-UN Slim Hide Away Type Indoor Unit – NA1E5 Series 9.4.1 Main PCB INDOOR OUTDOOR CN-TIMER CN-TH1...
10. Remote Control Operating Instructions 10.1 Wired remote control CZ-RT1 Name and function of each part REMOTE The OFF/ON button cannot be used. LOCAL All wired remote control buttons can be used. Timer/time setting display Check display Fan Speed display Operation mode selection display FILTER RESET display Appear after the cumulative running time reaches...
10.2 Wireless Remote Control CZ-RWS1 – Heat Pump models / CZ-RWC1 – Cooling models Name and Function of each part Address number display Operation mode selection display Infrared Transmitter Transmit the remote control signal. Airflow direction setting display Fan speed display Temperature setting display (16°C –...
11. Installation Instruction 11.1 Pipe Length Length Calculation U-4LA1E5, U-5LA1E5, U-6LA1E5 Model Length Piping connection example U-4LA1E5-1, U-5LA1E5-1, U-6LA1E5-1 Indoor / outdoor unit height difference 30m or less Allowable height different Indoor / Indoor unit height difference 15m or less Total piping length 20m ~ 90m Main1+Main2+Main3+Main4+Sub1+Sub2+Sub3+Sub4+Sub5...
11.2 Branch Pipe Connection CZ-P155BK1 Liquid Branch Gas Branch Branch to Indoor Unit Liquid (Hi) Pipe Gas (Low) Pipe 2.2 ~ 6.3kW 0.8 ~ 2.5HP 6.35 mm (1/4”) 12.70 mm (1/2”) 7.1 ~ 9.0kW 3.0 ~ 3.5HP 9.52 mm (3/8”) 15.88 mm (5/8”) Branch to Outdoor (4,5,6HP) 9.52 mm (3/8”)
11.3 Capacity Correction Capacity correction according to the connecting pipe length is shown in figure below. The rated capacity (indicated on the name plate) is based on 7.5m connecting pipe and horizontal installation. capacity ratio 0.95 0.90 0.85 1.00 Cooling pipe length (m)...
12. Testing and Commissioning 12.1 Precautions Regarding Test Run 12.2 Check before Test Run Content check ● Is the wire set up and connected as described in the instructions? Check for any phase sequence. ● Are the wire connection’s screws loose? ●...
12.3 Test Run Procedure Test operation can be performed from outdoor unit or indoor unit (1) Test operation from outdoor unit HEATING TEST (SW2) Press COOLING (SW3) or HEATING TEST (SW2) switch from outdoor PCB (main) for one second to start the test operation. Select cooling operation first for 20 minutes before select COOLING TEST (SW3) heating operation.
13. Outdoor Unit Operation Control 13.1 System Start Control 13.1.1 Outdoor unit operation mode judgment • When remote control, centralized control, or Cool/Heat Selector Switch (CZ-RD1) is turned ON, outdoor unit operation mode is set as shown in table below: Indoor Unit Operation Condition Outdoor Unit Operation Condition Cool or Soft Dry Mode...
13.3 Deice Control • This control will operate for 1 cycle after accumulation time for heating (Compressor ON) under low outdoor ambient environment as stated in table below: Outdoor Air Temperature (°C) Heat exchanger temperature (°C) Acc. Time (minutes) -5 to -7 -3 &...
14. Outdoor Unit Protection Control 14.1 Cooling Oil Return Control • Oil Return control will operate 1 cycle for every 3 hours of compressor accumulation run times (normal cooling operation mode continuously). • Cooling oil return control will take 5 minutes to complete. •...
14.5 Compressor Discharge Temperature Control • This control will operate if compressor discharge temperature is detected hot at alert level. If Compressor Discharge Temperature 100°C, liquid bypass valve will open. If Compressor Discharge Temp 105°C, compressor frequency will reduce 10% if the compressor discharge temp still at down zone.
14.10 Cooling Low Outdoor Ambient Temperature Protection Control • When outdoor is operating in Cool Mode if outdoor ambient temperature is below -15°C and compressor is operating for 15 minutes, compressor will stop. • When outdoor ambient temperature is less than -10°C, the system will restart. 14.11 Heating High Outdoor Ambient Temperature Protection Control •...
