Table of Contents

Need help?

Do you have a question about the 710FX2 and is the answer not in the manual?

Questions and answers

Summary of Contents for N-Tron 710FX2

Page 1 710FX2 Managed Industrial Ethernet Switch User Manual & Installation Guide...
Page 2: Table Of Contents
710FX2 Industrial Ethernet Switch Installation Guide ... 5 710FX2 Industrial Ethernet Switch Accessories ... 7 SAFETY WARNINGS ... 9 SUPPORT: ... 9 Installation ... 10 DIN RAIL MOUNTING ... 12 FRONT PANEL (710FX2) ... 13 APPLYING POWER (Top View)... 14 Connecting the Unit ...
Page 3 Show or Set N-View Configuration ... 145 Ping a Host ... 146 Show or Set Port Configuration ... 147 Reset the Switch ... 148 Show or Set SNMP Configuration ... 148 Show or Clear the Last System Error ... 149 Show System Information ...
Page 4 Example 4 – Basic understanding of Hybrid VLANs ... 160 Example 5 – Basic understanding of Overlapping VLANs... 161 Example 6 – Basic understanding of VLANs with Multicast Filtering ... 162 KEY SPECIFICATIONS (710FX2) ... 163 KEY SPECIFICATIONS (710FX2-HV) ... 165 Appendix A. XML Settings File Example ... 166 N-TRON Limited Warranty ...
Page 5: Revised 2012
710FX2 Industrial Ethernet Switch Installation Guide The N-TRON 710FX2 Industrial Ethernet Switch offers outstanding performance and ease of use. It is ideally suited for connecting Ethernet enabled industrial and or security equipment and is a fully managed switch. Page 5 of 170...
Page 6: Product Features
• 802.1Q tag VLAN and Port VLAN • 802.1p QoS, Port QoS, and DSCP • LLDP (Link Layer Discovery Protocol) • Trunk with other N-Tron trunking capable switches over two ports • Port Mirroring • 802.1D RSTP (Rapid Spanning Tree Protocol) •...
Page 7: 710Fx2 Industrial Ethernet Switch Accessories
Connection or disconnection in an explosive atmosphere could result in an explosion. NTCD-128 The configuration device is inserted in the back of the 710FX2. (Revised 2012-05-01 Configuration Device Ideal for saving, or restoring switch configuration parameters quickly without the need for a computer or software.
Page 8 In no event shall N-Tron Corp. be liable for any incidental, special, indirect, or consequential damages whatsoever included but not limited to lost profits arising out of errors or omissions in this manual or the information contained herein.
Page 9: Safety Warnings
SAFETY WARNINGS GENERAL SAFETY WARNINGS WARNING: If the equipment is used in the manner not specified by N-Tron Corp., the protection provided by the equipment may be impaired. LASER SAFETY (Single Mode Fiber Models -40 and -80) CAUTION: CLASS 1 LASER PRODUCT. Do not stare into the laser!
Page 10: Installation
Use 90°C or higher rated Copper wire, (0.22Nm) 2lb/in Tightening torque for field installed conductors. Please make sure the 710FX2 Series Ethernet Switch package contains the following items: 1. 710FX2 Series Switch 2. Product CD Contact your carrier if any items are damaged.
Page 11 CLEANING Clean only with a damp cloth. Page 11 of 170 (Revised 2012-05-01...
Page 12: Din Rail Mounting
URMK Most N-Tron™ products are designed to be mounted on industry standard 35mm DIN rail. However, DIN rail mounting may not be suitable for all applications. Our Optional Universal Rack Mount Kit (P/N: URMK) may be used to mount the enclosure to standard 19" racks, and our Optional Factory Installed Panel Mount Assembly may be used to mount the enclosure to a panel or any other flat surface.
Page 13: Front Panel (710Fx2)
FRONT PANEL (710FX2) From Top to Left: RJ45 Ports Auto Sensing 10/100 Base-TX Connections Fiber Ports 100 Base-FX Connections LED lights when Power is supplied to the unit NOTE: The RJ45 data port has two LEDs located on each connector. The left LED indicates LINK status, and the right LED indicates ACTIVITY.
Page 14: Applying Power (Top View)
The conditions for generating a fault condition (closing the relay) can be configured through software. Recommended 24V DC Power Supplies, similar to: N-Tron’s P/N NTPS-24-1.3 (NOTE: Not appropriate for use with M12, POE, and HV models.): Input AC 115/230V Output DC 24-28V Output Current 1.3A @ 24V...
Page 15: Connecting The Unit
Verify that the LNK LEDs are ON once the connection has been completed. To connect any port to another device (end node, Switch or Repeater), use a standard Category 5E straight through or crossover cable with a minimum length of one meter and a maximum length of 100 meters.
Page 16: N-Tron Switch Grounding Techniques
Some N-Tron switches have metal din-rail brackets that can ground the switch if the din-rail is grounded. In some cases, N-Tron switches with metal brackets can be supplied with optional plastic brackets if isolation is required.
Page 17: Rj45 Connector Crimp Specifications
RJ45 CONNECTOR CRIMP SPECIFICATIONS Please reference the illustration below for your Cat5 cable specifications: Page 17 of 170 (Revised 2012-05-01...
Page 18: Usb Interface
USB INTERFACE The 710FX2 Series switches provide a USB interface accessed via the USB connector labeled as “USB” on the unit. This is used to access the Command Line Interpreter (CLI). The USB connector is at the bottom of the 710FX2.
Page 19: Overview Of Advanced Features
Overview of Advanced Features Mode of Operation Each port on the switch can be configured into different modes of operation as shown below: Copper Ports: - Half Duplex - Full Duplex - Auto Negotiation Half Duplex In half duplex mode, the CSMA/CD media access method is the means by which two or more stations share a common transmission medium.
Page 20: Virtual Lan
A Default Virtual LAN (VID=1) exists to which a port, which is not a member of any other Virtual LAN, will belong. This allows the switch to operate as a ‘normal’ switch when it is used in a network. A port is automatically removed from the Default VLAN when it is reconfigured to belong to another Virtual LAN, because that is the most common operation.
