Key Features - NetComm NB5Plus4W Specifications

NB5Plus4W

KEY FEATURES

ADSL2+ Modem Router: supports ADSL, ADSL2
and ADSL2+
11g Wireless Access Point with WEP, WPA –
802.1x Security
Advanced Security Firewall (NAT, SPI and DoS support)
Fast, safe and versatile with both USB and four
Ethernet switch ports
Universal Plug & Play (UPnP) and IP Quality of Service (QoS)
Easy Set-up and Video Tutorials
VPN pass through
VoIP ready
3-YEAR WARRANTY WHEN YOU REGISTER ONLINE
1 year warranty out of the box. Extra 2 years FREE with
online registration at www.netcomm.com.au
(Conditional upon online registration)
TECHNICAL SPECIFICATIONS
WAN/LAN INTERFACE
• ANSI T1.413 issue 2
• ITU-T G.992.1 (G.dmt) and G.992.2 (G.lite) compliant
• ADSL2/2+, G.992.3/G.992.5
• Rate Adaptive modem at 32 Kbps steps
• Dynamic Adaptive Equalisation to improve Carrier's service area
• Bridge Tap Mitigation support
• Turbo DSL support improving packet throughput
performance by three times
• ATM Layer with Traffic shaping QoS Support (UBR, CBR,
VBR-rt, VBR-nrt)
• AAL ATM Attributes – AAL5
• Multiple PVC's – up to 8 supported
• Spectral compatibility with POTS
• F5 OAM Loop backs/Send and Receive
ENCAPSULATION SUPPORT
• RFC2684 Bridged and Routed LLC and VC Mux support
• RFC2364 PPPoA client support
• RFC2516 PPPoE client support
• RFC2225/RFC1577 classical IP support
• Transparent Bridge support
• PAP/CHAP/MS-CHAP for password authentication support
NETWORK SUPPORT
• Port Forwarding rules for popular games/applications
• Static IP, dynamic RIP routing support
• IP/TCP/UDP/ICMP/ARP/RARP application support
• Network Address Translation (NAT)
• Port mapping/forwarding
• IGMP Multicast
• SNTP (Simple Network Time Protocol)
Your NetComm dealer:
4-Port ADSL2 + Modem Router with 11g Wireless
• NAT Application Level Gateway for popular applications
• DHCP Server/Relay/Client
• DNS Relay Agent
• DMZ support
• Single session IP Sec and PPTP/L2TP VPN
pass-through support
• PPP Always On with configurable timeout
VoIP
• SIP version 1 & 2, H.323, MGCP support
• IP QoS support for voice packets
SECURITY
• NAT for basic Firewall and sharing
• Packet Filtering Firewall support
• Stateful Packet Inspection support
• Protection against Denial of Service attacks
• Password authentication to modem
WIRELESS
• 802.11g, 802.11b backwards compatible
• Auto/manual data rates of 54, 48, 36, 24,18,12, 11, 9, 6,
5.5, 2, 1Mbps
• WEP 128/64bit Pass phrase generator
• WPA
• 802.1x (Radius) authentication
• Multiple SSID support
• MAC address filtering
• SSID beacon (Enable/Disable)
• Removable omni-directional antenna, reverse SMA
MANAGEMENT SUPPORT
• Web-based HTTP management GUI (LAN or Remote)
• TFTP/FTP support for firmware upgrade
NETCOMM LIMITED
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
Internet
Connected to
11g Wireless Interface
Connected to inbuilt 4-port Ethernet switch
PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
Connected to
USB Interface
Firewall
NB5Plus4W ADSL2 +
Modem Router with 11g Wireless
• Web-based firmware upgrade (Local)
• Soft Factory Reset button via Web GUI
• Diagnostic test (DSL, OAM, Network, Ping Test)
• Telnet/CLI (read only)
• SNMP (Simple Network Management Protocol)
• Syslog support
HARDWARE
• Texas Instrument TNETD7300 single chip network
processor/line driver chipset
• Dying Gasp support
• A-Tick approval
PLATFORM SUPPORT
• Ethernet – OS independent: includes Windows
and UNIX
• USB – Windows® 98SE, ME, 2000, XP, 2003
LED INDICATORS
• 1 x PPP LED • 1 x WLAN LED • 1 x Power LED
ADSL Link Status LED • 4 x Ethernet Link/Activity Status
LED • 1 x USB Status LED
PACKAGE CONTENTS
• NB5Plus4W ADSL2+ Modem Router with 11g Wireless
• 15V AC 1.0 Amp power supply
• RJ11 ADSL line connection cable
• RJ11 to 605 line adaptor
• RJ45 10/100 Ethernet cable
• USB connection cable
• Removable antenna
• Driver/Manual and Utility Software CD
• Package Contents List
• Quick Start Guide
, Mac, Linux
®
• 1 x