15. Indoor Unit Operation Control 15.1 Operation Mode Priority Control • Operation modes available for remote control selection are: AUTO, COOL, DRY, HEAT and FAN • Types of operation mode which cannot be performed simultaneously at different indoor unit will be in standby condition.
15.3 Soft Dry Operation 15.3.1 Thermostat Control • Thermostat off point (ΔD) is determined using Indoor Intake Temperature - Remote Control Setting Temperature. Default thermostat off point is shown in table below: Low Static Hide-away (MA1-series) Wall Mounted 60 x 60 Cassette 95 x 95 Cassette Slim Hide-away Model...
15.4 Heating Operation 15.4.1 Thermostat Control • Thermostat off point (ΔD) is determined using Indoor Intake Temperature - Remote Control Setting Temperature. Default thermostat off point is shown in table below: Low Static Hide-away (MA1-series) Wall Mounted 60 x 60 Cassette 95 x 95 Cassette Slim Hide-away Model...
15.6 Indoor Fan Motor Operation • Type of indoor fan motor are shown in below table: Wall Mounted Type (KA1E5 Series) DC Fan Motor 60 x 60 Cassette Type (MA1E5 Series) 95 x 95 Cassette Type (NA1E5 Series) Slim Hide-away Type AC Fan Motor (NA1E5 Series) Low Pressure Hide-away Type...
Page 92
• During Heat Mode DC fan motor Manual fan speed depends on indoor heat exchanger temperature and air swing setting. Min Me Min Me C for C for cassette) Remote control cassette) Remote control setting setting Reduced Reduced Stop Stop Indoor heat exchanger temperature Indoor heat exchanger temperature Automatic air swing...
Page 93
AC fan motor Manual fan speed and Auto fan speed depends on indoor heat exchanger temperature. Min Me Remote control setting Reduced Reduced Stop Stop Indoor heat exchanger temperature Indoor heat exchanger temperature AC Fan motor control during Thermostat OFF and Compressor OFF. Temperature sampling during thermostat OFF, compressor ON and temperature between indoor intake temperature and setting temperature is below 30°C.
Page 94
Temperature sampling during thermostat OFF, compressor ON and temperature between indoor intake temperature and setting temperature is above 30°C. Compressor Thermostat 240s Sampling signal from outdoor unit 120s 120s 120s 240s 240s Remote controller Sampling time fan speed setting Skip sampling Indoor fan DC fan motor: SLo AC fan motor: Lo...
15.7 Airflow Direction 15.7.1 Wall Mounted Type (KA1E5 Series) Air swing direction setting Manual Automatic Mode Condition Step 1 Step 2 Step 3 Step 4 Normal 20° 32° 50° 68° Zone A 56° Indoor heat exchanger Zone B 56° temperature Zone C 20°...
Page 96
15.7.2 60 x 60 Cassette (YA1E5 Series) Air swing direction setting Manual Mode Condition Step 1 Step 2 Step 3 Step 4 Normal 20° 37° 53° 70° Deice 10° Heat Hot start 10° Heat removal control 20° Thermostat OFF 20° Normal 20°...
Page 97
15.7.3 95 x 95 Cassette (UA1E5 Series) Air swing direction setting Manual Mode Condition Step 1 Step 2 Step 3 Step 4 Normal 20° 35° 50° 70° Deice 10° Heat Hot start 10° Heat removal control 20° Thermostat OFF 20° Normal 20°...
15.8 Odor Cut control • This control starts when Cool / Soft Dry Mode ON and indoor fan speed is Auto. • The Auto fan pattern during this control. 40 sec 40 sec 50 sec 50 sec 20 sec 20 sec 120 sec 120 sec 20 sec...
15.10 Filter Check Control • This control detects the contamination of filter from the accumulated operation time of indoor unit Model Filter check time (hour) Wall mounted Except above 1000 • Accumulated time will be multiplied by a correction factor Fan Number Group Correction factor (%) Below Lo...
16. Indoor Unit Protection Control Protection controls applicable for Cool / Soft Dry Mode 16.1 Odor Remove control 16.2 Freeze Prevention control • This control starts when all below condition are satisfied Indoor thermostat ON and compressor ON for 4 minutes after startup. Indoor heat exchanger temperature less than 4°C.
