TECHNICAL SPECIFICATIONS
ROUTING
• Supports IP/TCP/UDP/ARP/ICMP/IGMP protocols
• IP routing with static routing and RIPv1/RIPv2 (RFC1058/2453)
• IP multicast and IGMP proxy (RFC1112/2236)
• Network address translation (NAT/PAT) (RFC1631)
• NAT ALGs for ICQ/Netmeeting/MSN/Yahoo Messenger
• DNS relay and caching (RFC1034/1035)
• DHCP server, client and relay (RFC2131/2132)
BRIDGING
• IEEE 802.1D transparent learning bridge
• IEEE 802.1q VLAN • Port-based VLAN
• Spanning tree protocol
SECURITY
• DMZ host/Multi-DMZ/Multi-NAT function
• Virtual server mapping (RFC1631)
• VPN pass-through for PPTP/L2TP/IPSec tunneling
• Natural NAT firewall
• Advanced Stateful packet inspection (SPI) firewall
• Application level gateway for URL and keyword blocking
• User access control: deny certain PCs access to Internet service
MANAGEMENT
• Easy-to-use web-based GUI for quick setup, configuration and
management
• Menu-driven interface/Command-line interface (CLI) for local
console and Telnet access
• Password protected management and access control list for
administration
• SNMP management SNMPv1/SNMPv2 (RFC1157/1901/1905)
agent & MIB II (RFC1213/1493)
• Software upgrade via web-browser/TFTP server
ATM
• Up to 8 PVCs • OAM F5 AIS/RDI and loopback
• AAL5
ATM QOS
• UBR (Unspecified bit rate) • CBR (Constant bit rate)
• VBR-rt (Variable bit rate real-time)
• VBR-nrt (Variable bit rate non-real-time)
AAL5 ENCAPSULATION
• VC multiplexing and SNAP/LLC
• Ethernet over ATM (RFC 2684/1483)
• PPP over ATM (RFC 2364)
• Classical IP over ATM (RFC 1577) PPP
• PPPoE for fixed & dynamic IP (RFC 2516)
• PPP over ATM for fixed and dynamic IP (RFC 2364)
• User authentication with PAP/CHAP/MS-CHAP
WAN INTERFACE
• SHDSL: ITU-T G.991.2 (Annex A, Annex B)
• Encoding scheme: 16-TCPAM
• Data Rate (2-wire mode): N x 64Kbps (N=0~36, 0 for adaptive)
• Data Rate (4-wire mode): N x 128kbps (N=0~36, 0 for adaptive)
• Impedance: 135 ohms
LAN INTERFACE
• 4-ports switching hub
• 10/100 Base-T auto-sensing and auto-negotiation
• Auto-MDIX
HARDWARE INTERFACE
• WAN: RJ-11 • LAN: RJ-45 x 4
• Console: RS232 female • RST: Reset button for factory
default
INDICATORS
• General: PWR • WAN: LNK, ACT
• LAN: 1, 2, 3, 4 • SHDSL: ALM
PHYSICAL/ELECTRICAL
• Dimensions: 18.7 x 3.3 x 14.5cm (WxHxD)
• Power: 100~240VAC (via power adapter)
• Power consumption: 9 watts max
• Temperature: 0~45 o C
• Humidity: 0%~95%RH (non-condensing)
MEMORY
• 2MB Flash Memory, 8MB SDRAM
NB714 G.SHDSL
2-wire or 4-wire SHDSL Modem Router

Key Features:

Built-In advanced SPI firewall
Four 10/100Mbps Auto-negotiation and Auto-MDIX switching ports for flexible LAN connectivity
DMZ host/Multi-DMZ/Multi-NAT enables multiple workstations on the LAN to access the Internet
Full ATM protocol stack implementation over SHDSL
PPPoA and PPPoE support user authentication with PAP/CHAP/MS-CHAP
SNMP management with SNMPv1/SNMPv2 agent and MIB II
Enhancements and new features are available via Internet software upgrade
3-YEAR WARRANTY WHEN YOU REGISTER ONLINE
1 year warranty out of the box. Extra 2 years FREE with online registration at
(Conditional upon online registration
PACKAGE CONTENTS
• NB74 (2-wire/4-wire) G.SHDSL Modem Router
• 9V DC 1.0 Amp power supply
• RS232 Console Cable
Internet
Firewall
Your NetComm dealer:
NETCOMM LIMITED PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
• RJ11 line connection cable
• RJ45 10/100 Ethernet cable
• User Guide CD
NB714
G.SHDSL Modem Router
PC PC
www.netcomm.com.au
PC PC
