ACHTUNG! Gerät vor Feuchtigkeit und Nässe schützen! Vor Öffnen des Gerätes Netzstecker ziehen! LESEN SIE VOR DER ERSTEN INBETRIEBNAHME ZUR EIGENEN SICHERHEIT DIESE BEDIENUNGSANLEITUNG SORGFÄLTIG DURCH! Einführung Wir freuen uns, dass Sie sich für einen FUTURELIGHT SC-240 entschieden haben. Sie haben hiermit ein intelligens, leistungsstarkes und vielseitiges Beleuchtungssystem erworben.
Rückseite: 6 - DMX Ausgang 7 - DMX Eingang 8 - Netzanschluss 9 - Sicherungshalter 10 - Control Board Control Board: 11 - Enter-Taste 12 - Up-Taste 13 - Down-Tasten 14 - Display Sicherheit Sicherheitshinweise ACHTUNG! Seien Sie besonders vorsichtig beim Umgang mit gefährlicher Netzspannung. Bei die- ser Spannung können Sie einen lebensgefährlichen elektrischen Schlag erhalten! Dieses Gerät hat das Werk in sicherheitstechnisch einwandfreiem Zustand verlassen.
Lassen Sie die Netzleitung nicht mit anderen Kabeln in Kontakt kommen! Seien Sie vorsichtig beim Umgang mit Netzleitungen und -anschlüssen. Fassen Sie diese Teile nie mit nassen Händen an! Vergewissern Sie sich, dass die anzuschließende Netzspannung nicht höher ist als auf der Rückseite ange- geben.
Nehmen Sie das Gerät erst in Betrieb, nachdem Sie sich mit seinen Funkionen vertraut gemacht haben. Lassen Sie das Gerät nicht von Personen bedienen, die sich nicht mit dem Gerät auskennen. Wenn Geräte nicht mehr korrekt funktionieren, ist das meist das Ergebnis von unfachmännischer Bedienung! Soll das Gerät transportiert werden, verwenden Sie bitte die Originalverpackung, um Transportschäden zu vermeiden.
Lampenjustierung Schraube A Schraube B Schraube C Der Lampenhalter des Gerätes wird ab Werk justiert. Da sich die zu verwendenden Lampen von Hersteller zu Hersteller unterscheiden, kann es u. U. notwendig sein, die Position des Lampenhalters nachzujustieren. Zünden Sie die Lampe und fokussieren Sie den Lichtstrahl auf einer ebenen Oberfläche (Wand). Zentrieren Sie den "Hot Spot"...
Page 9
Die Aufhängevorrichtungen des Projektors muss so gebaut und bemessen sein, dass sie 1 Stunde lang ohne dauernde schädliche Deformierung das 10-fache der Nutzlast aushalten kann. Die Installation muss immer mit einer zweiten, unabhängigen Aufhängung, z. B. einem geeigneten Fangnetz, erfolgen. Diese zweite Aufhängung muss so beschaffen und angebracht sein, dass im Fehlerfall der Hauptaufhängung kein Teil der Installation herabfallen kann.
Die Belegung der Anschlussleitungen ist wie folgt: Leitung International Braun Außenleiter Blau Neutralleiter Gelb/Grün Schutzleiter Der Schutzleiter muss unbedingt angeschlossen werden! Lichteffekte sollten im Allgemeinen nicht über Dimmerpacks geschaltet werden. LEBENSGEFAHR! Vor der ersten Inbetriebnahme muss die Einrichtung durch einen Sachverständigen geprüft werden! Anschluss an den DMX-512 Controller / Verbindung Projektor - Projektor Achten Sie darauf, dass die Adern der Datenleitung an keiner Stelle miteinander in Kontakt treten.
DMX-Protokoll Funktionen der Steuerkanäle Steuerkanal 1 - Horizontale Spiegelbewegung (Pan) Wenn Sie den Regler verschieben, bewegen Sie den Spiegel horizontal (PAN). Allmähliches Einstellen des Spiegels bei langsamen Schieben des Reglers (0-255, 128-Mitte). Der Spiegel kann an jeder gewünschten Einstellung angehalten werden. Steuerkanal 2 - Vertikale Spiegelbewegung (Tilt) Wenn Sie den Regler verschieben, bewegen Sie den Spiegel vertikal (TILT).