Protection controls applicable for Heat Mode. 16.5 Hot Start Control • This control starts when all conditions below are satisfied Compressor ON after completion of deice operation. • During this control PRE HEAT will display on wired remote control LCD. Indoor unit POWER LED blinks.
17. Servicing Mode 17.1 Emergency Operation • Emergency operation can be performed in the event of misplaced of wireless remote controller. Press AC RESET Press AC RESET button for 5 second s button for 5 second s Emergency Operation 1. Press and hold the receptor's AUTO switch for less than 5s.
17.2 Pump down 1. Standby Electrical Power without switch on Operation. 2. Press (1sec) Pump Down Switch at outdoor PCB. 3. Compressor start pump down. (Operate max 10min). 4. Close Liquid Valve. 5. Wait for refrigerant collection until low pressure switch triggered, then countdown timer (40sec) started with LED indication.
17.3 Auto Restart Control Auto Restart Switch (AUTO R/S) at outdoor main PCB is a setting to enable/disable AC system for auto restart back the operation when electrical power resume back from interruption. When electrical power on, the outdoor unit will send a signal about the auto restart switch setting to all connected indoor units.
17.5 Wired Remote Control Local Setting Mode • During unit off, press the TEST RUN button for 5 seconds to enter LOCAL MODE. • Press Temperature Up / Down button to select Mode No. • Press Timer SELECT button to enter setting mode. •...
Page 106
17.5.2 Night Time Low Noise • This control turns down outdoor unit operation noise by limiting compressor and outdoor fan speed. Setting Value Description Remark Not set Normal Noise Level Level 1 Low Noise Level Level 2 Lower Noise Level Level 3 Lowest Noise Level •...
17.6 Wireless Remote Control Local Setting Mode • Press the SET button (2) to enter Local Setting Mode • Press Temperature Up / Down button to select Mode No. • Press Timer Up / Down button to select setting value. •...
17.6.2 Thermostat OFF Indoor Fan Control • During thermostat OFF and compressor OFF, indoor fan control can be alter to suit different application requirement. Setting Value Description Operation details Default control Fan control by EEPROM Fan OFF for 3 minutes, then ON for 10 10 seconds fan sampling seconds.
18. Troubleshooting Guide Outdoor Unit Abnormality Control Areas to verify Error Code Indoor / outdoor unit communication line Indoor / outdoor unit communication line, lead F27-01 disconnection error wire terminal. Total quantity / capacity of connected indoor Total quantity / capacity of connected indoor F30-01 unit error unit is insufficient or over.
Page 110
Indoor Unit Abnormality Control Areas to verify Error Code Drain pump, float switch, drain pipe, indoor unit F15-01 Drain level error main PCB, connector CN-DRMTR, CN-TH2. F17-02 Indoor DC fan motor error Indoor DC fan motor, connector CN-FM. Indoor liquid pipe temperature sensor lead wire, F20-01 Indoor liquid pipe temperature sensor error indoor unit main PCB, connector CN-TH2.
19. Technical Data 19.1 Operation Characteristic • The numbers of indoor unit connectable to one outdoor unit is shown in tables below, but the total cooling capacity of indoor unit combination must be 50% to 130% of outdoor unit cooling capacity. 14.6 Total indoor capacity (kW) Rated...
Page 147
6HP (an example of maximum kW) Outdoor unit: U-6LA1E5 (maximum combination capacity: 20.2kW) Indoor units: S-22KA1E5 (2.2kW) x 5 + S-28KA1E5 (2.8kW) x 2 + S-36KA1E5 (3.6kW) Total capacity of indoor units selected: 20.2kW 6HP (an example of maximum kW) Outdoor unit: U-6LA1E5 (maximum combination capacity: 7.8kW)
19.7 Air Flow Volume 19.7.1 Wall Mounted Type Indoor Unit S-22KA1E5 (S) S-28KA1E5 (S) S-36KA1E5 (S) S-45KA1E5 (S) /min 10.9 11.3 Cooling /min /min /min 10.3 10.9 11.6 12.1 Heating /min 10.2 10.6 /min S-56KA1E5 S-63KA1E5 S-71KA1E5 /min 15.3 16.0 17.4...
