Key Features - NetComm NB5Plus4 Specifications

NB5Plus4

KEY FEATURES

ADSL2+ Modem Router: supports ADSL, ADSL2
and ADSL2+
Advanced Security Firewall (NAT, SPI and DoS support)
Fast, safe and versatile with both USB and four
Ethernet switch ports
Universal Plug & Play (UPnP) and Quality of Service (QoS)
Easy Set-up and Video Tutorials
VPN pass through
VoIP ready
3-YEAR WARRANTY WHEN YOU REGISTER ONLINE
1 year warranty out of the box. Extra 2 years FREE with
online registration at www.netcomm.com.au
(Conditional upon online registration)
TECHNICAL SPECIFICATIONS
WAN/LAN INTERFACE
• ANSI T1.413 issue 2
• ITU-T G.992.1 (G.dmt) and G.992.2 (G.lite) compliant
• ADSL2/2+, G.992.3/G.992.5
• Rate Adaptive modem at 32 Kbps steps
• Dynamic Adaptive Equalisation to improve Carrier's service area
• Bridge Tap Mitigation support
• Turbo DSL support improving packet throughput
performance by three times
• ATM Layer with Traffic shaping QoS Support (UBR, CBR,
VBR-rt, VBR-nrt)
• AAL ATM Attributes – AAL5
• Multiple PVCs – up to 8 supported
• Spectral compatibility with POTS
• F5 OAM Loopbacks/Send and Receive
ENCAPSULATION SUPPORT
• RFC2684 Bridged and Routed LLC and VC Mux support
• RFC2364 PPPoA client support
• RFC2516 PPPoE client support
• RFC2225/RFC1577 classical IP support
• Transparent Bridge support
• PAP/CHAP/MS-CHAP for password authentication support
NETWORK SUPPORT
• Port Forwarding rules for popular games/applications
• Static IP, dynamic RIP routing support
• IP/TCP/UDP/ICMP/ARP/RARP application support
• Network Address Translation (NAT)
Your NetComm dealer:
4-Port ADSL2 + Modem Router
• Port mapping/forwarding
• IGMP Multicast
• SNTP
• NAT Application Level Gateway for popular applications
• DHCP Server/Relay/Client
• DNS Relay Agent
• DMZ support
• Single session IP Sec and PPTP/L2TP VPN
pass-through support
• PPP Always On with configurable timeout
VoIP
• SIP version 1 & 2, H.323, MGCP support
• QoS support for voice packets
SECURITY
• NAT for basic firewall and sharing
• Packet Filtering firewall support
• Stateful Packet Inspection (SPI) support
• Protection against Denial of Service (DoS) attacks
• Password authentication to modem
MANAGEMENT SUPPORT
• Web-based HTTP management GUI (LAN or Remote)
• TFTP/FTP support for firmware upgrade
• Web-based firmware upgrade (Local)
• Soft Factory Reset button via Web GUI
• Diagnostic test (DSL, OAM, Network, Ping Test)
• Telnet/CLI (read only)
NETCOMM LIMITED
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
Internet Firewall
NB5Plus4
ADSL2 + Modem Router
Connected to inbuilt 4-port Ethernet switch
•
•
HARDWARE
•
•
•
•
PLATFORM SUPPORT
•
•
LED INDICATORS
•
•
PACKAGE CONTENTS
•
•
•
•
•
•
•
•
•
PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
Connected to
USB Interface
SNMP
Syslog support
Texas Instruments TNETD7300 single chip network
processor line driver chipset
Dying Gasp support
A-Tick approval
Ethernet – OS independent: includes Windows
Mac, Linux and UNIX
USB – Windows® 98SE, ME, 2000, XP, 2003
1 x PPP LED • 1 x Power LED • 1 x ADSL Link Status LED
4 x Ethernet Link/Activity Status LED • 1 x USB Status LED
NB5Plus4 ADSL2+ Modem Router
15V AC 1.0 Amp power supply
RJ11 ADSL line connection cable
RJ11 to 605 line adaptor
RJ45 10/100 Ethernet cable
USB connection cable
Driver/Manual and Utility Software CD
Package Contents List
Quick Start Guide
,
®
