Summary of Contents for Matsui mf654ewn
-
Page 2: Table Of Contents
ChapterⅠ Installation-------------------------------------------------------------1 Safety Instruction------------------------------------------------------- 1 Installation Instruction--------------------------------------------------- 2 Trial running----------------------------------------------------------- 4 ChapterⅡ Maintenance----------------------------------------------------------- 5 Foreword-------------------------------------------------------------- 5 Troubleshooting-------------------------------------------------------- 5 Note------------------------------------------------------------------8 Attached drawings-------------------------------------------------------8 Electric diagram-------------------------------------------------------- 9 Connection diagram-----------------------------------------------------10 1.1 Safety Instruction After unpacking, the appliance should be checked to see if there is any damage to it. The dishwasher is intended to wash dishes and plates by adults. -
Page 3: Installation Instruction
1.2 Installation Instruction Unpacking 1) Removing the packing accessories, please pay attention that the plastic bag should be out of the reach of children. 2) Open the door of the dishwasher to check the baskets are placed in the proper place (manufactures may fix the baskets by some simple ways for the sake of safety). - Page 4 Installation sketch map of Built-in type Installation steps: 1. leveling the appliance 2. connecting drain hose 3. connecting charging hose 4. electrical connection 5. disassemble the top board 6. Leveling the appliance 7. positioning in the cabinet 8. Fix the top with the board of cabinet Note : When making built-in installation of free-stand dishwasher, after dissemble the top board, the hook of it situated on the upper front corsspiece willbe extruded and needs to be...
-
Page 5: Trial Running
Leveling the appliance Once the appliance is positioned, adjust the feet(screw them in o rout) to adjust the height of the dishwasher, making it level to ensure the proper performance. Charging hose connection 1.Connect the charging hose to a water faucet(with a unicouple).See figure 4. -
Page 6: Chapterⅱ Maintenance
2.1 Foreword Before any repair service, you should check: a) Whether the dishwasher is properly installed according to the installation manual. b) Whether the damaged components have been repaired or not. c) Whether the charging hose and the drain hose are properly installed. d) Whether the dishwasher is level or not. - Page 7 * Flow and pressure of washing pump * The filter is clogged. * Detergent is not released from * Unqualified detergent or the dosage dispenser in the container is not correct. * Heating element is not working * No salt in the softener The dishes are not clean enough after * The nozzle is blocked by food * No rinse agent...
- Page 8 You should clean the filter system ever Take-down filter assembly The filter system is jammed by scran (just for some model) week E4:flooding error Installation is infirm Please install the filter system again The micro-filter is locked The Scran collection is damaged Please replace the Scran collection Odd smell in the dishwasher * Food particles on the tub bottom...
-
Page 9: Note
2.3 Notes 1. Accordi ng to the program requiring, when the dishwasher is heated to a ce rtain temperature, the circuit board will shut off the electric suppl y to the electrothermal element. 2. Aqua-st op devi ce: start up the drain pump and make the dishwasher stop its running. 3.
