Acquiring, Analyzing, And Presenting; Table 5-4. Ni-Daqmx Thermocouple Measurement Properties - National Instruments Module SCXI-1503 User Manual

Property
Analog Input»Temperature»
Thermocouple»Type
Analog Input»Temperature»
Thermocouple»CJC Source
Analog Input»Temperature»
Thermocouple»CJC Value
Analog Input»Temperature»
Thermocouple»CJC Channel
This is not a complete list of NI-DAQmx properties and does not include every
Note
property you may need to configure your application. It is a representative sample of
important properties to configure for voltage measurements. For a complete list of
NI-DAQmx properties and more information about NI-DAQmx properties, refer to your
ADE help file.
© National Instruments Corporation

Table 5-4. NI-DAQmx Thermocouple Measurement Properties

Short Name
AI.Thermcpl.Type
AI.Thermcpl.CJCSrc
AI.Thermcpl.CJCVal
AI.Thermcpl.CJCChan

Acquiring, Analyzing, and Presenting

After configuring the task and channels, you can start the acquisition, read
measurements, analyze the data returned, and display it according to the
needs of your application. Typical methods of analysis include digital
filtering, averaging data, performing harmonic analysis, applying a custom
scale, or adjusting measurements mathematically.
NI provides powerful analysis toolsets for each NI ADE to help you
perform advanced analysis on the data without requiring you to have a
programming background. After you acquire the data and perform any
required analysis, it is useful to display the data in a graphical form or log
it to a file. NI ADEs provide easy-to-use tools for graphical display, such as
Description
Specifies the type of
thermocouple
connected to the
channel.
Indicates the source of
cold-junction
compensation.
Specifies the
temperature of the
cold-junction if the
CJC source is constant
value.
Indicates the channel
that acquires the
temperature of the
cold junction if CJC is
channel.
5-7
Chapter 5 Using the SCXI-1503
DAQ
Assistant
Accessible
Yes
Yes
Yes
Yes
