1.3 Remote control

◆ This remote control use AAA battery, the definition as following:
Button
Power Button
Record Button
-/-- /0-9 Digital Button
Fn1 Button
Multi Button
Next Button
SEQ
Audio
Switch
Direction button
Enter Button
Menu Button
Exit Button
Focus/IRIS/Zoom/PTZ
Preset Button
Cruise Button
Track Button
Wiper Button
Light Button
Clear Button
Fn2 Button
Info Button
Snap Button
Search Button
Cut Button
Backup Button
Zoom Button
PIP Button
◆ Switch Remote Control ID
Take remote control and point to DVR then continuously press "8","8","ID(0-65535)","Enter".
＊The ID must be the same on DVR.
＊For example: If ID=1 , please take remote control and point to DVR then press 8,8,1,Enter.
(Press 8,8,1,Enter will enable the IR function, if you want to avoid other remote controller affect the
DVR, you can disable the IR function by press 8,8,2,Enter)
Remote Controller
Switch off—to stop DVR. Use it before turning off the power
To record manually
Input number or choose camera
Unavailable temporarily
To choose multi screen display mode
To switch the live image
To enter into auto dwell mode
To enable audio output in live mode
To switch the output between BNC and VGA
To move cursor in setup or pan/title PTZ
To confirm the choice or setup
To enter into menu
To exit the current interface
To control PTZ camera. Move camera /zoom /IRIS /Focus
To enter into preset setting in PTZ mode
To enter into cruise setting in PTZ mode
To enter into track setting in PTZ mode
To enable wiper function in PTZ mode
To enable light function in PTZ mode
To return to the previous interface
Unavailable temporarily
Get information about DVR like firmware version, HDD information
To Control playback. Play/Pause/Stop/Previous Section/Next
Section/Rewind/Fast Forward
To take snapshots manually
To enter into search mode
To set the start/end time for backup in playback mode
To enter into backup mode
To zoom in the images
To enter into picture in picture setting mode
Function
