First Alert FA168C Programming Manual page 3

Entry of a number other than one specified will give unpredictable results. Values shown in brackets are factory defaults.
Entries shown in dashed boxes indicate partition entries for FA168C only (not applicable for FA148CP).
Field Function
SYSTEM SETUP ( 20– 29)
20 INSTALLER CODE
21 QUICK ARM ENABLE
22 RF JAM OPTION
23 FORCED BYPASS
24 RF HOUSE ID CODE
26 CHIME BY ZONE
27
X–10 HOUSE CODE
28 ACCESS CODE FOR
4285/4286 PHONE MODULE
29 LONG RANGE RADIO OUTPUT
ZONE SOUNDS AND TIMING ( 31 – 39)
31 ONE AUDIBLE ALARM PER ZONE
32 FIRE ALARM SOUNDER TIMEOUT
33 ALARM SOUNDER TIMEOUT
34 EXIT DELAY
35 ENTRY DELAY #1 (zone type 01)
36 ENTRY DELAY #2 (zone type 02)
37 AUDIBLE EXIT WARNING
38 CONFIRMATION OF ARMING DING
39 POWER UP IN PREVIOUS STATE
DIALER PROGRAMMING ( 40 – 42)
Enter the number of digits shown. Do not fill unused spaces. Enter 0–9; #+11 for ' '; #+12 for '#'; #+13 for a 2-second pause. If fewer than the
maximum digits entered, exit the field by pressing [ ] and next desired field number.
40 PABX ACCESS CODE
41 PRIMARY PHONE No.
42 SECOND PHONE No.
352*5$00,1*)250
Data Entries
| |
Part. 1 Part.2
[0]
Part. 1 Part. 2
|
Part. 1 Part. 2 Common
[0]
[0]
| [00]
(Partition 1 only)
[0]
[0]
[0]
[1]
|
Part. 1 Part. 2
|
Part. 1 Part. 2
|
Part. 1 Part. 2
Part. 1 Part. 2
Part. 1 Part. 2
[1]
| |
Enter up to 6 digits. To clear entries from field, press 40 .
| | | | | | |
Enter up to 20 digits. To clear entries, press 41 .
| | | | | | |
Enter up to 20 digits. To clear entries, press 42 .
Programmable Values
4 digits, 0–9
| [4112]
0 = no; 1 = yes
[0,0]
0 = no RF Jam detection; 1 = send RF Jam report
UL: must be 1 if wireless devices are used
0 = none UL: must be "0"
[0,0]
1 = bypass open zones
00 = disable all wireless keypad usage
| |
01–31 = using 5827, 5827BD or 5804BD keypad
[00,00,00]
0 = no; 1 = yes (select zones to chime on zone list 3,
using *81 Menu mode)
0 = A; 1 = B, 2 = C, 3 = D, 4 = E, 5 = F, 6 = G,
7 = H, 8 = I, 9 = J, #10 = K, #11 = L, #12 = M, #13 = N,
#14 = O, #15 = P UL: not for fire or UL installations
00 = disable; 1st digit: enter 1–9; 2nd digit: enter # + 11
for " ", or # + 12 for "#".
UL: must be "00" for UL Commercial Burg. installations
0 = disable; 1 = enable
0 = no UL: must be "0"; 1 = yes
0 = sounder stops at timeout;
1 = no sounder timeout UL: must be "1" for fire install.
0 = none; 1 = 4 min; 2 = 8 min; 3 =12 min;
4 = 16 min; UL: minimum "1" (4 min.)
00–99 = seconds of exit delay time for each partition
| [70,70]
Common zones use same delay as partition 1.
00–99 = seconds of entry delay #1 time for each
| [30,30]
partition; UL: 45 seconds max.
Common zones use same delay as partition 1.
00–99 = entry delay #2 time for each partition;
| [60,60]
UL: 60 seconds max.
Common zones use same delay as partition 1.
0 = no; 1 = yes
[1,1]
0 = no; 1 = yes (wired keypads and RF)
[0,0]
2 = yes, RF only
0 = no; 1 = yes UL: must be "1"
| | |
| | | | | | | |
| | | | | | | |
– 3 –
| | | |
| | | |
