Hi Sharp ATR620H User Manual page 11

Click right mouse or press ESC button on the front panel, the control bar will display on the screen, refer to
Fig 3-1:
Full channel switch, camera 1 ~ 5, camera 1 ~ 12, or camera 1~24
Click Menu button, the interface will pop-up as Fig. 3-2; press MENU button on the front panel or
operate with remote controller also can display the main menu.
Main OSD
3 Main menu setup guide
1 Single
2 Multi
3 E-Zoom
4 Audio
5 PTZ
6 Record
7 Playback
8 Main Menu
9 Dwell
Fig. 3-1 main menu toolbar
Fig. 3-2 system setup
11
Full channel
4ch:1/5, 8ch:1/4/9/12,
16ch:1/4/9/16/25
Live/playback digital zoomx2
Audio channel setup and volume
Into PTZ control mode
Manual record
Playback the nearest file
Into main OSD
Channel sequence