Control Board Das Control Board befindet sich am Projektorkopf und bietet mehrere Möglichkeiten. So lassen sich z. B. die DMX-Startadresse eingeben, ein Testprogramm abspielen oder ein Reset durchführen. Außerdem lassen sich Spezialfunktionen abrufen. Über die Up-/Down-Tasten können Sie sich innerhalb des Menüs bewegen. Auf dem Display erscheinen nacheinander: "001, rPA, rtil, tSt, rES".
Die Gobos können mit einer weichen Bürste gereinigt werden. Reinigen Sie das Innere des Projektors mindestens einmal im Jahr einem Staubsauger oder einer Luftbürste. Die dichroitischen Farbfilter, das Goborad und die Innenlinsen sollten monatlich gereinigt werden. Im Geräteinneren befinden sich außer der Lampe und der Sicherung keine zu wartenden Teile. Wartungs- und Servicearbeiten sind ausschließlich dem autorisierten Fachhandel vorbehalten! Bitte beachten Sie auch die Hinweise unter "Lampeninstallation/Lampenwechsel".
Page 16
SC-240 Scanner User manual Table of contents Introduction ........................17 Features........................17 Description of the fixture ....................17 Safety ..........................18 Safety instructions......................18 Installation ........................20 Fitting/Exchanging the lamp..................20 Beampath ........................21 Rigging.......................... 21 DMX-512 connection / connection between fixtures ............. 22 DMX-Protocol ........................
CAUTION! Keep this device away from rain and moisture! Unplug mains lead before opening the housing! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOU INITIAL START - UP! Introduction Thank you for having chosen a FUTURELIGHT SC-240. You acquired a versatile, powerful and intelligent lighting-effect.
Rearpanel: 6 - DMX Output 7 - DMX Input 8 - Powercord 9 - Fuseholder 10 - Control board Control Board: 11 - Enter/release-button 12 - Up-button 13 - Down-button 14 - Display Safety Safety instructions CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! This device has left our premises in absolutely perfect condition.
Never let the power-cord come into contact with other cables! Handle the power-cord and all connections with the mains with particular caution! Make sure that the available voltage is not higher than stated on the rear panel. Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and the power-cord from time to time.
Installation Fitting/Exchanging the lamp DANGER! Install the lamp with the device switched off only. Unplug from mains before! Screws X and Y To insert the lamp HIT 230 V/150 W open the small cover at the rearpanel (see the drawing) by loosening the 2 Phillips screws X and Y on the cover.
The lampholder is aligned at the factory. Due to differences between lamps, fine adjustment may improve light performance. Strike the lamp and focus the light on a flat surface (wall). Center the hot-spot (the brightest part of the beam) using the 3 adjustment screws "A, B, C”. Turn one screw at a time to drag the hot-spot diagonally across the projected image.
but instead use a professional structural rigger. Improper installation can result in bodily injury and.or damage to property. The projector has to be installed out of the reach of people. If the projector shall be lowered from the ceiling or high joists, professional trussing systems have to be used. The projector must never be fixed swinging freely in the room.
Page 23
the fixture or one fixture with another. Occupation of the XLR-connection: If you are using the recommended FUTURELIGHT-controllers, you can connect the DMX-output of the controller directly with the DMX-input of the first fixture in the DMX-chain. If you wish to connect DMX- controllers with other XLR-outputs, you need to use adapter-cables.
DMX-Protocol Function of the control channels - 16 bit protocol Channel 1 - Horizontal mirror movement (Pan) Push slider up in order to move the mirror horizontally (PAN). Gradual mirror adjustment from one end of the slider to the other (0-255, 128-center).
Channel 4 - Shutter, Strobe, Gobos 0 - 5 Shutter closed 6 - 63 Full open position 64 - 127 Strobe-effect from slow to fast (max. 8 flashes/second) 128 - 132 Closed 133 - 135 Reset of the fixture 136 - 143 Full open position 144 - 151 Closed in reverse position...
Main functions - DMX 512 Address settings The "001" flashes. Use the [ ] and [ ] keys to select required address (001 - 509) and press [ ] to confirm and return to the main menu. - Pan reverse This function allows you to invert the Pan-movement.
- 4 control-channels: Channel 1: Horizontal mirror-movement (Pan) Channel 2: Vertical mirror-movement (Tilt) Channel 3: Colour-wheel Channel 4: Shutter, Strobe, Gobos Housing - Easy access to lamp and main components thanks to large opening cover and the projector‘s modular construction. Temperatures Maximum ambient temperature t : 55°...