Page 149
S-22YA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 150
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 151
S-28YA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 152
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 153
S-36YA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 154
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 155
S-45YA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 156
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 157
S-56YA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 158
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 159
19.7.3 90 x 90 Cassette Type Indoor Unit S-63UA1E5 S-71UA1E5 S-90UA1E5 /min 21.0 22.0 22.0 /min 19.0 20.0 20.0 /min 17.0 18.0 18.0 S-63UA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec...
Page 160
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 161
S-71UA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 162
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 163
S-90UA1E5 Airflow direction:20° 1. Cooling Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Cooling Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Cooling Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
Page 164
Airflow direction:70° 1. Heating Hi Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 2. Heating Me Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m) 3. Heating Lo Air velocity distribution 1m/sec over 0.5~1m/sec 0~0.5m/sec Reaching distance(m)...
19.8 Sound Data 19.8.1 Wall Mounted Type Indoor Unit H ○━━○ S-28KA1E5、S-28KA1E5S H ○━━○ S-22KA1E5、S-22KA1E5S M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 33 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB)
Page 172
H ○━━○ S-56KA1E5 S-63KA1E5 H ○━━○ M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 38 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60 NC-50 NC-50 NC-40 NC-40...
Page 173
19.8.2 60 x 60 Cassette Type Indoor Unit H ○━━○ S-22YA1E5 H ○━━○ S-28YA1E5 M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 33 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60...
Page 174
S-56YA1E5 H ○━━○ M △━━△ Octave Band Central Frequency(Hz) L □━━□ Frequency 50Hz Fan Speed A-scale(dB) 40 36 C-scale(dB) C-scale(dB) Back Ground Noise12dB NC-60 NC-50 NC-40 NC-30 NC-20 125 250 500 1000 2000 4000 8000 Frequency(Hz)
19.8.3 95 x 95 Cassette Type Indoor Unit H ○━━○ H ○━━○ S-63UA1E5(230V) S-71UA1E5(230V) M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 35 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60...
Page 176
19.8.4 Slim Hide-Away Type Indoor Unit H ○━━○ S-28NA1E5(230V) H ○━━○ S-22NA1E5(230V) M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 30 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60...
Page 177
H ○━━○ H ○━━○ S-56NA1E5(230V) S-45NA1E5(230V) M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 32 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60 NC-50 NC-50 NC-40 NC-40...
Page 178
19.8.5 Low Static Pressure Type Indoor Unit H ○━━○ H ○━━○ S-45MA1E5(230V) S-56MA1E5(230V) M △━━△ M △━━△ Octave Band Central Frequency(Hz) Octave Band Central Frequency(Hz) L □━━□ L □━━□ Frequency 50Hz Frequency 50Hz Fan Speed Fan Speed A-scale(dB) 40 35 A-scale(dB) C-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60...
H ○━━○ S-90MA1E5(230V) M △━━△ Octave Band Central Frequency(Hz) L □━━□ Frequency 50Hz Fan Speed A-scale(dB) 40 37 C-scale(dB) C-scale(dB) Back Ground Noise12dB NC-60 NC-50 NC-40 NC-30 NC-20 125 250 500 1000 2000 4000 8000 Frequency(Hz)
Page 180
19.8.6 Outdoor Unit H ○━━○ U-4LA1E5(Heating) H ○━━○ U-4LA1E5(Cooling) Frequency 50Hz Octave Band Central Frequency(Hz) Frequency 50Hz Octave Band Central Frequency(Hz) Fan Speed Fan Speed A-scale(dB) A-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20...
Page 181
H ○━━○ U-6LA1E5(Cooling) U-6LA1E5(Heating) H ○━━○ Frequency 50Hz Octave Band Central Frequency(Hz) Frequency 50Hz Octave Band Central Frequency(Hz) Fan Speed Fan Speed A-scale(dB) A-scale(dB) C-scale(dB) C-scale(dB) Back Ground Noise12dB Back Ground Noise12dB NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20 125 250 500 1000 2000 4000 8000 125 250 500 1000 2000 4000 8000 Frequency(Hz)
21. Allowable Pipe Length U-4LA1E5/5LA1E5/6LA1E5 Pipe connection example IN/OUT Allowable height 30m or less height difference difference IN/IN height 15m or less difference Total pipe Main1+Main2+Main3+Main4+Sub1+Sub2 20m~90m length +Sub3+Sub4+Sub5 Total pipe length of 40m or less Main1+Main2+Main3+Main4 Main pipe Total pipe length of Sub 50m or less Sub1+Sub2+Sub3+Sub4+Sub5...
