PC Control Command Reference

Command Codes
No. Function
01 Video
02 RGB1
03 S-VIDEO
04 Power On
05 Power Off
06 Picture Mute
07 Audio Mute
08 Onscreen Mute
09 Reset
10 D Up
11 D Down
12 D Right
13 D Left
14 D Right Up
15 D Left Up
16 D Right Down
17 D Left Down
18 Freeze
19 Front Floor
20 Front Ceiling
21 Rear Floor
22 Rear Ceiling
23 Auto Start On
24 Auto Start Off
25 Auto Picture On
26 Auto Picture Off
Code Data Description
03H No Same as remote
04H No Same as remote
C6H No Same as remote
08H No Same as remote (See NOTE on page 88.)
14H No Same as remote
47H No Same as remote
45H No
11H No
43H No (Resets immediately after returning ACK)
DEH No Same as remote
DFH No Same as remote
DCH No Same as remote
DDH No Same as remote
21H No Same as remote
22H No Same as remote
23H No Same as remote
24H No Same as remote
91H No Same as remote
33H No
34H No
35H No
36H No
19H No
1AH No
1BH No
1CH No
