Hi Sharp HS-DH8000 User Manual

Combo
Hide thumbs

Advertisement

Quick Links

Download this manual
Thank you for purchasing our product.
Please read this User's Manual before
using the
product.
Change without Notice
Combo DVR
User's Manual
User please operate according to the DVR model that you purchased

Advertisement

loading
Need help?

Need help?

Do you have a question about the HS-DH8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hi Sharp HS-DH8000

Summary of Contents for Hi Sharp HS-DH8000

  • Page 1 Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without Notice Combo DVR User’s Manual User please operate according to the DVR model that you purchased...

  • Page 2: Safety Precautions

    Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be sufficient magnitude to constitute risk of electrical shock to persons.

  • Page 3: About This Document

    About this document Before installing stand alone DVR, be sure to thoroughly review and follow the instructions in this Users Manual. Pay particular attention to the parts that are marked NOTICE. Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.
  • Page 4 FCC Statement: WARNING This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received including interference that may cause undesired operation."...

  • Page 5: Front Panel

    FRONT PANEL : DVR and AV mode select 1. SOURCE : OSD setup 2. MENU : OSD exit 3. ESC : Menu enter / Channel select 4. ENTER : Playback mode 5. PLAY : Direction button UP / Playback stop button 6.

  • Page 6: Rear Panel

    REAR PANEL ( 1 ~ 4 Channel ) ( 1 ~ 8 Channel ) Connector Define EXT AV IN External video in RCA type AV OUT External video out RCA type Network connection RJ-45 type CAM AUDIO IN Audio input RCA and Earphone type CAM 1 ~ CAM 4(8) Camera connection...
  • Page 7 Live mode Playback mode Indicator: Live: Live mode Video loss Recording Overwrite Motion Alarm Relay (Motion / Alarm) Channel sequence Keypad lock * 111111 is the default password Playback: Forward Reverse Pause...
  • Page 8 Mouse Control Screen display 1. Double-click of the left button on desired camera ○ to full channel 2. Double-click of the left button on desired camera ○ to quad screen ○ ○ Menu display 1. One-click of the right button to menu OSD ○...
  • Page 9 Main MENU – Camera Set Right adjustment of each element will increase picture quarterly displayed. We recommend you to adjust each element of cameras and monitor to be connected to the DVR unit. Main MENU – Camera Set – Display: Channel mask on or off Main MENU –...
  • Page 10 Main Menu – Record Set Record Set – Schedule Record Frame rate Record Set – Motion Record Frame rate Record Set – Alarm Record Frame rate Record Set – Record Quality: High / Normal / Low Record Set – Event Rec Duration: 5 / 10 / 15 / 20 / 25 / 30 Record Set –...
  • Page 11 Notice: 1. Each channel has own frame rate adjustment of each recording mode. 2. In 24 hours, user can adjust each channel frame rate of different record mode. Such as schedule, motion detection, and alarm record more. 3. Press button to change different of record modes. Schedule record mode Motion record mode Alarm record mode...
  • Page 12 Record Time Table: 80GB HD Record Quality: Low. Average: 5 KB; REC FPS REC Hour Record Quality: Normal. Average 10 KB; REC FPS REC Hour Record Quality: High. Average 20 KB; REC FPS REC Hour Actual recording time is base on live environment. This table is only for reference. 20 K x 30 (frame rate) x 60 (mins) x 60 (secs) = 2160000 K = 2160 M / hr 2160 M / hr x 24 = 51840000 K = 51840 M = 51.84 G / (1 Day) Please format hard disk before starting recording after all the HDD installation...
  • Page 13 Main Menu – Alarm Detection Alarm Signal type depends on Alarm Sensor polarity define on NO (N/Open) or NC (N/Close) mode. Alarm POP UP: Event channel jumps to full screen when alarm triggered. Quad screen with the alarm symbol if more than two cameras triggered. Door closed Door open Relay: NO + COM or NC + COM...
  • Page 14 Main Menu – Motion Detection Main Menu – Motion Detection – Motion Area Detected area cursor Alarm POP UP: Alarm channel jumps to full screen when motion triggered. Quad screen with the alarm symbol if more than two cameras triggered. Main Menu –...
