MultiModemDSVD User Guide
Terse
62
63
64
66
67
69
70
77
78
79
80
81
84
91
150
151
152
153
154
155
156
157
158
159
160
161
162
165
166
167
168
169
170
171
172
173
174
175
176
177
180
180
181
181
182
182
183
183
184
184
Multi-Tech Systems, Inc.
4 AT Commands, S-Registers, and Result Codes
Verbose
CONNECT 24000
CONNECT 26400
CONNECT 28800
COMPRESSION CLASS 5 Connected with MNP Class 5 data compression
COMPRESSION V.42 bis Connected with V.42 bis data compression
COMPRESSION NONE
PROTOCOL NONE
PROTOCOL LAPM
CARRIER 31200
CARRIER 33600
PROTOCOL ALT
PROTOCOL ALT-CELLULAR Connected in MNP 10 mode
CONNECT 33600
CONNECT 31200
CARRIER 32000
CARRIER 34000
CARRIER 36000
CARRIER 38000
CARRIER 40000
CARRIER 42000
CARRIER 44000
CARRIER 46000
CARRIER 48000
CARRIER 50000
CARRIER 52000
CARRIER 54000
CARRIER 56000
CONNECT 32000
CONNECT 34000
CONNECT 36000
CONNECT 38000
CONNECT 40000
CONNECT 42000
CONNECT 44000
CONNECT 46000
CONNECT 48000
CONNECT 50000
CONNECT 52000
CONNECT 54000
CONNECT 56000
CONNECT 28000
CARRIER 28000
CONNECT 29333
CARRIER 29333
CONNECT 30667
CARRIER 30667
CONNECT 33333
CARRIER 33333
CONNECT 34667
CARRIER 34667
Description
Connected at 24000 bps
Connected at 26400 bps
Connected at 28800 bps
Connected without data compression
Connected without any protocol
Connected in V.42 LAPM mode
56000 bps data carrier detected
33600 bps data carrier detected
Connected in MNP mode
Connected at 33600 bps
Connected at 31200 bps
32000 bps data carrier detected
34000 bps data carrier detected
36000 bps data carrier detected
38000 bps data carrier detected
40000 bps data carrier detected
42000 bps data carrier detected
44000 bps data carrier detected
46000 bps data carrier detected
48000 bps data carrier detected
50000 bps data carrier detected
52000 bps data carrier detected
54000 bps data carrier detected
56000 bps data carrier detected
Connected at 32000 bps
Connected at 34000 bps
Connected at 36000 bps
Connected at 38000 bps
Connected at 40000 bps
Connected at 42000 bps
Connected at 44000 bps
Connected at 46000 bps
Connected at 48000 bps
Connected at 50000 bps
Connected at 52000 bps
Connected at 54000 bps
Connected at 56000 bps
Connected at 28000 bps (V.90 mode)
28000 bps data carrier detected (V.90 mode)
Connected at 29333 bps (V.90 mode)
29333 bps data carrier detected (V.90 mode)
Connected at 30667 bps (V.90 mode)
30667 bps data carrier detected (V.90 mode)
Connected at 33333 bps (V.90 mode)
33333 bps data carrier detected (V.90 mode)
Connected at 34667 bps (V.90 mode)
34667 bps data carrier detected (V.90 mode)
51
