Thank you for purchasing our product.
Please read this User's Manual before
using the
product.
Change without Notice

4 Channel Digital Video Recorder

User's Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-DVR045 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hi Sharp HS-DVR045

Summary of Contents for Hi Sharp HS-DVR045

  • Page 1: Channel Digital Video Recorder

    Thank you for purchasing our product. Please read this User’s Manual before using the product. Change without Notice 4 Channel Digital Video Recorder User’s Manual...

  • Page 2: Safety Precautions

    Safety Precautions CAUTION RISK OF ELECTRICAL SHOCK. DO NOT OPEN ! CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This label may appear on the bottom of the unit due to space limitations. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be...
  • Page 3 About this document Before installing stand alone DVR, be sure to thoroughly review and follow the instructions in this Users Manual. Pay particular attention to the parts that are marked NOTICE. Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.

  • Page 4: Table Of Contents

    Content Table Safety Precautions………………………………………………….……………………………………….. 2 Content Table……….………………………………………………………………………………………… 4 1. Hardware……………………………………………………………………………………………………… 4 2. Unit Description of Front Panel…………………………………………………………………………….. 5 3. Unit Description of Rear Panel……………………………………………………………………………… 6 4. Installation……………………..……………………………………………………………………………… 7 1. Procedure………………………..……………………………………………………………….… 7 2. Picture……………………………………………….……………………………………………… 9 3. Playback………..………..……………………………………………….………………………… 11 5. Function Setup…………………..………………………………………………………….………………… 13 1.

  • Page 5: Unit Description Of Front Panel

    Unit Description of Front Panel 1 ~ 4 camera channel full screen choose button / 0 ~ 9 password input 4 quad split screen display button Picture in picture button Picture 2x2 zoom in ZOOM Picture on picture button Picture Freeze FREEZE Channel auto sequence button AUTO...

  • Page 6: Unit Description Of Rear Panel

    Unit Description of Rear Panel Power code in 12V/5A, power switcher Monitor out Camera 1 ~ 4 in and out VGA output. PC monitor connector. VG A Audio channel input x 4 and (OPTIONAL) output x 2 RS 485 A + / B – Network connector.

  • Page 7: Installation

    Installation Procedure 1) Camera Connection Connect the camera to the CAMERA INPUT LEVEL VIDEO MONITOR on the Rear Panel of the 4 CH DVR. VIDEO LENS AC24V/DC12 Rear part of CAMERA 2) Monitor Connection (Composite Connection Method) Connect the monitor to the MONITOR OUT on the Rear Panel of the 4 CH DVR.
  • Page 8 4) HDD internal connection How to connect single HDD How to connect 2 HDD I/O BOARD I/O BOARD MASTER HDD1 MASTER MAIN BOARD MAIN BOARD SLAVE HDD2 Set the drive jumpers as specified by hard disk drive manufacturer. Set the drive jumpers as specified by hard disk drive manufacturer. Make sure the HDD is MASTER.

  • Page 9: Picture

    Picture Full screen or quarterly split screen display Press quad button to display 4 quarterly split screen. Press numeric 1 / 2 / 3 / 4 buttons to display the desired camera image in full screen. 1.) FREEZE Mode 1. In live and the quad mode press (FREEZE) button to freeze image.
  • Page 10 4.1) POP (PICTURE ON PICTURE) 1.) Press POP button to display pictures on screen. Press (AUTO) button begins to sub-screen auto sequence. CAMERA 2 CAMERA 3 CAMERA1 CAMERA 4 5.) Alarm Sensor Recording See the alarm recording setup page 6.) Scheduled Recording See the scheduled recording setup page 7.) Motion detection Recording See the motion detection recording setup page...

  • Page 11: Playback

    Playback 1. Playback Mode 1) Press button to begin playback. PLAY (System will playback the previous time recording.) 2. T-SRH button PLAY SETUP PAGE T-SRH: Playback by time search. EVENT LIST Press T-SRH button to active playback function. TIME LIST Press direction button FIRST: xxxx/xx/xx xx:xx:xx...
  • Page 12 2) TIME LIST (Playback image by Time-Search): Recorded images list (by hours) TIME SEARCH LIST PAGE FIRST: xxxx/xx/xx xx:xx:xx (The FIRST date and time recording display). LAST: xxxx/xx/xx xx:xx:xx (The final date and time recording display). GOTO: xxxx/xx/xx xx:xx:xx (year / month / day, Hour / Minute / Second) Press direction button Left/Right to change date and time values position.