  • Page 15 Main Menu – Video Setup Video Adjustment Main Menu – Audio Set - If microphone, audio line in or any how, user please set the audio record mode to on and also adjust volume input or output to right sound effects. - Mute means live audio is turn on or quiet.
  • Page 16 Main Menu – System Set – Hard Disk Setup – Format HDD – Password HDD was formatted successful. - Before hard disk format, user needs to put the right password. The password is same as unlock which is default 111111. - Please set HDD to Master if only one installed.
  • Page 17 Menu Protection: On / Off. User needs to login password before enter to menu. Auto Key Lock: After 1 ~ 60 seconds system automatically key lock which means before operate DVR user needs to unlock. Main Menu – System Set – Time Set Select time zone and auto time synchronization with NTP server.
  • Page 18 Main Menu – System Set – BUZZER SETUP Main Menu – System Set – Network Settings Network Settings – Local IP Network Settings – Local IP – STATIC Network Settings – Local IP – DHCP Select static IP address / Gateway / Net Mask Auto IP detected under IP sharing or router Main Menu –...
  • Page 19 Main Menu – System Set – Network – PPPOE ID If the DVR is under a network system, suggest enable Main Menu – System Set – Time Set NTP server to get a network request automatically. Main Menu – System Set – Network – PPPOE – Password Input PPPoE account and password.
  • Page 20 Ex: Enter in www.dyndns.com to apply a free account and host name. Click Create Account to make a new ID name. Fill in all the personal information, password, email requested; please go to user’s email account to active your new account. Return to DynDNS website; click Account to long in page. cv1000 123456 Type your applied Username and Password...
  • Page 21 Logged In page Click “My Services” icon Click Add Host Services: Click “Add Host Service”...
  • Page 22 Add static DNS Host: Select Static DNS: add Static DNS Host Type a Hostname user decided. No useful df6020 Add Host Ex: Create a new df6020 host name, after add a new host name; DynDNS page shows a confirm message page.
  • Page 23 Enable : DNS Server: From ISP DDNS Server: DynDNS. HOST Name: Insert host name User Name: Insert DynDNS username Password: Insert DynDNS password On IE browser blank bar, type df6020.dyndns.org; and then user can get on line. DNS address is required. (Please ask local ISP). DNS only works under DDNS mode. Network stream speed depends on the locality bandwidth.
  • Page 24 Main Menu – System Set – RS-485 Main Menu – System Set – Pan/Tilt Device Control: Keypad, mouse * Mouse control: press ESC to PTZ mode, press AUTO button, and then once-click left button of mouse to control PTZ movement. Press quad button + number 1 ~ 4 (1 ~ 8) button to set presets, press AUDIO + 1 ~ 4 ( 1~ 8) to call preset.
  • Page 25 Main Menu – System Set – F/W Upgrade Stop all hard disk working before update, select F/W upgrade and then press ENTER to search firmware. Press PLAY to start version update. DVR auto reboot after version update.
  • Page 26 Main Menu – System Set – Load Active-X Control Stop all hard disk working before load Active-X control 1. Before DVR IE connection, please download the ActiveX to DVR hard disk from CD-ROM, and then you can view DVR image via internet any PC. Steps: CD disk ActiveX USB pan drive...
  • Page 27 Main Menu – Search Main Menu – Search – TIME LIST Main Menu – Search – Event List Main Menu – Search – Time Search Press ENTER to select data and time. Direction left and right button to move value item. ENTER or + / - button to change value.
  • Page 28 Main Menu – Search – Time Search: After data and time select, go to Search and then press ENTER to start playback. Playing Forward speed: x 2 / x 3 / x 4 (Direction right button) Reverse speed: x 8 / x 16 / x 32 (Direction left button) Press STOP to search list, press ESC to live mode.
