Installation to Threaded Rod
2
Thread two 1/4-20 hex thin nylon-insert locknuts (not included) on two 1/4-20 threaded rods (not included) to the
desired height of projector mount assembly. Attach projector mount assembly (A) to the two 1/4-20 threaded rods
using two 1/4-20 hex thin nylon-insert locknuts as shown in figure 2.7 or figure 2.8.
1/4-20 THREADED ROD
(NOT INCLUDED)
1/4-20 HEX THIN
NYLON-INSERT
LOCKNUT
(NOT INCLUDED)
fig. 2.7
Visit the Peerless Web Site at www.peerlessmounts.com
A
ARROW
INDICATES
FRONT OF
MOUNT
1/4-20 HEX THIN
NYLON-INSERT
LOCKNUT
(NOT INCLUDED)
1/4-20 HEX THIN
NYLON-INSERT
LOCKNUT
(NOT INCLUDED)
7 of 10
For customer care call 1-800-865-2112 or 708-865-8870.
1/4-20 THREADED ROD
(NOT INCLUDED)
1/4-20 HEX THIN
NYLON-INSERT
LOCKNUT
(NOT INCLUDED)
A
ARROW
INDICATES
FRONT OF
MOUNT
fig. 2.8
ISSUED: 08-05-08 SHEET #: 056-9008-1