  • Page 13: Function Setup

    FUNCTION SETUP LOGIN MENU Press button to enter into menu. You could do the system function setup in MENU. Password enter window pop-up: Default password (Account-Admin): 00000 LOGIN DVR SYSTEM Default password (Account-User): 11111 Default password (Account-GUEST): 22222 PASSWORD xxxxx Press numeric (0 ~ 9)button to choose password.

  • Page 14: Basic Operation

    Press MENU button to enter MAIN SETUP PAGE. Basic Operation MAIN SETUP PAGE 1. HDD INFORMATION 2. DATE-TIME SETUP 3. DISPLAY SETUP 4. CAMERA SETUP 5. BUZZER&RELAY SETUP 6. SYSTEM SETUP 7. PTZ SETUP 8. ADVANCED SETUP Use direction button up/down button to select setup item.
  • Page 15 1. HDD INFORMATION MAIN SETUP PAGE SIZE USED BRAND 1. HDD INFORMATION 080GB OW SEGATE 2. DATE-TIME SETUP 3. DISPLAY SETUP 4. CAMERA SETUP STATUS: USE 5. BUZZER&RELAY SETUP START: xxxx(Y)/xx(M)/xx(D) xx:xx:xx(H:M:S) 6. SYSTEM SETUP END: xxxx(Y)/xx(M)/xx(D) xx:xx:xx(H:M:S) 7. PTZ SETUP 8.
  • Page 16 2. DATE-TIME SETUP MAIN SETUP PAGE DATE-TIME SETUP PAGE 1. HDD INFORMATION 1. HOUR TYPE: 2. DATE-TIME SETUP 2. DATE TYPE 3. DISPLAY SETUP 3. DATE 2000 / 00 / 00 4. CAMERA SETUP 4. TIME 5. BUZZER&RELAY SETUP 5. DATE-TIME POSITION SETUP 6.
  • Page 17 3. DISPLAY SETUP DISPLAY SETUP PAGE MAIN SETUP PAGE 1. DATE-TIME 1. HDD INFORMATION 2. CAMERA TITLE 2. DATE-TIME SETUP 3. PB DATE-TIME 3. DISPLAY SETUP 4. PB CAMERA TITLE 4. CAMERA SETUP 5. DVR STATUS 5. BUZZER&RELAY SETUP 6. BORDER SET WHITE 6.
  • Page 18 4. CAMERA SETUP MAIN SETUP PAGE CAMERA SETUP PAGE 1. HDD INFORMATION 1. COLOR SETUP 2. DATE-TIME SETUP 2. TITLE SETUP 3. DISPLAY SETUP 3. MARK&MIRROR SETUP 4. CAMERA SETUP 5. BUZZER&RELAY SETUP MENU, ESC: EXIT, ENTER: RUN 6. SYSTEM SETUP 7.
  • Page 19 (2.) TITLE SETUP: Input TITLE of each camera. 14 characters can be input. CAMERA TITLE SETUP PAGE CH1 (CAM01 ) CAMERA SETUP CH2 (CAM02 ) 1. COLOR SETUP CH3 (CAM03 ) 2. TITLE SETUP CH4 (CAM04 ) 3. MARK&MIRROR SETUP MENU, ESC: EXIT: : MODIFY Press direction button up/down/left/right to choose items and position.
  • Page 20 3.)MASK&MIRROR SETUP MASK&MIRROR SETUP PAGE **MASK FUNCTION CAMERA SETUP 1. CH 1: 1. COLOR SETUP 2. CH 2: 2. TITLE SETUP 3. CH 3: 4. CH 4: 3. MARK&MIRROR SETUP **MIRROR FUNCTION OFF 1. CH 1: 2. CH 2: 3. CH 3: 4.
  • Page 21 5. BUZZER&RELAY SETUP BUZZER&RELAY SETUP PAGE MAIN SETUP PAGE BUTTON MUTE 1. HDD INFORMATION **SYSTEM BUZZER 2. DATE-TIME SETUP 1. ALARM BUZZER 3. DISPLAY SETUP 2. MOTION BUZZER 4. CAMERA SETUP 3. VLOSS BUZZER 5. BUZZER&RELAY SETUP **SYSTEM RELAY N.O. 6.
  • Page 22 6. SYSTEM SETUP MAIN SETUP PAGE SYSTEM SETUP 1. HDD INFORMATION 1. DWELL INTERVAL 010SEC 2. DATE-TIME SETUP 2. LANGUAGE ENGLISH 3. DISPLAY SETUP 3. RS-485 ID 4. CAMERA SETUP 4. RS-485 BAUDRATE 9600 5. BUZZER&RELAY SETUP 5. LIVE AUDIO 6.
  • Page 23 7. PTZ SETUP MAIN SETUP PAGE PTZ SETUP PAGE 1. HDD INFORMATION **PROTOCOL P-TYPE 2. DATE-TIME SETUP **BAUDRATE 2400 3. DISPLAY SETUP **CHANNEL NUMBER CH01 4. CAMERA SETUP PTZ NUMBER 5. BUZZER&RELAY SETUP LINE SCAN 6. SYSTEM SETUP TEST 7. PTZ SETUP 8.
  • Page 24 8. ADVANCED SETUP ADVANCED SETUP PAGE MAIN SETUP PAGE 1. ALARM SETUP 1. HDD INFORMATION 2. MOTION SETUP 2. DATE-TIME SETUP 3. RECORD SETUP 3. DISPLAY SETUP 4. EVENT RECORD 4. CAMERA SETUP 5. EVENT 5. BUZZER&RELAY SETUP 6. PASSWORD SETUP 6.
