VISUAL DISPLAY DISPENSER
O
M
WNERS
ANUAL
M
: JT20, JT20-W25, JT20-W26
ODEL
Publication Number: 621058565INS
Revision Date: June 24, 2014
Revision: A
Visit the Cornelius web site at www.cornelius.com for all your Literature needs.

Advertisement

Table of Contents
loading

Related Manuals for Cornelius JT20

Summary of Contents for Cornelius JT20

  • Page 1 VISUAL DISPLAY DISPENSER WNERS ANUAL : JT20, JT20-W25, JT20-W26 ODEL Publication Number: 621058565INS Revision Date: June 24, 2014 Revision: A Visit the Cornelius web site at www.cornelius.com for all your Literature needs.

  • Page 2: Contact Information

    Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal...

  • Page 3: Table Of Contents

    Setting up your JT20 ........

  • Page 5: Safety Instructions

    Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE. © 2014, Cornelius Inc. - 1 - Publication Number:621058565INS...

  • Page 6: Safety Precautions

    Before shipping, storing, or relocating the unit, the unit must be sanitized and all sanitizing solution must be drained from the system. A freezing ambient environment will cause residual sanitizing solution or water remaining inside the unit to freeze resulting in damage to internal components. Publication Number: 621058565INS - 2 - © 2014, Cornelius Inc.

  • Page 7: General Description

    JetSpray Owner’s Manual GENERAL DESCRIPTION The JT20 dispenser is a counter top visual display action beverage dispenser. It is designed to dispense a variety of products. WARNING: This appliance should be earthed. This appliance is not suitable for use by unsupervised children.

  • Page 8: Specifications

    Over 10 U.S. gallon, 40 litres. Capacity Over 6 U.S. gallons, 24 litres Refrigeration Jet Spray 1/5 h.p. hermetically sealed system. Spray Drive and Fan Motor No oiling required Power Drive Magnet Permanent INDOX magnet. Publication Number: 621058565INS - 4 - © 2014, Cornelius Inc.

  • Page 9: Installation And Operating Instructions

    2. Consider installation of a drain hose which connects to outlet on drip tray bottom (Part No. 18747001). 3. Turn bowl upside down and insert gasket into groove. Wet gasket for ease of insertion, pressing gasket into groove while following numbers (see Fig. 2). © 2014, Cornelius Inc. - 5 - Publication Number: 621058565INS...
  • Page 10 7. Slide bowl over the cooling tubes and assemble the bowl to the dispenser. Be careful not to wrinkle gasket as it will result in beverage leaking out of bowl (see Fig. 5). Publication Number: 621058565INS - 6 - © 2014, Cornelius Inc.
  • Page 11 Make sure end of tube does not get caught on edge above handle support spout opening, pull end of tube for final seating into bowl spout seat. Make sure tube is free of wrinkles and extends below sup- port spout above ¼ inch (see Fig 7) © 2014, Cornelius Inc. - 7 - Publication Number: 621058565INS...

  • Page 12: Operating Procedures

    NOTE: If unit is to be used to dispense beverage from only one bowl, use right hand bowl, but add a gallon of water to left bowl to assure proper cooling. 3. The thermostat is preset at the factory and will not normally require resetting by owner. Publication Number: 621058565INS - 8 - © 2014, Cornelius Inc.

  • Page 13: Frequent Maintenance Procedures

    2. To replace condensate drains, hold drain against front panel under rectangular hole (opening in side of drain should be toward front panel). Push up through hole until drain snaps into place (see Fig 9). Towards Front Panel Figure 9. © 2014, Cornelius Inc. - 9 - Publication Number: 621058565INS...

  • Page 14: Sanitizing Unit

    Circulator : Slide impeller up on shaft and clean underside of impeller at center. If impeller rubs on base of circulator, replace. NOTE: Switch must be "OFF" when inserting the pump housing assembly into the bowl to assure magnetic coupling. Publication Number: 621058565INS - 10 - © 2014, Cornelius Inc.

  • Page 15: Bowl Leaks

    2. Be sure gasket has been put on properly. Check gasket for tears or cuts in rubber as they cause leaks. 3. Remove and examine pinch tube for holes. Figure 11. JT20 Wiring Diagram © 2014, Cornelius Inc. - 11 -...
  • Page 16 JetSpray Owner’s Manual Publication Number: 621058565INS - 12 - © 2014, Cornelius Inc.
