Connections
Before making connections:
*
First turn off the power of all the attached equipment and make connections.
*
Refer to the user manual included with each separate piece of equipment.
Wiring Diagram
DVD player
with HDMI out
Second monitor
Computer (Analog)
DVD player with
component out
Computer (Digital)
English-14
VCR or
Laser Disc Player
DVD player with
SCART OUT
Stereo Amplifier
