Parts List - NEC NP600CM Installation And Assembly Manual

Custom ceiling mount for nec np400, np500, np500w, and np600 projectors
Hide thumbs

Advertisement

Before you start check the parts list to insure all of the parts shown are included.

Parts List

Description
projector mount assembly
A
B
4 mm security allen wrench
C
#10-32 x 3/8" serrated washer head socket pin screw
D
#10-32 x 1/4" socket pin screw
E
flat washer
F
#14 x 2.5 phillips hex head wood screw
G
concrete anchor
AA
adapter plate
BB
M4 x 16 mm serrated socket pin screw
CC
retaining spacer
DD
2 mm allen wrench
NOTE: Actual parts may appear slightly different than illustrated.
B
F
DD
1
Disengage connection block from projector mount assembly (A) by unscrewing captive screw and sliding out
connection block as shown.
CONNECTION BLOCK
Visit the Peerless Web Site at www.peerlessmounts.com
AA
A
3 of 10
Qty. Part #
1 055-2803
1 560-9646
2 520-2151
1 520-2196
C
2 540-1078
2 5S1-015-C04
2 590-0097
E
1 055-2869
3 510-2087
3 590-2009
1 560-1097
BB
CC
CAPTIVE SCREW
For customer care call 1-800-865-2112 or 708-865-8870.
A
D
G
ISSUED: 08-05-08 SHEET #: 056-9008-1