Page 21: Rapid Spanning Tree Protocol
STP when desired. SNMP Traps The 710FX2 Series switch supports up to 5 SNMP Trap Stations to which SNMP Traps will be sent. The switch supports five standard traps; Link Up, Link Down, Cold Start, Warm Start, Authentication Errors, and power supply failure.
Page 22: N-Ring
DHCP is controlled by RFC 2131. The N-Tron DHCP Switch can be configured to be a DHCP Client. Alternately the N-Tron DHCP switch can be configured to be a DHCP Server, a DHCP Relay Agent, or both.
Page 23: Dhcp Client
MAC addresses as authorized. Dynamically learned MAC addresses are those that the switch detects on any port while in ‘Learning’ mode. A manually entered MAC address must designate the ports that the address is authorized on. A non-authorized MAC address will be discarded and will be shown on the intruder log.
Page 24: Troubleshooting
~ 2X. Verify that Link LEDs are ON for connected ports. Verify cabling used between stations. Verify that cabling is Category 5E or greater for 100Mbit operation. SUPPORT Contact N-Tron Corp. at: TEL: 251-342-2164 FAX: 251-342-6353 E-MAIL: N-TRON_Support@n-tron.com WEB: www.n-tron.com...
Page 25: Web Software Configuration
Web Software Configuration Web Management Enter the switch’s IP address in any web browser and login to the web management feature of the 710FX2 Series. Default: User Name: admin Password: admin (Revised 2012-05-01 Page 25 of 170...
Page 26: Web Management - Home
When the administrator first logs onto a 710FX2 Series switch the default home page will be displayed. On the left hand side of the screen there is a list of configurable settings that the 710FX2 Series switch will support. This section of the manual will go through each and every choice listed on the left hand side of the screen and explain how to configure those settings.
Page 27: Web Management - Menu Structure
Web Management – Menu Structure To the left, there is a menu which is shown fully opened below. The pages opened by each of the individual selections are described in the rest of this section. The use of each of these pages is also described in this section.
Page 28: Administration - System
The calculated ambient temperature near the switch. This calculation is only valid after a warm-up period. Upper Threshold: The highest temperature for the switch without causing a fault to occur. The threshold is specified as an integer in C degrees. The range is from -60°C to 100°C, and the default is product dependent.
Page 29 Client ID Option used by DHCP clients to specify their unique identifier. The identifier may be the MAC address, switch name, or entered as a text string or hex characters. Fallback IP Address Contains the configured Fallback IP Address of the device.
Page 30 Administration – System, Continued… By selecting the Modify button, you will be able to change the switch’s IP Configuration, Client ID, IP Address, Subnet Mask, Gateway, Name, Contact information, and the Location of the switch through the web management features, depending on the IP Configuration. It is recommended to change the TCP/IP...
Page 31 If the IP Configuration mode is set to DHCP and the Fallback IP address is changed from the default IP address, then the switch will use the Fallback addresses if the IP configuration isn’t received from a DHCP server in 2 minutes after initial boot. If Fallback address is used, DHCP Client will stop sending requests. If the IP Configuration is received from a DHCP server, it will never fallback, even if the lease is lost.
Page 32: Administration - Snmp
Administration – SNMP The SNMP tab under the Administration category allows SNMP to be disabled or enabled, and shows a list of IP Addresses that act as SNMP Traps. The Read-Only, Read-Write, and Trap Community Names are also shown here. By selecting the Modify button, you will be able to change any of the fields listed.
Page 33 Administration – SNMP, Continued… Page 33 of 170 (Revised 2012-05-01...
Page 34: Administration - Fault
Administration – Fault The Fault tab under the Administration category provides configurable selections indicating the way to notify when a Power, N-Ring Manager, N-Link fault, or Port Usage Fault occurs. The notification may consist of any combination of the options: Show Web, Show LED, and Contact. Power signal faults consist of V and V .
Page 35 Following the Modify button, the administrator will see a list of configurable fields for the Fault configuration. The fault relay contacts can be configured to open on fault or to close on fault, with the latter being the default. Once these fields are filled in to meet the needs of the administrator’s network, the changes may be updated by clicking the Update button at the bottom of the page.
Page 36: Dhcp - Server - Setup Profiles
DHCP – Server – Setup Profiles The Setup Profiles tab under the DHCP/Server category lists the following information about the current state of the server and the existing network profiles: Server Enabled Indicates whether the DHCP server is active. Allow Broadcast Indicates whether the DHCP server will process broadcast messages.
Page 37 DHCP – Server – Setup Profiles, Continued… Page 37 of 170 (Revised 2012-05-01...
Page 38: Dhcp - Server - Setup Ip Maps
There are two different data entry formats available according to whether the relay agent type is for an N-TRON or for a generic switch. To create a range of static IP addresses on an N-Tron relay agent switch: Network Profile An existing network profile to which the IP map applies.
Page 39 Should be set to N-TRON. Switch Model List of N-TRON models that support this feature. Remote ID A unique identifier that designates the N-TRON relay agent switch. Checkbox used to add an IP map for the corresponding port. Port No The actual port number.
Page 40 DHCP – Server – Setup IP Maps, Continued… DHCP – Server – Setup IP Maps, Continued… To create a range of static IP addresses on a generic relay agent switch: Network Profile An existing network profile to which the IP map applies.
Page 41 The actual port number. Remote ID The identifier that corresponds to an Option 82 Remote ID sub-option used by the particular relay agent switch. Circuit ID The identifier that corresponds to an Option 82 Circuit ID sub-option used by the particular relay agent switch.
Page 42 DHCP – Server – Setup IP Maps, Continued… The Single IP type of mapping is used to create a static IP address for an individual client. The following information is required: Network Profile An existing network profile to which the IP map applies. The static IP address to offer to a client.
Page 43: Dhcp - Server - View Bindings
DHCP – Server – View Bindings The View Bindings tab lists the bindings of physical devices to IP addresses that are in use or offered: Network Profile The profile applied to the binding entry. Binding Identifier The client associated with the binding entry. Client Hardware Address (MAC) The client’s MAC address.
