Figure; Using The Scxi-1503; Developing Your Application In Ni-Daqmx; Typical Program Flowchart - National Instruments Module SCXI-1503 User Manual

National instruments module user's manual

Hide thumbs Also See for Module SCXI-1503:

Table of Contents

Note

If you are not using an NI ADE, using an NI ADE prior to version 8.1, or are using

an unlicensed copy of an NI ADE, additional dialog boxes from the NI License Manager

appear allowing you to create a task or global channel in unlicensed mode. These messages

continue to appear until you install version 8.1 or later of an NI ADE.

This chapter makes suggestions for developing your application and

provides basic information regarding calibration.

This section describes how to configure and use NI-DAQmx to control the

SCXI-1503 in LabVIEW, LabWindows/CVI, and Measurement Studio.

These ADEs provide greater flexibility and access to more settings than

MAX, but you can use ADEs in conjunction with MAX to quickly create a

customized application.

Figure 5-1 shows a typical program voltage measurement flowchart for

creating a task to configure channels, take a measurement, analyze the data,

present the data, stop the measurement, and clear the task.

5-1

SCXI-1503 User Manual
