Introducing the 1394 DV-Cam Kit
The 1394 DV-Cam Kit is designed to add three 1394 (FireWire) ports
to your computer for easy connection to DV camcorders, hard disk
drives (self-powered), scanners, printers, and other 1394 devices.
For your convenience, one 1394 (FireWire) 6-pin/4-pin DV cable is
included for connecting DV camcorders and other 1394 devices
using 4-pin connector. Deluxe video editing software is also included
for producing greeting cards, video e-mails, or home videos complete
with attractive titles, effects, and background music.
Key Features and Benefits
• IEEE 1394-1995, P1394a (rev. 1.1) and OHCI Interface Specification
1.0 compliant
• Fully compliant with PCI Plug-n-Play 2.1
• Adds 3 IEEE 1394 (FireWire) ports to your PC for connecting
up to 63 devices
• Supports hot-swapping and plug-n-play feature
• Supports serial bus data transfer rates of 100, 200, 400 Mbps
• Works with various types of DV camcorders (Sony, Panasonic,
Canon, JVC, Sharp and more), hard disk drives (self-powered),
hubs, CD-RWs/DVD-ROMs, MO drives, digital cameras,
scanners and audio/video devices such as TV and set-top box
System Requirements
• Pentium 233 MHz computer with one available PCI slot
• 1 GB or larger hard disk drive
• 32 MB RAM and CD-ROM drive
• Windows 98 SE/ME/2000
Recommended system for Digital Video capturing/editing:
• Pentium II 400 MHz computer
• 64 MB RAM and CD-ROM drive
04-0211B
1394 DV-Cam Kit
Quick Installation Guide
1
Advertisement
Table of Contents
Related Manuals for SIIG NN26 Series
Summary of Contents for SIIG NN26 Series
-
Page 1: Quick Installation Guide
1394 DV-Cam Kit Quick Installation Guide Introducing the 1394 DV-Cam Kit The 1394 DV-Cam Kit is designed to add three 1394 (FireWire) ports to your computer for easy connection to DV camcorders, hard disk drives (self-powered), scanners, printers, and other 1394 devices. For your convenience, one 1394 (FireWire) 6-pin/4-pin DV cable is included for connecting DV camcorders and other 1394 devices using 4-pin connector. -
Page 2: Package Contents
• 80 MB of available hard disk space • Video card with 4 MB RAM (PCI or AGP) • Windows 98 SE/ME/2000 Package Contents • One 1394 3-port host adapter • Deluxe Ulead VideoStudio DV editing software • One 1394 (FireWire) 6-pin/4-pin DV cable •... - Page 3 Windows ME/2000 Driver Installation Windows ME and Windows 2000 will automatically detect and install the correct driver for the 1394 3-Port host adapter. To verify successful installation: 1. Check Device Manager to verify successful driver installation. Windows 98 SE/ME: From the main desktop, double click My Computer, Control Panel, System, then click Device Manager.
- Page 4 Connecting 1394 Devices The following section provides information on connecting devices to your 1394 DV-Cam Kit. Connecting DV Camcorder Before setting up the digital video camcorder, make sure to verify the driver for the 1394 adapter has been successfully installed in your system and follow the setup procedures listed below.
-
Page 5: Technical Support
RMA number posted on the outside of the shipping carton. Step 3: Ship the Product You are responsible for the cost of shipping back to SIIG at the following address: SIIG, Inc. RMA#_______________ 6078 Stewart Ave. - Page 6 Fremont, CA 94538-3152 1394 DV-Cam Kit is a trademark of SIIG, Inc. SIIG and SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation.
