- Page 1 16 CH DVR User’s Manual...
-
Page 2: Important Safeguards
Cautions Read Before System Operation Follow these details to prevent material damage or personal injury. Signs of Caution and Warning Warning: This sign indicates that the user could die or be seriously wounded if not used or installed properly. Caution: This sign indicates that the user could be wounded or could expect property damage if not used or installed properly. - Page 3 Caution 1. Use the power cord, which is supplied or recommended by the supplier. The internal fan rotates at high speed and may cause an accident. 2. Do not drop, give strong vibration, or shock to the product. It may cause malfunction. 3.
-
Page 4: Table Of Contents
Contents GETTING STARTED................................. 5 1.1 S YSTEM TARTUP AND HUTDOWN ..............................5 1.2 F RONT ANEL ....................................6 1.3 R ANEL ....................................7 1.4 R EMOTE ONTROLLER ..................................8 OPERATION....................................9 2.1 T URNING ON URNING OFF THE SYSTEM .............................9 2.2 S CREEN LAYOUT .....................................9 2.3 S ETTING SCREEN... -
Page 5: Getting Started
GETTING STARTED 1.1 System Startup and Shutdown After connecting all peripheral devices then power on the DVR system, It will ask password with admin account after the DVR system startup, “Admin” user has fully control to the entire DVR system. PS. -
Page 6: Front Panel
1.2 Front Panel 11 12 Button Function DVD Burner Backup the recorded image by internal DVD burner Numeric Button Select the desired channel or input password Sequence display ZOOM Zoom In/Out POWER Power ON / OFF the DVR system SEARCH Go to search mode BACKUP Go to backup mode... -
Page 7: Rear Panel
1.3 Rear Panel 6 7 8 10 11 12 14 Name Description Video-In Video input (CH1 ~ CH16) BNC type Video Loop-Out Loop-out of camera images (CH1 ~ CH16) Spot-Out Connect the spot monitor Audio-In Audio input device (x16) S-Video Connect to S-Video terminal Video-Out Connect the CCTV monitor... -
Page 8: Remote Controller
1.4 Remote Controller The function button of this IR remote controller as below REC : Record button DVR-ID Number button AUDIO : Audio ON / Mute BACKUP : Backup the recorded data to other device MENU : Go to ‘MENU’ mode to setup the system / Close the dialog window OSD : Show or Hide OSD PTZ : Control Pan/Tilt/Zoom camera. -
Page 9: Operation
2. OPERATION 2.1 Turning on / Turning off the system Turn on the system. Connect the power cord with product and AC110V/220V socket, system will turn on automatically. Turn off the system. Press MENU button and go to shutdown. [MENU SETUP password SYSTEM... -
Page 10: Setting Screen
2.3 Setting screen Full screen mode - Press button. Whenever pressing button, screen will go to next screen. - Press desired numeric button of remote controller. Quad screen mode - To see quad screen mode, press button. - Whenever pressing button, screens will go to next quad screens. - Page 11 POP mode - Press POP button to enlarge specific camera with 7 other cameras. - Whenever pressing POP button, the biggest screen will change. OSD mode - System shows LIVE image with OSD or without OSD. - Press OSD button of remote controller to appear or disappear OSD. OSD button PIP mode (picture in picture) In case of full screen display mode, you can see other camera with a small window.
- Page 12 Sequence mode - If you press SEQ button in case of FULL or QUAD screen mode, screen(s) will rotate automatically. - Default value of cannel changing interval is 2 or 3 seconds. - User can select changing interval value from 1 to 99 seconds. SPOT OUT You can show specific video screen to monitor separately through SPOT OUT port of DVR.