Page 44: Dhcp - Relay & Local Ip - Setup
DHCP – Relay & Local IP - Setup The Setup tab under the DHCP/Relay & Local IP category shows the current state of the relay agent. By selecting the Modify button, you can configure general settings of the relay agent, as well as, configure settings on a per port basis.
Page 45 DHCP – Relay & Local IP – Setup, Continued… Relay Status Indicates whether the DHCP relay agent is active. Remote ID The unique identifier that designates the relay agent switch. Server # IP The configured IP address of the DHCP servers. Port No The actual port number.
Page 46 DHCP – Relay & Local IP – Setup, Continued… Page 46 of 170 (Revised 2012-05-01...
Page 47: Lldp - Configuration
Enabled on LLDP Port settings. Default = 2 Seconds. Notification Interval Specifies the interval between successive Notifications generated by the switch. If a port sends out a notification and another port tries to send out a notification, the notification will not be sent until the interval expires.
Page 48: Lldp - Ports
Receive Enables or Disables Receiving of LLDP Frames from neighbor switches. Allow Management Data Allow the Transmission of Management type information. For example: IP Address of switch, Port Description, System Name and Vlan information. Allow Notifications Notifications are transmitted when local or remote data changes.
Page 49: Lldp - Status
The name of the local port on which the neighbor information was received. Neighbor MAC MAC address of neighbor switch. Corresponds to the LLDP Chassis ID TLV. Neighbor IP IP address of neighbor switch. Corresponds to the LLDP Management Address TLV.
Page 50: Lldp - Statistics
Total count of all LLDP frames received with one or more detectable errors. Neighbor Age Outs Total count of the times that a neighbor's information has been deleted from the switch because the Time to Live (TTL) has expired. LLDP Port Status Local Port setting (Receive-Rx/Transmit-Tx/Disable).
Page 51: Ports - Configuration
Ports – Configuration The Configuration tab under the Ports category will show a detailed overview of all the active ports on the switch. The overview will display the following information: Port Number This is the port index. Port Name This field displays the name of the port. The designation of TX is for copper ports, FX is for fiber optic ports, and GB is for the Gigabit ports (fiber or copper).
Page 52 Ports – Configuration, Continued… Page 52 of 170 (Revised 2012-05-01...
Page 53 Ports – Configuration, Continued… The User can click on the Port Number to configure each port individually. This will allow the user to change the port’s settings for the following fields which are explained above: Admin Status Speed and Duplex Cross Over Flow Control PVID...
Page 54: Ports - Mac Security - Learning
Ports – MAC Security – Learning The Learning tab allows the administrator to control the learning or locking modes for the ports. ‘Locked’ is the secure mode. ‘Learning’ builds an internal list of authorized MAC addresses based on an approved LAN.
Page 55 Ports – MAC Security – Learning Continued… In ‘Locked’ mode, ‘Secured Ports’ shows the ports that are presently secured. Note: when N-Ring and/or N-Link are used, the N-Ring/N-Link ports will not have MAC Security enabled. Page 55 of 170 (Revised 2012-05-01...
Page 56 Ports – MAC Security – Learning Continued… The Modify button allows the administrator to change the current mode and select the ports to be secured. When transitioning from ‘Learning’ to ‘Locked’, the Address Resolution Logic (ARL) table represents the authorized MAC addresses, with the addition of any manually entered addresses (refer to Authorization List section below).
Page 57: Ports - Mac Security - Authorization List
Ports – MAC Security – Authorization List The Authorization List tab allows for manual entry or deletion of authorized MAC source addresses with associated authorized ports. Selecting Modify displays the MAC Authorization Configuration page, which allows the administrator to add new entries, delete existing entries, or edit authorized ports of existing entries. Selecting Delete removes the associated entry.
Page 58: Ports - Mac Security - Intruder Log
Ports – MAC Security – Intruder Log The Intruder Log tab displays a list of unauthorized MAC addresses that attempted to access the secured device. Each intruder entry in the log is unique, and is based on the combination of MAC address, VLAN, and port.
Page 59: Ports - Mirroring
Ports – Mirroring A mirroring port is a dedicated port that is configured to receive the copies of Ethernet frames that are being transmitted out and also being received in from any other port that is being monitored. The Mirroring tab under the Ports category displays the status including the list of Source Ports and the Destination Port that the Sources are being mirrored to.
Page 60: Ports - Mirroring, Continued
Ports – Mirroring, Continued… Following the Modify button, you can enable the status of port mirroring and select source ports and the destination port that the source ports will be mirrored to. Page 60 of 170 (Revised 2012-05-01...
Page 61: Ports - Mirroring, Continued
Ports – Mirroring, Continued… Mirrored Data Only: If this checkbox is selected, only mirrored data will be transmitted by the destination port. That is, data that was to be transmitted from the Destination Port itself, other than by mirroring, will not be transmitted.
Page 62: Ports - Trunking
Two ports of the same speed can constitute a valid trunk. Only 1 Trunk per switch can be created. All trunk ports must be at the same speed and duplex mode. If a port is not linked, there could be difficulty as to similar speed and duplex mode.
Page 63: Ports - Qos
Ports – QOS The QOS decision tree chooses the highest priority Transmit Queue (TQ) of the following criteria: Force High Priority (Port Based) TQ mapping, IEEE 8021.p TQ mapping, or DSCP TQ mapping. The QOS tab under the Ports category displays the following details: Port Number This is the port index.
Page 64 Ports – QOS, Continued… Following the Modify button, the administrator can independently configure the ports for different QOS functionality. Once these fields are filled in to meet the needs of the administrator’s network, the changes may be updated by clicking the Update button at the bottom of the page. Page 64 of 170 (Revised 2012-05-01...
Page 65: Statistics - Port Statistics
Statistics – Port Statistics The Ports Statistics tab under the Statistics category displays a list of MIB parameters. Each port has a separate counter for each parameter. This gives users the ability to see what kind of packets are going over which ports.
