• Do likewise for each parameter that needs to be modified.
• Press for more than 3 seconds on the button
the configuration menu.
Code Parameter
d.00 Maximum heating power
d.01 Pump over-run time - heating
Blocking time for burner in heating
d.02
mode (anti-cycle time)
The following menu is displayed if a domestic hot water tank is connected to the appliance.
d.03 Temperature of the DHW outlet
d.04 Temperature of water in the tank
d.18 Pump function
d.19 Speed of the pump
Maximum temperature setting for
d.20
domestic hot water
The following 2 menus are displayed if an option card (not supplied) is installed on the appliance.
d.27 Function relay 1
d.28 Function relay 2
d.34 Speed of fan
Domestic hot water flow
d.36
Heating flow temperature
d.40
d.41 Heating return temperature
The following 2 menus are displayed if an outdoor sensor (not supplied) is installed on the appliance.
d.43 Heating curve
d.47 Exterior temperature
Time remaining before the end of the
d.67
anti-cycle in heating mode.
Maximum temperature setting for
d.71
heating outlet
d.90 Detection of eBUS controller
0020085231_02 - 05/10 - Glow-worm
Supplied By www.heating spares.co Tel. 0161 620 6677
to exit
Unit Description
Choose a value:
24cxi ► 5 to 18 kW
kW
30cxi ► 6 to 25 kW
35cxi ► 8 to 30 kW
min. Choose a value between 2 and 60.
To prevent the burner frequently switching on and off,
the reactivation of the burner is electronically blocked for a period
that is determined each time the burner stops. The burner blocking
time can be adapted to the usage conditions for the heating
min.
installation and depends on the temperature that is set for heating:
- at 80°C, the period is fixed (2 minutes)
- at 10°C, the period is adjustable: choose a value between 2 and
60 minutes.
°C Display the temperature of the DHW outlet.
°C Display tank water temperature.
Mode:
0 = With the burner
-
1 = Continuous with ambient temperature
2 = Continuous
Functioning mode:
0 = Automatic: maximum speed when the burner is switched on
- 1 = Minimum speed
2 = Automatic: automatic speed when the burner is switched on
3 = Maximum speed
The recommended maximum temperature setting for domestic hot
°C
water is 60°C. Choose a value suitable for your needs.
- Reserved for future use
- Reserved for future use
Fan speed is displayed between 0 and 99.
rpm
Multiply the displayed value by 100.
Display domestic hot water flow.
l/min.
Display the heating flow temperature.
°C
°C Display the heating return temperature.
See the instructions for the external sensor connected to the
K
appliance.
°C Display the temperature measured by the external sensor.
min. Display the time remaining before the end of the anti-cycle.
°C Select a value between 50°C and 80°C.
0 = Not detected
-
1 = Detected
