MAINTENANCE
18.9

Combustion block

9
8
7
6
5
4
3
2
1
Legend
1 Gas valve connection
2 Grounding cable
3 Spark electrode inlet
4 Spark electrode retaining screw.
5 Spark electrode gasket
6 Spark electrode
7 burner retaining nut
8 Burner retaining screw
9 Thermal fuse connection
- 44 -
Supplied By www.heating spares.co Tel. 0161 620 6677
10 Coil
11 Heat exchanger
12 burner gasket
13 burner
14 Gas valve
15 fan
16 fan connection
17 Gas pipe
10
11
12
13
14
15
16
17
0020085231_02 - 05/10 - Glow-worm
