Summary of Contents for Dogtra 175NCP
-
Page 2: Table Of Contents
CONTENTS MAIN FEATURES PRODUCT SAFETY AND HEALTH STATEMENTS COLLAR PACKAGE CONTENTS DESCRIPTION OF TRANSMITTER PARTS DESCRIPTION OF COLLAR / RECEIVER PARTS BATTERY CHARGER CHARGING THE BATTERIES TESTING YOUR COLLAR OPERATING INSTRUCTIONS ACCESSORIES WARRANTY AND REPAIR INFORMATION... -
Page 3: Main Features
400+ Dogs should be in good health during any e-collar yards. training. Dogtra e-collars are not intended for use on dogs weighing less than 12 pounds or under 6 months of age. Waterproof collar/receiver and water-resistant transmitter. -
Page 4: Product Safety And Health Statements
PACKAGE INCLUDES PRODUCT SAFETY AND HEALTH STATEMENTS Proper e-collar use COLLAR Dogtra e-collars are intended for the sole purpose of behavior modification of dogs. They are not PACKAGE CONTENTS intended for human use or use on other animals. Dogtra Company does not assume any liability for improper use of the Dogtra e-collar. -
Page 5: Description Of Transmitter Parts
TRANSMITTER TRANSMITTER DESCRIPTION OF TRANSMITTER PARTS transmitter 2 Antenna Antenna Transmitter Antenna Intensity Selection Dial A short 2 antenna is supplied with the transmitter. Indicator Light The antenna should be screwed into the top of the transmitter to ensure that the signals are sent “Nick”... - Page 6 TRANSMITTER TRANSMITTER Transmitter Battery Charging Receptacle Located on the side of the transmitter, the receptacle is covered by a rubber plug. Insert one end of the battery charging cable into the receptacle to charge the battery. (See Battery Charging Procedure on page 21.) Intensity Selection Dial After charging is completed, cover the The intensity selection dial is located on the...
-
Page 7: Button Function
TRANSMITTER BUTTON FUNCTION BUTTON FUNCTION Pager Nick Constant Transmitter Indicator Light (LED window) The transmitter indicator light is located near the intensity selection dial. When a button on the transmitter is pushed, the light comes on to The transmitter for has three indicate that the transmitter is being activated. -
Page 8: Description Of Collar / Receiver Parts
BUTTON FUNCTION COLLAR / RECEIVER “Nick” Button DESCRIPTION OF COLLAR / RECEIVER PARTS When the “Nick” button is pushed the receiver emits a single, rapid pulse of electrical Collar stimulation. “Constant” Button Pressing the “Constant” button gives Collar strap Battery Charging continuous stimulation as long as the button is Receptacle... - Page 9 COLLAR / RECEIVER COLLAR / RECEIVER On/Off Magnetic Switch On/Off Magnetic Switch Receiver Indicator Light (LED window) To activate the , place the red Located on the front of the collar, the dot on the back of the transmitter to the red dot on indicator light comes on and blinks once every 2 the collar receiver.
- Page 10 COLLAR / RECEIVER COLLAR / RECEIVER Fitting the Collar on the Dog Receiver Battery Charging Receptacle The collar should be fitted so that the On the inside of the collar, next to the collar stainless steel contact points press firmly against strap, is a battery charging receptacle with a the dog’s skin.
-
Page 11: Battery Charger
Charging Cable 120 volt Charger Wall Outlet Dogtra uses Ni-MH (Nickel-Metal-Hydride) The battery charger and charging cables batteries that do not set a memory and can be allow you to charge both the transmitter and charged on a regular basis without harm to the receiver at the same time. -
Page 12: Charging The Batteries
CHARGING THE BATTERIES CHARGING THE BATTERIES Battery Charging Procedure 2. Do not charge the batteries near any 1. Attach the charging cables to both the flammable substances. transmitter and receiver(s), as shown on page 19. 3. Fully charge the batteries for 10 hours if the unit is to be stored without use for a 2. -
Page 13: Testing Your
TESTING TESTING TESTING YOUR 2. Turn the intensity level on the transmitter COLLAR up to the maximum level (100) and press the Nick button. The indicator light(LED) on the collar receiver will light briefly as you push the button. Pressing the Constant button will light the indicator for as long as you hold the button down, up to twelve seconds. -
Page 14: Operating Instructions
OPERATING OPERATING OPERATING INSTRUCTIONS Intensity Selection To select the intensity level, start on the zero Fitting the Collar (0) setting. Gradually increase the level until you The collar strap should be adjusted so that the get a response from the dog that would be contact points are held firmly against the dog’s equivalent to a quick pull or jerk with a leash. - Page 15 OPERATING RECEPTION Reception Maintenance e-collar has a range of The receiver and collar strap should be 400+ yards. Depending on the way you use your cleaned periodically with detergent and water to transmitter, the transmitting range may vary. prevent malfunction. Hold the transmitter away from your body and avoid touching the antenna to get the greatest Always clean and rinse the collar thoroughly...
-
Page 16: Accessories
Labor fees and shipping fees incurred are the customers’ responsibility. Labor fees will be variable depending on the extent of work required. The Limited Lifetime Warranty will expire 5 years from the date a model is discontinued in production by Dogtra Company. - Page 17 Any water damage on the Water Resistant of service, Dogtra will estimate the age of the unit Transmitters of the 175NCP, 180NCP, 200NCP, by the serial number. Serial number estimates can 202NCP, 1400NCP, 1402NCP, 1500NCP and be different than the actual purchase time.
- Page 18 Dogtra is not responsible Send repair units to: for loss of training time or inconvenience while Dogtra Company / Repairs the unit is in for repair work. Dogtra does not 22912 Lockness Avenue provide loaner units or any form of Torrance, CA 90501 compensation during the repair period.
- Page 19 M E M O M E M O...
- Page 20 M E M O...
