INSTALLATION
13.2.2 After Sales Service settings
• Press for more than 7 seconds on the button
access the configuration menu. The screen displays "0".
• Press on button
or under the symbol
After Sales Service password.
• Press on
to validate. The screen displays the
parameter "00" and its value "XX".
• Press on button
or under the symbol
parameter to modify.
• Press on button
or under the symbol
value of the parameter.
• Repeat the process for each parameter modified.
• Press for more than 3 seconds on the button
the configuration menu.
Code Parameter
d.08 Current state of the 230V room thermostat
d.09 Flow temperature set point from external eBus control
d.10 Heating pump status
d.16 Current state of the 24V room thermostat
d.17 Flow or Return temperature monitoring
d.21 Warmstart status
d.22 DHW demand active (tapping)
d.23 Central heating mode
d.25 Warm start
d.33 Speed setpoint of fan
d.44 Digitalized ionisation voltage
Unsuccessfull ignitions at first attempt
d.68
d.69 Unsuccessfull ignitions at second attempt
d.80 Operating hours in heating mode
d.81 Operating hours in domestic hot water mode
d.82 Number of burner starts in heating mode
d.83 Number of burner starts in DHW mode
Device Specific Number
d.93
d.96 Factory reset
- 30 -
Supplied By www.heating spares.co Tel. 0161 620 6677
to
and enter the
to access the
to modify the
to exit
Unit Description
230V room thermostat :
- 0 = open (no heating),
1 = closed (heating mode).
°C External eBus set value.
0 = off
-
1 = on
0 = open (no heating),
°C
1 = closed (heating mode)
Temperature regulation on flow (radiator) or return
°C
(under-floor heating) temperature sensor.
0 = warmstart function disabled
-
1 = warmstart activated
0 = off
-
1 = on
0 = CH not available (summer mode)
-
1 = CH available (winter mode)
Loading enabled or disabled by Appliance Interface
-
or Ebus or external controls.
Fan speed is displayed between 0 and 99.
rpm
Multiply the displayed value by 100.
V Display the digitalized ionisation voltage
Display the number of unsuccessfull ignitions at first
-
attempt.
Display the number of unsuccessfull ignitions at
-
second attempt.
Display the number of operating hours in heating
h
mode. Multiply the displayed value by 100.
Display the number of operating hours in domestic
h
hot water mode. Multiply the displayed value by 100.
Display the number of burner starts in heating
-
mode. Multiply the displayed value by 100.
Display the number of burner starts in DHW mode.
-
Multiply the displayed value by 100.
Select the product code of the appliance:
24cxi = 15
-
30cxi = 22
35cxi = 17
All parameters stored in EEPROM (main board +
appliance interface) are reset to factory settings if
- this function is activated.
0 = deactivated
1 = activated
Modifiable
factory
setting parameter
- no
- no
- no
- no
0 yes
- no
- no
- no
- no
- no
- no
- no
- no
- no
- no
- no
- no
15
yes
22
17
0 yes
