Connecting a DVD Player with HDMI out*

Connecting your DVD player to your LCD monitor will enable you to display DVD video.
Refer to your DVD player user's manual for more information.
Select [HDMI] from the AUDIO INPUT button.

Connect the LCD Monitor to a DVD Player

• Please use an HDMI cable with HDMI logo.
• It may take a moment for the signal to appear.
• PC-DVI signals are not supported.

Connecting a DVD Player with SCART out*

Connecting your DVD player to your LCD monitor will enable you to display SCART.
Connect the LCD Monitor to a DVD Player
• To connect the DVD/HD IN connector (RCA) on the LCD monitor and connect the video (sync) and the Video In connector
(RCA), use an RCA connector cable (sold separately).
Some DVD players may have different connectors such as DVI-D connector.
Select [ON] mode from the "SCART MODE" menu when you use a SCART connector. For mode selection, see "SCART
MODE" on page 28.
The AUDIO IN* 1, 2 and 3 can be used for audio input. To select audio source [IN1], [IN2] or [IN3] press the AUDIO INPUT
button.
To DVD Component video output
*: The product you purchased may not have this feature.
To HDMI output
HDMI connector
English-19
LCD monitor
LCD monitor
