Table 5-1. NI-DAQmx Voltage Measurement Properties (Continued)
Property
Analog Input»General
Properties»Advanced»
Gain and Offset»Gain
Value
Analog Input»General
Properties»Advanced»
High Accuracy Settings»
Auto Zero Mode
Analog Input»General
Properties»Advanced»
Input Configuration»
Coupling
Property
Analog Input»Temperature»
RTD»Type
Analog Input»Temperature»
RTD»R0
© National Instruments Corporation
Short Name
AI.Gain
AI.AutoZeroMode
AI.Coupling

Table 5-2. NI-DAQmx RTD Measurement Properties

Short Name
AI.RTD.Type
AI.RTD.R0
Description
Specifies a gain factor to apply
to the signal conditioning
portion of the channel. The
SCXI-1503 supports 1 or 100.
Specifies when to measure
ground. NI-DAQmx subtracts
the measured ground voltage
from every sample. The
SCXI-1503 supports None or
Once.
Specifies the input coupling of
the channel. The SCXI-1503
supports DC and GND
coupling.
Description
Specifies the type of
RTD connected to the
channel.
Specifies the
resistance in ohms of
the sensor at 0 C.
5-5
Chapter 5 Using the SCXI-1503
DAQ
Assistant
Accessible
No
Yes
No
DAQ
Assistant
Accessible
Yes
Yes
SCXI-1503 User Manual