  • Page 25 2. MOTION SETUP ADVANCED SETUP PAGE MOTION SETUP 1. ALARM SETUP **MOTION FUNCTION **CHANNEL NUMBER CH01 2. MOTION SETUP 3. RECORD SETUP 1. FRAME NUMBER 4. EVENT RECORD 2. SENSITIVITY 5. EVENT 3. MOTION ACTIVE 6. PASSWORD SETUP 4.MOTION AREA SETUP 7.
  • Page 26 > MOTION AREA SETUP < (Press LOCK button for help) ****CH01 AREA MASK**** Press 1/2/3/4 numeric to select channel. : WALK ON MODE Press value change button to change mode. 1.2.3.4: SELECT CHANNEL : MOVE SURSOR Press direction button to move cursor. Press ENTER button to on mask function or off.
  • Page 27 3. RECORD SETUP RECORD SETUP 1. RECORD TYPE FIELD ADVANCED SETUP PAGE 2. HDD FULL OVERWRITE 1. ALARM SETUP 3. RECORD SCHEDULE 2. MOTION SETUP 4. RECORD START 3. RECORD SETUP 5. RESOLUTION 4. EVENT RECORD 6. AUDIO RECORD 5. EVENT 7.
  • Page 28 >SCHEDULE SETUP< RECORD SETUP 1. RECORD TYPE FIELD Press direction buttons to choose 2. HDD FULL OVERWRITE SCHEDULE items. 3. RECORD SCHEDULE 4. RECORD START Press values change button to increase or reduce 5. RESOLUTION 6. AUDIO RECORD Factory default is everyday all schedules time on 7.
  • Page 29 30MIN SCHEDULE SETUP CURSOR STEP 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 00:30 01:30 02:30 03:30 04:30 05:30 06:30 07:30 08:30 09:30 10:30 11:30 12:30 13:30 14:30 15:30 16:30 17:30 18:30 19:30 20:30 21:30 22:30 23:30 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00 00:30 01:30 02:30 03:30 04:30 05:30 06:30 07:30 08:30 09:30 10:30 11:30 12:30 13:30 14:30 15:30 16:30 17:30 18:30 19:30 20:30 21:30 22:30 23:30 00:00 01:00 02:00 03:00 04:00 05:00 06:00 07:00 08:00 09:00 10:00 11:00 12:00 13:00 14:00 15:00 16:00 17:00 18:00 19:00 20:00 21:00 22:00 23:00...
  • Page 30 >RECORD SPEED SETUP< RECORD SETUP 1. RECORD TYPE FIELD RECORD SPEED SETUP PAGE 2. HDD FULL OVERWRITE TOTAL SPEED: FULL / HALF / 20 fps / 10 fps / 4 fps 3. RECORD SCHEDULE CH 01: ON 4. RECORD START CH 02: ON 5.
  • Page 31 4. EVENT RECORD ADVANCED SETUP PAGE EVENT RECORD SETUP PAGE 1. ALARM SETUP 1. EVENT MOTION 2. MOTION SETUP 2. EVENT ALARM 3. RECORD SETUP 3. EVENT DURATION 0 10 SEC 4. EVENT RECORD 4. RECORD SPEED FULL 5. EVENT 5.
  • Page 32 5. EVENT ADVANCED SETUP PAGE 1. ALARM SETUP 2. MOTION SETUP EVENT SETUP PAGE 3. RECORD SETUP 1. MOTION EVENT 4. EVENT RECORD 2. ALARM EVENT 3. VLOSS EVENT 5. EVENT 6. PASSWORD SETUP SYSTEM EVENT 7. HDD FORMAT 8. FACTORY DEFAULT 9.
  • Page 33 6. PASSWORD SETUP ADVANCED SETUP PAGE 1. ALARM SETUP 2. MOTION SETUP PASSWORD SETUP PAGE 3. RECORD SETUP 1. PASSWORD AUTH ON 4. EVENT RECORD 2. ADMIN (00000) 5. EVENT 3. USER (11111) 6. PASSWORD SETUP 4. GUEST (22222) 7. HDD FORMAT 8.
  • Page 34 7. HDD FORMAT ADVANCED SETUP PAGE 1. ALARM SETUP Press direction buttons up/down to 2. MOTION SETUP HDD FORMAT items position. 3. RECORD SETUP Press ENTER to format all HDD. 4. EVENT RECORD 5. EVENT Caution: User can format HDD only when 6.
  • Page 35 8. FACTORY DEFAULT ADVANCED SETUP PAGE 1. ALARM SETUP 2. MOTION SETUP Press direction buttons up/down to 3. RECORD SETUP FACTORY DEFAULT items position. 4. EVENT RECORD Press ENTER to restore. 5. EVENT 6. PASSWORD SETUP 7. HDD FORMAT 8. FACTORY DEFAULT 9.