23. Exploded View and Replacement Parts List 23.1 Indoor Unit 23.1.1 S-22KA1E5 S-22KA1E5S S-28KA1E5 S-28KA1E5S S-36KA1E5 S-36KA1E5S S-45KA1E5 S-45KA1E5S CWH55025J CWH55051AJ Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 259
REF. PART NAME & DESCRIPTION S-22KA1E5 S-22KA1E5S REMARK CHASSY COMPLETE CWD50C1653 CWD50C1666 FAN MOTOR L6CBYYYL0058 L6CBYYYL0058 CROSS FLOW FAN COMPLETE CWH02C1076 CWH02C1076 BEARING ASS’Y CWH64K007 CWH64K007 SCREW - CROSS FLOW FAN CWH551146 CWH551146 EVAPORATOR CWB30C3135 CWB30C3135 FLARE NUT (LIQUID) CWT251030...
Page 260
REF. PART NAME & DESCRIPTION S-28KA1E5 S-28KA1E5S REMARK CHASSY COMPLETE CWD50C1653 CWD50C1666 FAN MOTOR L6CBYYYL0058 L6CBYYYL0058 CROSS FLOW FAN COMPLETE CWH02C1076 CWH02C1076 BEARING ASS’Y CWH64K007 CWH64K007 SCREW - CROSS FLOW FAN CWH551146 CWH551146 EVAPORATOR CWB30C3136 CWB30C3136 FLARE NUT (LIQUID) CWT251030 CWT251030 FLARE NUT (GAS) CWT251032...
Page 261
REF. PART NAME & DESCRIPTION S-36KA1E5 S-36KA1E5S REMARK CHASSY COMPLETE CWD50C1653 CWD50C1666 FAN MOTOR L6CBYYYL0058 L6CBYYYL0058 CROSS FLOW FAN COMPLETE CWH02C1076 CWH02C1076 BEARING ASS’Y CWH64K007 CWH64K007 SCREW - CROSS FLOW FAN CWH551146 CWH551146 EVAPORATOR CWB30C3136 CWB30C3136 FLARE NUT (LIQUID) CWT251030 CWT251030 FLARE NUT (GAS) CWT251032...
Page 262
REF. PART NAME & DESCRIPTION S-45KA1E5 S-45KA1E5S REMARK CHASSY COMPLETE CWD50C1653 CWD50C1666 FAN MOTOR L6CBYYYL0058 L6CBYYYL0058 CROSS FLOW FAN COMPLETE CWH02C1076 CWH02C1076 BEARING ASS’Y CWH64K007 CWH64K007 SCREW - CROSS FLOW FAN CWH551146 CWH551146 EVAPORATOR CWB30C3136 CWB30C3136 FLARE NUT (LIQUID) CWT251030 CWT251030 FLARE NUT (GAS) CWT251032...
Page 263
23.1.2 S-56KA1E5 S-63KA1E5 S-71KA1E5 CWH55025J CWH55051AJ Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 264
REF. PART NAME & DESCRIPTION S-56KA1E5 S-63KA1E5 S-71KA1E5 REMARK CHASSY COMPLETE CWD50C1665 CWD50C1665 CWD50C1665 FAN MOTOR L6CBYYYL0057 L6CBYYYL0057 L6CBYYYL0057 CROSS FLOW FAN COMPLETE CWH02C1077 CWH02C1077 CWH02C1077 BEARING ASS’Y CWH64K007 CWH64K007 CWH64K007 SCREW - CROSS FLOW FAN CWH551146 CWH551146 CWH551146 EVAPORATOR CWB30C3141 CWB30C3151 CWB30C3160...
Page 265
23.1.3 S-22YA1E5 S-28YA1E5 S-36YA1E5 S-45YA1E5 S-56YA1E5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 266
Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 267
REF. PART NAME & DESCRIPTION S-22YA1E5 S-28YA1E5 S-36YA1E5 REMARK BASE PAN ASS’Y CWD52K1100 CWD52K1100 CWD52K1100 INNER POLYSTYRENE COMPLETE CWG07C1067 CWG07C1067 CWG07C1067 CABINET SIDE PLATE ASS’Y CWE041121 CWE041121 CWE041121 CABINET SIDE PLATE ASS’Y CWE041122 CWE041122 CWE041122 FAN MOTOR,DC 40W 3 PH L6CBYYYL0048 L6CBYYYL0048 L6CBYYYL0048...