Page 66: Statistics - Port Utilization
These figures and bars are for a general feeling of what the bandwidth usage is. N-Tron recommends the use of N-View in order to get a more precise bandwidth usage figure.
Page 67: Vlan - Configuration
VLAN – Configuration Note: Consult the Table of Contents for ‘VLAN Addition and Deletion Example’, and ‘VLAN Configuration Examples’. These are detailed examples. Replace VID Tag with Default Port VID Specifies whether or not to replace the incoming VID tag with the port's designated VID. Perform Ingress Filtering Specifies whether or not to filter out ingress frames when a VID violation is detected.
Page 68: Vlan - Group Configuration
VLAN – Group Configuration VLAN ID This field displays the VLAN ID. The range should be 1-4094. VLAN Name This configurable field displays the name of the VLAN, which accepts alphanumeric and special characters (#, _, -, .) only. Allow Management Specifies whether or not all ports in this VLAN are management ports.
Page 69: Bridging - Aging Time
After selecting the Modify button, the user will be presented with a page that allows the number to be entered and updated. The default aging time is 20 seconds. Note: If the switch is an active participant of an N-Ring, then the N-Ring Aging Time will be used instead of the Bridging Aging Time.
Page 70: Bridging - Unicast Addresses
Following the Add button on the page above, the administrator must enter a valid MAC address and associate it with a port number on the switch. Once the administrator hits the Add button, the changes will take effect instantly.
Page 71 Bridging – Unicast Addresses, Continued… Once a static MAC address has been added, it will be displayed in a list on the main page under Unicast MACs tab. Following the Remove button on the example above, an administrator can select a static MAC address from the list using a pull-down menu.
Page 72: Bridging - Multicast Addresses
Note: If there are multiple ports on different VLANs, the 710FX2 will apply the static multicast address to the lowest VLAN-ID that is associated with one of the ports assigned to the static multicast address.
Page 73 Then click on the Remove button at the bottom of the page. Note: If there are multiple ports on different VLANs, the 710FX2 will apply the static multicast address to the lowest VLAN-ID that is associated with one of the ports assigned to the static multicast address.
Page 74: Bridging - Show Mac By Port
Bridging – Show MAC by Port This feature shows the MAC addresses of devices connected to each switch port and the IP Addresses associated with the MACs. The browser page ‘View MAC by Port’ shows the MAC for the device found on each port, and the IP for the MAC presented if available.
Page 75 When an IP has been manually entered a button is provided to ‘Delete IP’, and invoking it will allow the administrator to delete the manual association of an IP to that MAC. Page 75 of 170 (Revised 2012-05-01...
Page 76: Rstp - Configuration
RSTP – Configuration The Configuration tab under the RSTP category will display the RSTP information for the first VLAN. Using the pull-down menu at the top of the page an administrator can choose which VLAN to configure RSTP on. Once the VLAN is selected, the administrator may configure the bridge by clicking on the ‘Configuration’...
Page 77 RSTP – Configuration Continued… The configuration screen for the VLAN that was previously selected will look like the example below. Here the administrator can make changes such as the Hello Time, Forward Delay, Max Age, Priority, and the Status of RSTP on that VLAN. The administrator or user can see the current RSTP status of the ports on that VLAN by clicking on the ‘here’...
Page 78 RSTP status of the ports on that VLAN. This will show information such as the Path Cost and the Port State. If the switch sees a redundant path it will put the port with the highest Path Cost into Blocking mode where it will discard packets coming in on that port.
Page 79 RSTP – Configuration Continued… If the administrator selects one of the ports on the previous screen, he or she can change the Port’s Path Cost, Priority, and the status of Admin Edge and Auto Edge. Page 79 of 170 (Revised 2012-05-01...
Page 80: Igmp - Configuration
IGMP – Configuration The Configuration tab under the IGMP category will display the IGMP basic configuration settings. By default, IGMP is enabled. Following the Modify button, the administrator will see a list of configurable fields for the IGMP configuration. Once these fields are filled in to meet the needs of the administrator’s network, the changes may be updated by clicking the Update button at the bottom of the page.
Page 81 IGMP – Configuration, Continued… The IGMP Status pull-down allows the user to enable or disable IGMP completely. The Query Mode pull-down allows the user to set query mode for Automatic (the default), On (always), or Off (never): Page 81 of 170 (Revised 2012-05-01...
Page 82 IGMP – Configuration, Continued… The Router Mode pull-down allows the user to choose router mode. ‘Auto’ allows for dynamically detected and manually set router ports. ‘Manual’ allows only for manually set router ports. ‘None’ allows no router ports. If Remove Unused Groups is checked then unused IGMP Groups will be removed and traffic with those multicast addresses will be treated as normal multicast.
Page 83 The user can specify the manual router ports: Page 83 of 170 (Revised 2012-05-01...
Page 84: Igmp - Show Group And Show Router
IGMP – Show Group and Show Router The Show Groups tab under the IGMP category will display a list of IGMP groups based on the Group IP and the port number that it is associated with. The Show Routers tab under the IGMP category will display a list of Auto-detected Router IPs and the port numbers that they are associated with.
Page 85: Igmp - Rfilter
IGMP – RFilter The ‘rfilter’ (Router Multicast Data Filter) function allows you to choose whether or not DATA frames with KNOWN group multicast addresses are sent to the ‘router’ ports (links to other switches). Control packets (Join, Leave) will be sent to the router(s) regardless of this setting. “KNOWN” is known from dynamic IGMP Snooping operations.
Page 86 IGMP – RFilter, Continued… Modifying rfilter port settings: Page 86 of 170 (Revised 2012-05-01...
Page 87: N-View - Configuration
N-View – Configuration The Configuration tab under the N-View category will display two basic variables for N-View, the status and the interval between packets. Following the Modify button on the above example, the administrator can modify the variable to change the frequency with which N-View reports information.
Page 88: N-View - Ports
N-View – Ports The Ports tab under the N-View category will display a list of all the configured ports on the 710FX2 unit along with the ports transmitting multicast packets and MIB stats respectively. Page 88 of 170 (Revised 2012-05-01...