Replacing the fuse If the lamp burns out, the fine-wire fuse of the device might fuse, too. Only replace the fuse by a fuse of same type and rating. Before replacing the fuse, unplug mains lead. Procedure: Step 1: Unscrew the fuseholder on the rearpanel with a fitting screwdriver from the housing (anti- clockwise).
Page 29
SC-240 Scanner Mode d'emploi Sommaire Introduction ........................30 Features........................30 Description de l'appareil....................30 Sécurité..........................31 Instructions de sécurité ....................31 Installation ........................33 Installer/remplacer de la lampe ..................33 Cours des rayons......................34 Montage du projecteur ....................34 Connexions au contrôleur DMX-512 / raccord projecteur - projecteur ......36 Protocole DMX.........................
ATTENTION! Protéger de l‘humidité! Débrancher avant toute manipulation! POUR VOTRE PROPRE SÉCURITÉ, VEUILLEZ LIRE CE MODE D‘EMPLOI ATTENTIVEMENT AVANT LA PREMIÈRE MISE EN SERVICE! Introduction Nous vous remerçions et vous félicitons d’avoir choisi un FUTURELIGHT SC-240. Vous êtes en possession d’un effet lumineux puissant, intelligent et aux possibilités multiples.
Ne laissez pas les câbles d'alimentation en contact avec d'autres câbles. Soyez prudent; lorsque vous manipulez les câbles et les connexions, vous êtes soumis à des risques d'électrocutions! Ne manipulez jamais les partys sous tension avec les mains mouillées! Assurez-vous que la tension électrique ne soit pas supérieure à celle indiquée au dos de l’appareil. Mettez le câble d'alimentation seulement dans des prises adaptées.
Si vous deviez transporter l'appareil, utilisez l'emballage d'origine pour éviter tout dommage. Notez que pour des raisons de sécurité, il est interdit d'entreprendre toutes modifications sur l'appareil. Il est interdit de retirer le code barre de l'appareil. Ceci annulerait toute garantie. Si l'appareil est utilisé...
Ajustage de la lampe Vis A Vis B Vis C Le porte-lampe de l’appareil est ajusté à l‘usine. Comme les lampes à utiliser diffèrent d’un fabricant à l’autre, il pourrait devenir nécessaire de procéder à un nouveau ajustage de la position du porte-lampe. Allumez la lampe et focussez le rayon de lumière sur une surface plane (mur).
Page 35
Les dispositifs de suspension du projecteur doivent être construites et conceptionnés de telle manière qu’ils puissent supporter son charge utile de 10 fois pour 1 heure sans déformation permanente nuisible. L’installation doit toujours être effectuée avec une deuxième suspension indépendante, par ex. un filet de capture approprié.
L'occupation des câbles de connection est: Câble International Brun Phase Bleu Neutre Jaune/Vert Terre La terre doit être connecteé! Ne jamais connecter des effets lumineux à un "dimmer pack". DANGER DE MORT! Avant la première mise en marche, l’installation doit être contrôlé par un organisme agrée! Connexions au contrôleur DMX-512 / raccord projecteur - projecteur Faites attention que les câbles n'ont pas de contact entre eux.
Protocole DMX Fonctions des canaux de contrôle Canal de contrôle 1 - Mouvement horizontal (Pan) Les mouvements horizontaux du miroir (PAN) sont contrôles par le régulateur. Ajuster le miroir peu à peu en poussant lentement le régulateur (0-255, 128-center). Vous pouvez arrêter le miroir à la position désirée. Canal de contrôle 2 - Mouvement vertical (Tilt) Les mouvements verticaux du miroir (TILT) sont contrôles par le régulateur.
Fonctions principales - DMX 512 Codage de l'adresse initiale: Le caractère "001" clignote. Pressez les touches Up/Down pour sélectioner l'adresse désirée (001-509). Pressez la touche Enter pour confirmer la séléction. - Pan reverse: Cette fonction permet d'invertir le mouvement PAN. Pressez les touches Up/Down pour sélectioner "ON" pour activer cette fonction ou "OFF"...