-
Page 13: Digital-Zoom
2.4 Digital-ZOOM If you press ZOOM key of remote controller while in full screen mode, Digital- ZOOM function will work If you press direct button of remote controller, Zoom-Area window will move. If you press ZOOM key again, Zoom-Area window will be enlarged or diminished. If you press ENTER key, selected Zoom-Area will be displayed as full screen. -
Page 14: Searching
2.6 Searching Press SEARCH button. The SEARCH menu will pop-up. SEARCH BY TIME (1) Enter desired date and time to search for. (2) Then, Press ENTER button. SEARCH BY CALENDAR (1) If you select SEARCH BY CALENDAR, the calendar will appear. (2) Select desired date by pressing ◀▶▲▼... -
Page 15: Playback
GO TO FIRST Play starts from oldest restored data. GO TO LAST Play starts from latest restored data. If DVR is recording now, play will continue. If DVR is not recording, play will pause at last recorded position. 2.7 Playback Play starts with PLAY button. -
Page 16: Backup
2.8 Backup Backup to USB, CD/DVD writer devices PS. DVR just supports CD-R/CD-RW/DVD-R/DVD-RW format only. User can backup the data to USB flash memory or External USB CD/DVD writer. (1) For USB backup, connect USB device to USB port of DVR system. (2) Press FUNCTION button and Select BACKUP. -
Page 17: Ptz Control
2.9 PTZ CONTROL PTZ control If you press button of remote controller, screen will change to FULL screen mode and you can control PTZ camera. If you press Enter button while in PTZ menu, PTZ- ADVANCE function will pop-up. PTZ BASIC If you press ◀▶▲▼... -
Page 18: Audio
2.10 Audio Set audio output to make sounds at external speaker. Audio works only at full screen mode. You can control audio volume 2.11 Log view You can refer system log and backup by USB memory. ● EVENT TYPE – Select desired event type ●... -
Page 19: S/Wupgrade
If you click desired sub menu, system will move to selected sub-menu. Click right button of mouse to move to previous mode. MENU SETUP SERACH BACKUP LOGVIEW FUNCTION LOG OUT MENU 2008/04/20 05:35:30 A B C D 77% Go to Setup menu Start or Stop recording Go to Search menu Go to Backup menu... - Page 20 2.13.1 USB upgrade (1) Copy provided firmware file to your USB memory stick. The firmware file should be in Root directory of USB memory. (2) Connect USB memory stick to USB port of DVR. (3) Press Menu button and go to SOFTWARE UPDATE. [MENU SETUP password...
-
Page 21: System Setup
3. SYSTEM SETUP Before Use ● Accessing the Setup Menu (1) Pressing MENU button and select SETUP. (2) A password box will appear. Enter Admin password. ote : Use the Number buttons to enter the appropriate password. Default password is “0000”. ●... -
Page 22: Display
3.1 DISPLAY 3.1.1 DISPLAY – OSD ● CAMERA NAME - Show camera name on screen. ● CAMERA NUMBER – Show each number of cameras on the screen. ● CAMERA BOARDER – Show outline of channel. ● LANGUAGE – Select OSD language. ●... -
Page 23: Camera
3.1.2 DISPLAY-LIVE(/SPOT)-SEQ(FULL/QUAD) - Set switching time to display a full screen in sequence. - CH : Input desire channel no. - TIME : Input direst switching time - DEFALT CH : Change to factory default value - ALL TIME : same time is input to all channel. - SPOT OUT : Select desire port of SPOT OUT ote : can enter max. - Page 24 3.2.2 CAMERA – PTZ ● ID – Enter ID of PTZ camera. ● PROTOCOL – Select a protocol type of camera. ● BAUD – Select a baud rate of camera. 3.2.3 CAMERA – PRESET ● CAMERA – Select specific camera to save preset position. ●...
-
Page 25: Record
E.g. In this case, Camera 1 will move to saved position as follows, PTZ04 3sec PTZ12 3sec PTZ04 3sec PTZ12 3sec PTZ04 …….. 3.2.5 CAMERA-COLOR ● CAMERA – Select camera to change color. ● BRIGHT– Adjust bright of camera. ● CONTRAST – Adjust contrast of camera. ●... - Page 26 ● RESOLUTION – Use this menu to specify the size of a screen to be recorded. One resolution can be selected for all channel. NTSC 720 x 480 720 x 576 720 x 240 720 x 288 360 x 240 360 x 288 ●...
- Page 27 3.3.2 SCHEDULE System records according to schedule setting. Schedule recording types are as follows, Continuous Recording Event Recording (record when motion or alarm is detected.) Continuous + Event If one of CH-1 box is set to “C” and CH-2 is set to “E” on the same box, then the box will be displayed as “+”...