Page 89 N-View – Ports, Continued… Following the Modify button on the above example, the administrator can modify these two variables to enable or disable multicast out of the port and if MIB stats are sent out for those ports. Page 89 of 170 (Revised 2012-05-01...
Page 90: N-Ring - Configuration
The N-Ring Aging Time has a default of 20 seconds and is separate from the Bridging Aging Time. N-Ring Aging Time is used when the switch is an N-Ring Manager or becomes an active N-Ring Member, and in either case N-Ring status includes for example: “Switch is currently using N-Ring Aging Time = 20 Seconds”...
Page 91 N-Ring – Configuration, Continued… The “N-Ring Mode” is one of three, as below: If N-Ring Mode is “Manager”, then a pull-down allows selection of available ports TX1/TX2, or FX1/FX2 (on 710FX2) as N-Ring ports. Page 91 of 170 (Revised 2012-05-01...
Page 92 N-Ring – Configuration, Continued… If N-Ring Mode is “Manager”, then VLAN ID can be set to a unique VLAN id (1 ~ 4094). Default is 3333. If N-Ring Mode is “Manager”, then a pull-down allows selection as to whether the N-Ring ports are members of the VLAN’s Tagged or Untagged ports.
Page 93: N-Ring - Advanced Configuration
The interval of time to wait in milliseconds before requesting subsequent sign-on information from ring members when the ring is broken. The default is 3000. Sign-On Info Spacing Multiplier The amount of time to wait in milliseconds, scaled by switch number, before sending information to the ring manager. The default is 5. Sign-On Info Retry Timeout The amount of time the ring member will wait in milliseconds for the ring manager to acknowledge receipt of the member's information before the member tries to re-send the information.
Page 94 N-Ring – Advanced Configuration, Continued… Page 94 of 170 (Revised 2012-05-01...
Page 95: N-Ring - Status
The Status tab under the N-Ring category will display the N-Ring status. Below is an example of N-Ring Status from a switch in defaults (N-Ring Auto Member) that is not an N-Ring Manager and has not become an “Active” N-Ring Member: Below is an example of N-Ring Status from an “Active”...
Page 96 N-Ring – Status, Continued… Below is an example of N-Ring Status from an N-Ring Manager with a healthy N-Ring: Page 96 of 170 (Revised 2012-05-01...
Page 97 N-Ring Map show problems. Ports that are red indicate that the port is not linked. MAC addresses that are red indicate that there is no communication to that switch. The red “Ring Broken” line shows where the N-Ring is broken.
Page 98 N-Ring – Status, Continued… In rare cases an N-Ring can have a “Partial Fault”. An example of this is to have a break in just one fiber in a duplex channel fiber pair. The screenshot below shows N-Ring Manager Status when a ‘Higher’ N-Ring Port (TX2, FX2) is not receiving self health frames all the way around the N-Ring, though the other (low TX1, FX1) N-Ring port is: The screenshot below shows N-Ring Manager Status when a ‘Lower’...
Page 99: N-Link - Configuration
Coupler Port (Default: TX4) Coupler Port (Auto-Detected) N-Link Couper N-Ring Member N-Ring Auto Member For convenience, a diagram similar to the above is provided in the switch’s browser help for N-Link. (Revised 2012-05-01 N-Ring N-Rng Auto Manager Member N-Ring #1 Control...
Page 100 There must be a direct link between the Master and Slave Partner ports. Use of media converters or other switches is not supported. There must be at least one other switch, besides the Master and Slave, that supports N-Link on the N-Ring.
Page 101 Following the Modify button on the above example, the administrator will see a list of configurable fields for the N-Link configuration, as below. The port configured as the Default Coupler Port will be used as the Standby Coupler port if the switch detects an N-Link Master and becomes an N-Link Slave.
Page 102 N-Link – Configuration, Continued… The “N-Link Mode” is one of two choices, as below: If N-Link mode is “Master”, then the administrator must configure the Control Port (default: TX3) and the Primary Coupler Port (default: TX4). Once these fields are filled in to meet the needs of the administrator’s network, the changes may be saved by clicking the Update button at the bottom of the page.
Page 103: N-Link - Status
The Status tab under the N-Link category will display the N-Link status. If the switch is an N-Link Master or Slave, the following switch status and partner status information will be shown. Fields with a red background designate a fault condition.
Page 104 N-Link – Status, Continued… Below is an example of N-Link Status from an N-Link Coupler switch: Below is an example of N-Link Status from an N-Link Master switch: Page 104 of 170 (Revised 2012-05-01...
Page 105 N-Link – Status, Continued… Below is an example of N-Link Status from an N-Link Slave switch: Below is an example of N-Link Status from an N-Link Master and Slave where the Primary Coupler link is broken: Page 105 of 170...
Page 106 N-Link – Status, Continued… Below is an example of N-Link Status from an N-Link Master and Slave where the Standby Coupler link is broken: Below is an example of N-Link Status from an N-Link Master and Slave where the Control link is broken: Page 106 of 170 (Revised 2012-05-01...
Page 107 N-Link – Status, Continued… Below is an example of N-Link Status from an N-Link Master and Slave where the Partner link is broken: Page 107 of 170 (Revised 2012-05-01...
Page 108: Cip - Configuration
The Configuration tab under the CIP category will display basic variables for CIP, and the status: Cip Status: Enables or Disables CIP on the Switch. Default: Enabled. Multicast RPI: The minimum Requested Packet Interval for Class 1 (multicast) connections, in milliseconds.
Page 109: Cip - Status
Major Revision: The Major Revision of the CIP implementation. Minor Revision: The Minor Revision of the CIP implementation. Serial Number (hex): CIP Serial number, unique across all N-Tron CIP devices. This is the last 4 octets of the base switch MAC.
Page 110: Firmware/Config - Tftp
The TFTP tab under the Firmware/Config category gives the administrator the ability to upload or download a config file for a 710FX2 Series switch. This allows administrators to backup their configurations to a server offsite in case they need to reload their custom configurations at a later time. Administrators can also...
