Product View; Port Connections - First Data FD200Ti Quick Setup Manual

Getting to know the FD200

Port connections

The pictures show an FD200
of the FD200
PIN pads and contactless readers.
Phone (blue)
➔
For dial-up transactions using a phone line.
USB (gray) and Serial (green)
➔
You may connect additional peripherals to the USB or COM
ports, such as the FD-10 or FD-10C PIN Pads, and/or the
FD-30 PIN Pad or Vivopay
MagTek
Ethernet (yellow)
➔
For Internet transactions using Cable or DSL.
Note: This is a Class I LED product. Some peripherals require a separate power source.
Before connecting a USB device or similar device, remove the power cable connector
from the terminal's power port.
4
COM
terminal enable you to add peripherals such as
Ti
MiniMICR Check Reader.
®
USB ETHERNET PHONE