Page 268
REF. PART NAME & DESCRIPTION S-45YA1E5 S-56YA1E5 REMARK BASE PAN ASS’Y CWD52K1100 CWD52K1100 INNER POLYSTYRENE COMPLETE CWG07C1067 CWG07C1067 CABINET SIDE PLATE ASS’Y CWE041121 CWE041121 CABINET SIDE PLATE ASS’Y CWE041122 CWE041122 FAN MOTOR,DC 40W 3 PH L6CBYYYL0048 L6CBYYYL0048 ANTI-VIBRATION BUSHING CWH501105 CWH501105 CORD HOLDER CWD741024...
Page 269
Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 270
REF. PART DESCRIPTION PART NO. PART NO. PART NO. REMARK FRONT GRILLE - COMPLETE CWE11C4526 CWE11C4526 CWE11C4526 A.S MOTOR DC SINGLE 12V 250 OHM CWA981105J CWA981105J CWA981105J BRACKET - A.S.MOTOR CWD932522 CWD932522 CWD932522 VANE CWE241159 CWE241159 CWE241159 SHAFT CWH631038 CWH631038 CWH631038 SHAFT CWH631045...
Page 271
23.1.4 S-63UA1E5 S-71UA1E5 S-90UA1E5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 272
Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 273
REF. PART NAME & DESCRIPTION S-63UA1E5 S-71UA1E5 S-90UA1E5 REMARK BASE PAN ASS'Y D52K1111 D52K1111 D52K1111 INNER POLYSTYRENE COMPLETE G07C1060 G07C1060 G07C1060 CABINET SIDE PLATE E041139 E041139 E041139 CABINET SIDE PLATE E041140 E041140 E041140 FAN MOTOR L6LAJYF00017 L6LAJYF00017 L6LAJYF00017 ANTI-VIBRATION BUSHING H501016 H501016 H501016...
Page 275
23.1.5 S-22NA1E5 S-28NA1E5 S-32NA1E5 S-36NA1E5 S-45NA1E5 S-56NA1E5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 278
23.1.6 S-45MA1E5 S-56MA1E5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 279
QUANTITY PER 1 UNIT REMARK REF. PART NAME PARTS NUMBER S-45MA1E5 S-56MA1E5 PANEL BOTTOM P42-T04150 DRAIN PAN ASSY P42-T04460 STAY DRAIN PAN ASSY P45-T09250 PANEL SIDE L ASSY P42-T04390 PANEL TOP ASSY P42-T03740R PANEL SIDE R ASSY P42-T04280 FAN BASE P45-T07690R FAN BRACKET L P02-T07890R...
Page 280
QUANTITY PER 1 UNIT REMARK REF. PART NAME PARTS NUMBER S-63MA1E5 S-71MA1E5 S-90MA1E5 PANEL BOTTOM P42-T04160 DRAIN PAN ASSY P42-T04470 STAY DRAIN PAN ASSY P45-T08740 PANEL SIDE L ASSY P42-T04290 PANEL TOP ASSY P42-T03750R PANEL SIDE R ASSY P42-T04280 FAN BASE ASSY P45-T08850 FAN BRACKET L P02-T07890R...
Page 281
23.1.7 U-4LA1E5-1 U-5LA1E5-1 U-6LA1E5-1 U-4LA1E5 U-5LA1E5 U-6LA1E5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 282
Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 283
Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 284
REF. PART NAME & DESCRIPTION U-4LA1E5-1 U-5LA1E5-1 U-6LA1E5-1 REMARK BASE PAN ASS'Y CWD52K1164A CWD52K1164A CWD52K1164A COMPRESSOR CWB092390 CWB092390 CWB092390 ANTI-VIBRATION BUSHING CWH50055 CWH50055 CWH50055 CWH561049 CWH561049 CWH561049 PARTICULAR PLATE CWD911471 CWD911471 CWD911471 HEATER CWA341037 CWA341037 CWA341037 FIN & TUBE CONDENSER COMPLETE CWB32C2896 CWB32C2887 CWB32C2887...