Page 111: Firmware/Config - Tftp, Continued
Firmware/Config – TFTP, Continued For ‘uploading a saved config to server’ or ‘downloading a config from server’, there are checkbox choices that can be made as below. The most common example is to keep the pre-existing IP, Gateway, and Subnet Mask when otherwised downloading a config from the server.
Page 112: Support - Web Site And E-Mail
Support – Web Site and E-mail If at any point in time you get confused or would like additional support directly from N-Tron, you may visit N-Tron’s web site, or e-mail N-Tron directly with the links provided for more information.
Page 113: Rate Limiting - Broadcast Rate Limit Configuration
Rate Limiting – Broadcast Rate Limit Configuration The Rate Limiting/Broadcast link will display all the ports that are installed in the 710FX2 Series unit and will list the Broadcast Pass Rate Percentage for each port. Broadcast Pass Rate Percentage defaults to 3% on 10/100Mbs ports.
Page 114: Rate Limiting - Multicast Rate Limit Configuration
Rate Limiting – Multicast Rate Limit Configuration The Rate Limiting/Multicast link will display all the ports that are installed in the 710FX2 Series unit and will list the Multicast Pass Rate Percentage for each port. Multicast Pass Rate Percentage defaults to 100% on all ports.
Page 115: User Management - Adding Users
The User Management link will display a list of all the users who have access to the management features of the switch and their access permissions. Following the Add button on the above example, the administrator can add another user and assign the user a username, a password, and the user’s permissions (user/administrator).
Page 116: User Management - Removing Users
A page should follow indicating that the user was successfully removed from the list. Note: There are a maximum number of 5 users per switch. User permissions have the right to view switch configurations and to view current port settings, but cannot make any changes to these settings.
Page 117: Logicalview
LogicalView The 710FX2 Web Management offers a logical view of the switch. Here a user or administrator can see a graphical depiction of the 710FX2 series switch. Ports that are linked will appear in green, while ports that are not linked will appear in black. The example below shows a 710FX2FX2 with ports 3, 4, 5, and 7 linked.
Page 118: Configuration - Save Or Reset
The “Factory” button will reload N-Tron’s factory default configuration settings. Doing so will reconfigure the 710FX2 Series switch to factory defaults. In many cases it is desirable to restore factory defaults but retain certain settings. Checkboxes are provided to select the desired behavior. Note that if no Configuration Device is present, that is presented.
Page 119 If a Configuration Device is present, that is presented: Page 119 of 170 (Revised 2012-05-01...
Page 120: Help - Overview
When the Help link is clicked on, you will see the Overview page that will have some basic definitions and more specific choices at the top of the screen. Although this page is not as detailed as the manual, it gives you a basic feel for different features the 710FX2 offers. Page 120 of 170...
Page 121: Help - Administration
Help – Administration Following the Administration link on the help page, the administrator or user can see some information regarding the configuration options in the Administration category on the left side of the web management. Page 121 of 170 (Revised 2012-05-01...
Page 122: Help - Dhcp
Help – DHCP Following the DHCP link on the help page, the administrator or user can see some information regarding the configuration options under the DHCP categories on the left side of the web management. Page 122 of 170 (Revised 2012-05-01...
Page 123: Help - Lldp
Help – LLDP Following the LLDP link on the help page, the administrator or user can see some information regarding the configuration options in the LLDP category on the left side of the web management. Page 123 of 170 (Revised 2012-05-01...
Page 124: Help - Ports
Help – Ports Following the Ports link on the help page, the administrator or user can see some information regarding the configuration options in the Ports category on the left side of the web management. Page 124 of 170 (Revised 2012-05-01...
Page 125: Help - Statistics
Help – Statistics Following the Statistics link on the help page, the administrator or user can see some information regarding the configuration options in the Statistics category on the left side of the web management. Page 125 of 170 (Revised 2012-05-01...
Page 126: Help - Vlan
Help – VLAN Following the VLAN link on the help page, the administrator or user can see some information regarding the configuration options in the VLAN category on the left side of the web management. Page 126 of 170 (Revised 2012-05-01...
Page 127: Help - Bridging
Help – Bridging Following the Bridging link on the help page, the administrator or user can see some information regarding the configuration options in the Bridging category on the left side of the web management. Page 127 of 170 (Revised 2012-05-01...
Page 128: Help - Rstp
Help – RSTP Following the RSTP link on the help page, the administrator or user can see some information regarding the configuration options in the RSTP category on the left side of the web management. Page 128 of 170 (Revised 2012-05-01...
Page 129: Help - Igmp
Help – IGMP Following the IGMP link on the help page, the administrator or user can see some information regarding the configuration options in the IGMP category on the left side of the web management. Page 129 of 170 (Revised 2012-05-01...
Page 130: Help - N-View
Help – N-View Following the N-View link on the help page, the administrator or user can see some information regarding the configuration options in the N-View category on the left side of the web management. Page 130 of 170 (Revised 2012-05-01...
Page 131: Help - N-Ring
Help – N-Ring Following the N-Ring link on the help page, the administrator or user can see some information regarding the configuration options in the N-Ring category on the left side of the web management. Page 131 of 170 (Revised 2012-05-01...
Page 132: Help - N-Link
Help – N-Link Following the N-Link link on the help page, the administrator or user can see some information regarding the configuration options in the N-Link category on the left side of the web management. Page 132 of 170 (Revised 2012-05-01...
Page 133: Help - Cip
Help – CIP Following the CIP link on the help page, the administrator or user can see some information regarding the configuration options in the CIP category on the left side of the web management. Page 133 of 170 (Revised 2012-05-01...
Page 134: Help - Firmware/Config
Help – Firmware/Config Following the Firmware/Config link on the help page, the administrator or user can see some information regarding the configuration options in the Firmware/Config category on the left side of the web management. Page 134 of 170 (Revised 2012-05-01...