Canal de contrôle 1 - Mouvement horizontal (Pan) Canal de contrôle 2 - Mouvement vertical (Tilt) Canal de contrôle 3 - Roue de couleurs Canal de contrôle 4 - Shutter, Strobe, Gobos Témperatures Maximale température ambiante t : 55° C Maximale température du boîtier (à...
Avant le remplacement du fusible débrancher l'appareil. Procédure: Pas 1: Dévissez le porte-fusible (dans le sens inverse des aiguilles d'une montre) au dos de l'appareil avec un tournevis et le retirer du boîtier. Pas 2: Retirez le fusible défectueux du porte-fusible. Pas 3: Installez le nouveau fusible au porte-fusible.
Page 42
SC-240 Scanner Manual del usuario Contenido Introducción ........................43 Características ......................43 Descripción de las partes....................43 Seguridad ........................44 Instrucciones de seguridad ................... 44 Instrucciones de manejo ....................45 Instalación ........................46 Instalación/reemplazar de la lámpara ................46 Marcha de los rayos...................... 47 Conexión al controlador DMX / conexión proyector - proyector........
¡PRECAUCION! ¡Evite el contacto de este aparato con la lluvia y la humedad! ¡Desconectar de la corriente antes de abrir la caja! ¡POR SU PROPIA SEGURIDAD, POR FAVOR LEA ESTE MANUAL DEL USUARIO DETENIDAMENTE ANTES DE LA CONEXIÓN INICIAL! Introducción Gracias por haber elegido un FUTURELIGHT SC-240.
¡No deje que el cable de alimentación entre en contacto con otros cables! ¡Maneje los cables de corriente alterna y las conexiones de corriente alterna con mucha precaución! Asegúrese de que la tensión de alimentación no es mayor que la indicada en el panel trasero. Preste atención que el cable de alimentación no esté...
¡Por favor tenga en cuenta que por razones de seguridad las modificaciones no autorizadas del aparato están prohibidas! El código de barras de serie no debe ser quitado del aparato, en caso de que esto ocurra la garantía ya no es válida.
Ajuste de la lámpara Tornillo A Tornillo B Tornillo C El sistema de portalámparas está ajustado en la fábrica. Como las lámparas de los fabricantes diferentes son diferentes, puede ser necesario de reajustar la posición del sistema de portalámparas. Enciende la lámpara y foca el rayo en una superficie plana (pared). Centre el "Hot Spot" (la parte más brilliante del rayo) en tornear los 3 tornillos "A, B, C".
Page 48
La suspensión del proyector debe ser fabricado de una manera que puede llevar 10 vezes la carga por una hora sin sufrir deformaciones dañosas permanentes. La instalación siempre debe ser efectuada con una segunda suspensión independiente, por ejemplo una red de anclaje apropriada.
La tierra debe ser conectada. En general los efectos de luz no deben ser conectados a dimming-packs. ¡PELIGRO DE MUERTE! ¡Antes de la primera puesta en marcha, la instalación debe ser inspeccionada por un perito! Conexión al controlador DMX / conexión proyector - proyector Asegúrese de que los conductores del cable de datos no hagan contacto entre si.
Protocolo DMX Fonctions de los canales de control Canal 1: Movimiento horizontal (Pan) Establezca los ajustes para mover el espejo horizontalmente. Los movimientos graduales del espejo mediante el ajuste lento de los valores DMX (0-255; 128 = centro). Canal 2 - Movimiento vertical (Tilt) Establezca los ajustes para mover el espejo verticalmente (TILT).
Confirme la selección deseada con la tecla Enter. Las funciones son descritas en la parte siguiente. Funciones principales - Ajustar la dirección de comienzo DMX-512: "001" parpadea. Pulse las teclas Up/Down para ajustar la dirección de comienzo (001-509) deseada. Pulse la tecla Enter para confirmar.
Canal 3 - Rueda de colores Canal 4 - Shutter, efecto flash, gobos Caja Aces fácil a la lámpara y a los componentes mas importantes gracias a la apertura grande y la construcción modular del proyector. Témperaturas Máxima temperatura ambiente t : 55°...
Reemplazar el fusible Si la lámpara se funde, el fino cable del fusible del aparato podría fundirse también. Reemplazar el fusible por un fusible del mismo tipo. Antes de reemplazar el fusible desenchufar el cable de la red. Procedimiento: Paso 1: Desatornillar de la caja el portafusibles del panel trasero con un destornillador adecuado (en dirección contraria a las agujas del reloj).