  • Page 36: Specifications

    Specification and configuration DVR045 Model NTSC/ PAL Auto Detection Video I/F Input CH inputs 1.0Vp-p, 75ohm unbalanced (BNC Type) Output TV - monitor Composite (BNC), 1 TV - monitor (S-Video), 4 looping output (BNC) Horizontal Resolution 80 TV Lines S/N Ratio More than 40dB Color 6.7 Million...
  • Page 37 Mechanical IR Remote Controller Standard Shuttle Control Input Power Supply DC 12V / 5A Weight N.W.:7.3 kg(TBD) Dimension 430 (W) x 360 (D) x 72.6 (H) mm Operating Temperature 41° F~104° F (5° C~+40° C) Operating Humidity Less than 90% DVR system...

  • Page 38: Ptz Control

    DVR control PTZ dome (User needs to login if password protection is on) KAY 0 : To PTZ control mode. KEY 1 ~ 4 : Select camera. KEY 5: Exit preset function. KEY6 ~ KEY 9 / (Preset 1 ~ Preset 4): To preset position then preset setup mode on. (4 Preset setup support.) KEY QUAD: Set the preset position.
  • Page 39 (Approximate Time) Record Time Table: 80GB HD Record Quality: Low Full Half Hours 163 hr 243 hr 280 hr 379 hr 520 hr Record Quality: Normal Full Half Hours 194 hr 253 hr 357 hr 506 hr Record Quality: Fine Full Half Hours...
  • Page 40 1. Double click CD ROM, Video Viewer.exe. 2. Click Search to Live, then starts file search where user saved.
  • Page 41 Click Open to open file then playback. Click Save to save .bmp file.