Page 135: Help - Rate Limiting
Help – Rate Limiting Following the Rate Limiting link on the help page, the administrator or user can see some information regarding the configuration options in the Broadcast or Multicast Rate Limiting categories on the left side of the web management. Page 135 of 170 (Revised 2012-05-01...
Page 136: Help - User Management
Help – User Management Following the User Management link on the help page, the administrator or user can see some information regarding the configuration options in the User Management category on the left side of the web management. Page 136 of 170 (Revised 2012-05-01...
Page 137: Help - Other
Help – Other Following the Other link on the help page, the administrator or user can see some information regarding other links or categories on the left hand side of the web manager, as above. Page 137 of 170 (Revised 2012-05-01...
Page 138: Cli Commands
Show or set System configuration. Debug Set/Get debug trace level for a given module. Use "cmd ?" to get help about a specific command. N-TRON/Admin> N-TRON/Admin> abcd ? Unknown Command: "abcd" Type "?" for a list of available commands. N-TRON/Admin> logout ? Logout Log out of console interface.
Page 139: Logout
Parameters Examples NOTES (Revised 2012-05-01 Ping Ping a host. … N-TRON/Admin> ? ? Show a list of all commands or get help on a specific command. SYNTAX: ? [cmd] OPTIONS: cmd : The command for which to get help. logout...
Page 140: Show, Add, Or Delete Arl Entries
No. Idx Val Port Mask Port(s) --- --- --- ---------- ---------- 1 0x00000000 (None) 1 0x00000001 TX1 N-TRON/Admin> arl add 00:19:b9:03:aa:79 3 0 1 1 N-TRON/Admin> arl del 00:19:b9:03:aa:79 1 Port(s) 1 00:07:af:ff:b8:00 CPU 1 00:19:b9:03:aa:77 TX3 Page 140 of 170...
Page 141: Configuration Device Operations
Format the configuration device to factory default. -m model Configuration device model number. Valid values are: 1=At32K, 2=At64K, and 3=card. Compare Compare the configuration of the switch to the configuration device. Erase Erase the switch configuration on the configuration device. N-TRON/Factory> cfgdev info Port A:...
Page 142: Show Or Set Cip Configuration
CIP configuration (same as -show parameter). -Cip [-e[nable] | -d[isable] | -show] -Cip -show Show CIP configuration. -Cip [-e[nable] | -d[isable]] Set the CIP status to e(nabled) or d(isabled). N-TRON/Admin> cip -show CIP Configuration: ------------------ Status: Enabled EthIp Interval:...
Page 143: Save Or Reset The Configuration Settings
: 192.168.1.250 Router Mode : Auto Manual Router Ports : (None) IGMP Number of Groups : 1 IGMP Resource Usage % : 1 N-TRON/Admin> igmp –status disabled IGMP Status : Disabled IGMP Version Query Mode : Auto CIP Querier Status...
Page 144: Show Or Set Mirror Configuration
: Disabled Destination Port : TX1 Tx Source Ports : (None) Rx Source Ports : (None) N-TRON/Admin> mirror -status enabled -dp 6 -tx 1,3-5 -rx 1,3,5 Mirror Status : Enabled Destination Port : TX6 Tx Source Ports : TX1, TX3-TX5...
Page 145: Show Or Set N-Ring Configuration
Port Set -------- TX1 / TX2 FX1 / FX2 N-TRON/Admin> nring –mode m –ports 2 Do you Want to Save Changes and Restart the System Now [y/n]? … Nview Show or set N-View configuration. If no parameters are specified, this command will show the N-View configuration (same as -show parameter).
Page 146: Ping A Host
Number of echo requests to send. -w timeout Timeout in milliseconds to wait for each reply. N-TRON/Admin> ping 192.168.1.119 … N-TRON/Admin> ping –n 6 192.168.1.119 … N-TRON/Admin> ping –t 192.168.1.119 … N-TRON/Admin> ping –w 2000 192.168.1.119 Reply from 192.168.1.119: time=970ms Reply from 192.168.1.119: time<10ms...
Page 147: Show Or Set Port Configuration
-uah percent Set the usage alarm high percentage. The range is 0-100. -security state Set the security status for all supported ports to e(nabled) or d(isabled). N-TRON/Admin> port –sd 100f –flow enabled –dp 7 –pvid 2 5 Examples Port Port Admin...
Page 148: Reset The Switch
-rw name Set the Authorized Community Name for SNMP Set requests. -trap name Set the Authorized Community Name for SNMP Traps. N-TRON/Admin> snmp –ro users IP Address - Trap Stn.#1 IP Address - Trap Stn.#2 IP Address - Trap Stn.#3 IP Address - Trap Stn.#4...
Page 149: Show Or Clear The Last System Error
+ Boot Loader: BL 2.0.5.1 (0x02000501) + OS Version: 3.2.1 + Build Date: 8 2009 at 15:10:57 + Copyright: Copyright (c) 2008-2009 N-TRON Corp. All rights reserved. + Processor: 66 MHz (66000000) + SDRAM Size: 16 MB + Flash Size:...
Page 150: Set Or Show The System Ip Configuration
: 255.255.255.0 Fallback Gateway : 192.168.1.1 Press <ENTER> to Save Changes and Restart the System Now … N-TRON/Admin> sysip -i 192.168.2.119 -s 255.255.252.0 -g 192.168.1.1 IP Configuration Mode : Static Static IP Address : 192.168.2.119 (has been changed) Static Subnet Mask : 255.255.252.0 (has been changed)
Page 151: Show Or Set System Configuration
Changes have been made that have not been saved. … A switch name may only contain alphanumeric, space, ‘:’, ‘-‘, ‘_’, and ‘#’ characters, and may not begin with a number, space, or underscore. A name with embedded space characters must be enclosed in quotes.
Page 152: Vlan Addition And Deletion Example
VLAN Addition and Deletion Example The screen capture below is the factory default VLAN configuration. Clicking on the “Modify” button allows one to add a new VLAN: When creating a new VLAN, a numeric ID is required, Name is entered. Note that N-Ring VLAN is a reserved name with a special meaning.
