First Alert FA168C Programming Manual page 7

CONFIGURABLE ZONE TYPE OPTIONS (*182-*185)
182 CONFIGURABLE ZONE TYPE 90
183 ZONE TYPE 90 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
184 CONFIGURABLE ZONE TYPE 91
185 ZONE TYPE 91 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
KEYPAD OPTIONS (*190-*196 NOTE: Options for keypad address 16 are set by the factory and cannot be changed.)
NOTE: Each keypad must be assigned a unique address. Keypads programmed with the same address will give
unpredictable results.
190 KEYPAD 2 ADDRESS 17
191 KEYPAD 3 ADDRESS 18
192 KEYPAD 4 ADDRESS 19
193 KEYPAD 5 ADDRESS 20
194 KEYPAD 6 ADDRESS 21
195 KEYPAD 7 ADDRESS 22
196 KEYPAD 8 ADDRESS 23
197 EXIT TIME DISPLAY INTERVAL
198 DISPLAY PARTITION NUMBER
(for Alpha Display Keypads)
199 ECP FAIL DISPLAY
1 2 3 4
Enter the appropriate value for each entry, 1-10, based on the charts provided on
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
90 ALARM ID: XXX
TROUBLE ID: XXX
1 2 3 4
Enter the appropriate value for each entry, 1-10, based on the charts provided on
next page. Each entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
91 ALARM ID: XXX
TROUBLE ID: XXX
[0] [0]
Partition/ Sound
Enable
FA168C: enter partition
FA148CP: 1 = enable
0 = disable
[0] [0]
†
Part./Enable Sound
[0] [0]
†
Part. /Enable Sound
[0] [0]
†
Part. /Enable Sound
[0] [0]
†
Part. /Enable Sound
[0] [0]
†
Part. /Enable Sound
[0] [0]
†
Part. /Enable Sound
[0]
[0]
[0]
– 7 –
5 6 7 8
Enter the desired 3-digit Contact ID® report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
5 6 7 8
Enter the desired 3-digit Contact ID® report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
Partition: 0 = keypad disabled; 1-3 = part. no. (3 = com)
Sound: 0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime
beeps
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
See field ∗190 for entries.
† FA168C: enter partition
FA148CP: 1 = enable; 0 = disable
0 = no display; 1-5 = seconds between display refresh
0 = no; 1 = yes (partition no. appears on Alpha Display)
0 = 3-digit display ("1" + device address)
1 = 2-digit fixed-display as "91"
9 10
9 10