  • Page 29 Backup mode: Before backup, USB pan driver is required. Back up file size can not exceed 1GB, when system reads USB (thumb driver only) device, the system will stop recording about 2 seconds Mode 1: On live mode, press backup button to file backup page. Total hard disk data time range Select start and end time of backup After select backup time, apply to count...
  • Page 30 After a while, all backup information display on screen, user now can press backup button to start file backup. Data is writing to USB pan drive, users please wait until backup complete. Press menu button to quit USB page. Mode 2: Press play button to start playback, the playback beginning time is the last one hour record.
  • Page 31 USB compatible(Max. 4G) ADATA / Transcend / San Disk / Kingston Main Menu – Language – English or Chinese Main Menu – Exit User needs to save changes if any function value has changed. And then exit menu.
  • Page 32 Net viewer (4/8Channel viewer) Viewer function: 1. Backup file player 2. Network viewer 3. Connection DVR control via viewer:* 4. DVR screen: Quad, Camera 1 ~ 4 (Camera 1~8) full screen / Key lock / Channel auto sequence. Audio ON : stream speed – not good. OFF : stream speed – good 5.
  • Page 33 Net Viewer configures: Player Switch to backup file play mode NetViewer Switch to DVR network viewer Disconnect Network log out and connect canceled Audio Audio volume adjust (PC site) Local Recording Viewing image record Always On Top Player or viewer always on top even other data folders open Full Screen Viewer change to full screen Maximize...
  • Page 34 File Player: Click browser to open file which you saved Player button Open \ Fast Backward \ Play Reverse \ Previous Frame \ Pause \ Next Frame \ Play\ Fast Forward \ Still Capture\ Split1 \ Split 4 \ Split 9 1.
  • Page 35 Player Configure: Player Switch to backup file play mode Netviewer Switch to DVR network viewer Open File Open the backup file which saved in any path Open Disk Open the DVR hard disk which is installed to PC IDE slot Export Backup file to AVI files transform (Video + Audio).
  • Page 36 Options Always on top: Player always on top even other data folders opened Show time: Show the PC time of when user start recording backup file On Screen display date/time (Show time) format: Please select the date format you want. %Y/%m/%d %H:%M:%S: 2008/04/28 15:32:29 %y/%m/%d %H:%M:%S:...
  • Page 37 VVF file export to AVI Click audio on if the image includes audio. Browse the file source Browse a path for file output File preview Select a compression codec Percentage of the export AVI progress Users please wait until file export completed.
  • Page 38 PTZ Control mode Channel / Direction Near / Far, Call OSD, Menu confirm Select camera channel Set presets (1~8 Channel ) (1~4 Channel) Zoom -- / + : Lens, Near / Far Menu: Call PTZ OSD Enter: OSD value confirm Channel: Select PTZ channel Preset: Preset setup Select preset 1 ~ 4 ( Preset 1~8) , and then click SET to save.
  • Page 39 IE browser: IE control button is same as DVR keypad. 1. Before DVR IE connection, please download the ActiveX to DVR hard disk from CD-ROM, and then you can view DVR image via internet any PC. Steps: CD disk ActiveX USB pan drive DVR (with hard disk) USB Menu - System Set –...
  • Page 40 LCD OSD Brightness LCD Screen brightness Contrast LCD Screen contrast Saturation LCD Screen saturation Tint LCD Screen tint Sharpness LCD Screen sharpness Color Temperature H Position Horizontal position V Position Vertical position User please set up the monitor setting according to one's vision hobbit...
  • Page 41 Trouble shooting: Hardware LCD MAIN BOARD INVERTER POWER SUPPL IO BOARD DVR MAIN BOARD 1. After power on the system, if the FAN doesn’t work or front panel LED light off, the root cause is POWER SUPPLY error. 2. The front panel LED light is normal and the voice adjustment is normal but the screen can not display, the root cause is INVERTER error.
  • Page 42 Software: 1. After install the Hard Disk, the Hard Disk can't read, why? The Hard Disk JUMPER setting error, please check the Hard Disk JUMPER, it should be setup with MASTER. 2. The CCD display with Black/White mode, why? The root cause is system auto switch error, please check the channel 1, it should be connected with CCD.
