PARTS NAME

MAIN UNIT AND CONTROL PANEL
Control Panel
ION SHOWER button (indicator light-green)
PLASMACLUSTER ION (
Light on: ON; Light off: OFF.
Back View
House Dust
Monitoring
Dust
DUST SENSOR
Main Unit
Clean
Dirty
E - 4
FAN SPEED button (indicator lights-green)
E-9
DUST
E-9
) ON/OFF button (indicator light-blue)
Air Outlet
Handle
Power Plug Power Cord
CHILD LOCK button (indicator light-green) E-10
PLASMACLUSTER ION
E-10
Light Control BRIGHT/DIM/OFF button
FILTER RESET button (indicator light-orange)
Front View
HEPA Filter
Active Carbon
Deodorizing Filter
Rear Panel
(Pre-filter)
The device starts when the
button with is pressed.
POWER ON/OFF button E-8
ODOR
OFF TIMER button (indicator lights-green)
E-10
E-12
ODOR SENSOR
House dust monitoring and odor
monitoring work together to show the air
pollution level in a room. However, the
Dust Sensor and the Odor Sensor monitor
dust pollution and odor emission
respectively, so their indicator lights may
not change simultaneously.
E-11
Odor
Monitoring
Odor
Weak
Strong
E - 5