-
Page 28: Event
● RECORDING MODE - SCHEDULE System record according to Schedule mode - CONTINUE Always recording while system is running. (Recording never stops unless HDD is full or error!!) - EVENT Regardless of schedule mode, Event is recorded if Motion or Sensor is set ●... - Page 29 ● SENSITIVITY – Set the sensitivity of motion detection. Sensitivity degree : 0 < 1 < 2 < ….. < 9 ● ALARM-OUT – Set the alarm-out when motion is detected. 3.4.2 SENSOR ● RECORD – DVR System starts recording when a signal is detected from sensor. ●...
-
Page 30: Storage
3.4.4 VLOSS When video loss happens, system sounds connected alarm. You can select desire alarm port per each channel. 3.4.5 MISC ● PRE-REC TIME – Enter recording time (0~30sec) before event occurs. ● POST-REC TIME – Enter recording time (0~120sec) after event occurs ●... -
Page 31: Network
3.5.2 AUTO-BACKUP ● EXTEND – When the disk in product is full, DVR system copies additional recorded video files which will be erased due to overwriting to USB HDD. EXTEND BACKUP ㅁ A ㅁ B USB Storage INTERNAL HDD USB Storage INTERNAL HDD If you change USB port of external USB HDD after auto backup setting, Please check Auto ☞... - Page 32 (2) ADSL(PPPOE) If you use ADSL model, select ADSL and enter PPPOE ID and PASSWORD. If you don’t know ID and Password, please contact your ADSL service provider. 3.6.2 DDNS DVR supports basically DYNDNS.COM and NO-IP.COM for DDNS connection. Enter appropriate data as follows, ●...
-
Page 33: System
3.6.4 ACCESSLIST Registered IP address is allowed to access DVR. If you set at least one IP address, then only entered IP address(es) would be allowed to access DVR. 3.7 SYSTEM 3.7.1 CONFIG You can save system setting values to USB device or can load system setting values from USB device. - Page 34 ● DATE FORMAT – Select Date format. ● TIME FORMAT – Select type of time indication ● TIME ZONE – Select your arear to make adjustment of time zone . ● TIME SYNC This function is for synchronizing the time of DVR periodically with that of the connected sever by every hour.
- Page 35 ● TIME OUT – When this is set to ON, LOGIN window will re-appear after entered time from any signal input. If you want to log out, you need to go to MENU and select LOG OUT like right picture. 3.7.6 SHUTDOWN ●...
-
Page 36: Central Monitoring System (Cms)
4. Central Monitoring System (CMS) General information about CMS program CMS program is an application with which users not only watch and control remote DVRs, but also receive video/audio data or alarm signals with LAN, WAN environment. CMS enables users who care about security to manage full information from all the wire-connected DVRs. -
Page 37: Screen Division Option
Operating CMS program 4.1 Screen division option S/W displays appropriate channel mode automatically according to channel q’ty of connected DVRs. Also, you can select desire channel mode among 4 / 9 / 16 / 64 channel mode. You can see full scree mode by clicking maximize button You can see one channel mode by double click... -
Page 38: Dvr List
4.2 DVR LIST You can make DVR list to connect and all camera of the DVR will be displayed in the connection. 4.2.1 Group display window This window shows all kinds of registered information Group name, DVR site name, IP address / channel / Model name / Network port 4.2.2 Make Group or DVR site Delete Group / DVR site... -
Page 39: Pre List
4.3 PRE LIST You can make camera list to display from some DVRs. Then, you can save the camera list and load. 4.3.1 Making display List Select desire group and click button and drag desire camera to display to right table. -
Page 40: Connection / Disconnection
4.4 Connection / Disconnection Select a GROUP or a DVR that you want to connect or disconnect and click Connection or Disconnection button 4.5 PTZ control If you click PTZ button, window will change to PTZ control mode. Then, you can control PTZ camera in one channel mode. -
Page 41: Create User
4.7 Create user If you click button, a window of user list will appear. You can manage users to access Client S/W by adding or deleting user. ADD : add user DEL : delete registered user CHG : change user ID or Password Default : Delete all registered users except for admin user 4.8 Snapshot Select screen and click the snapshot button... -
Page 42: Remote Playback Player
4.10 Remote playback player (1) Select DVR site (2) Click button to change to remote playback mode. (3) Select recorded data and select time and minute by dragging (4) Then, click play button to play.