Page 153 The result of add is a “New VLAN”. In this case, it does not overlap the “Default VLAN” ports. Page 153 of 170 (Revised 2012-05-01...
Page 154 The ports of ”New VLAN” may be added back to “Default VLAN” to create overlapping VLANs. Note: If there are multiple ports on different VLANs, the 710FX2 will apply the static multicast address to the lowest VLAN-ID that is associated with one of the ports assigned to the static multicast address. If the lowest VLAN-ID contains all the ports assigned to the static multicast address (an umbrella VLAN), it will function for all those ports with no problems.
Page 155 Page 155 of 170 (Revised 2012-05-01...
Page 156 And the “New VLAN” is removed. Note that the new configuration of the switch must be saved if the configuration must survive a power cycle. Page 156 of 170 (Revised 2012-05-01...
Page 157: Vlan Configuration Examples
Broadcast, Multicast, and Unicast frames in one VLAN will not interfere with another isolated VLAN group. The examples in this section are shown as configured on a 708TX switch, but the 710FX2 series may be configured similarly with the additional ports.
Page 158: Example 2 - Basic Understanding Of Tagged Vlans (Admit - Tagged Only)
Example 2 – Basic understanding of tagged VLANs (Admit – Tagged Only) Receiving Tagged VID Port # in packet Untagged VID 2 VID 4 VID 2 Untagged VID 1 VID 1 VID 4 (Revised 2012-05-01 Destination Transmitting Address Port #s MAC on port TX2 MAC on port TX2 MAC on port TX2...
Page 159: Example 3 - Basic Understanding Of Tagged Vlans (Admit - All)
Example 3 – Basic understanding of tagged VLANs (Admit – All) Receiving Tagged VID Destination Port # in packet Address Untagged MAC on port TX2 VID 2 MAC on port TX2 VID 4 MAC on port TX2 VID 2 Unknown MAC Untagged Unknown MAC VID 1...
Page 160: Example 4 - Basic Understanding Of Hybrid Vlans
Example 4 – Basic understanding of Hybrid VLANs Receiving Tagged VID Port # in packet Untagged Untagged VID 4 VID 4 VID 2 Untagged Untagged VID 4 VID 4 VID 2 VID 2 (Revised 2012-05-01 Destination Transmitting Address Port #s MAC on port TX2 MAC on port TX3 MAC on port TX2...
Page 161: Example 5 - Basic Understanding Of Overlapping Vlans
Example 5 – Basic understanding of Overlapping VLANs Receiving Tagged VID Port # in packet Untagged Untagged VID 4 VID 4 Untagged Untagged VID 2 or 3 Untagged Untagged Untagged Untagged VID 2 or 3 (Revised 2012-05-01 Destination Transmitting Address Port #s MAC on port TX2, VID=4...
Page 162: Example 6 - Basic Understanding Of Vlans With Multicast Filtering
Untagged Untagged Note: If there are multiple ports on different VLANs, the 710FX2 will apply the static multicast address to the lowest VLAN-ID that is associated with one of the ports assigned to the static multicast address. If the lowest VLAN-ID contains all the ports assigned to the static multicast address (an umbrella VLAN), it will function for all those ports with no problems.
Page 163: Key Specifications (710Fx2)
KEY SPECIFICATIONS (710FX2) Switch Properties Number of MAC Addresses: Aging Time: Latency Type: Switching Method: Case Dimensions Height: Width: Depth: Weight (max): Din-Rail mount: Electrical Redundant Input Voltage: Input Current (max): N-TRON Power Supply Environmental Operating Temperature: -40°C to 70°C Storage Temperature: -40°C to 85°C...
Page 164 100 Mb Fiber Transceiver Characteristics Fiber Length 2km* TX Power Min -19dBm -31dBm RX Sensitivity Max Wavelength Min/Max 1310nm * Multimode Fiber Optic Cable ** Singlemode Fiber Optic Cable Regulatory Approvals: Safety: Suitable for use in Class I, Division 2, Groups A, B, C and D Hazardous Locations, or Nonhazardous Locations only.
Page 165: Key Specifications (710Fx2-Hv)
KEY SPECIFICATIONS (710FX2-HV) Switch Properties Number of MAC Addresses: 8,000 Aging Time: Programmable Latency Type: 2.6 µs Switching Method: Store & Forward Case Dimensions Height: 4.3” / 10.8 cm Width: 3.2” / 8.2 cm Depth: 4.6” / 11.7 cm Weight (max):...
Page 166 100 Mb Fiber Transceiver Characteristics Fiber Length 2km* TX Power Min -19dBm -31dBm RX Sensitivity Max Wavelength Min/Max 1310nm * Multimode Fiber Optic Cable ** Singlemode Fiber Optic Cable EMI, Immunity and Environmental Compliance IEC 61850-3 Electric Utility Substations IEEE 1613 Electric Utility Substations EMC Directive 2004/108/EC EN 61000-6-2 (Immunity) NEMA TS 2 Traffic Control Equipment...
Page 167: Appendix A. Xml Settings File Example
Appendix A. XML Settings File Example <!-- Overview of XML settings for N-TRON switches <!-- XML settings can be downloaded to a switch to configure the switch. XML settings cover a subset of the settings available through a web browser.
Page 168 </IPConfiguration>  <!-- A list of logon accounts (5 maximum) to add to the switch. <Users mode="keep or delete"> <!-- mode=delete - delete existing accounts before adding accounts (default) <!-- mode=keep - do not delete existing accounts before adding accounts <!--...
Page 169  <!-- 1 to maximum port for switch <!-- Name of port on switch <!-- Example of a MAC with no delimiters, valid on all ports.
Page 170: N-Tron Limited Warranty
N-TRON, Corp. warrants to the end user that this hardware product will be free from defects in workmanship and materials, under normal use and service, for the applicable warranty period from the date of purchase from N-TRON or its authorized reseller. If a product does not...

N-Tron 710FX2 User Manual & Installation Manual

Quick Links

Need help?

Questions and answers

Related Manuals for N-Tron 710FX2

Summary of Contents for N-Tron 710FX2

Table of Contents
