1. Remove cardboard carton
from metal frame.
DR125 Set-up Instructions

Removal from crate

1
2. Remove wire straps
and foam covering from
handlebar.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DR125 and is the answer not in the manual?

Questions and answers

Summary of Contents for Baja motorsports DR125

  • Page 1 DR125 Set-up Instructions Removal from crate 1. Remove cardboard carton from metal frame. 2. Remove wire straps and foam covering from handlebar.
  • Page 2 Removal from crate 3. Remove wire straps from front forks and rear swing arm. Tool Kit 4. Remove bolts from both sides of metal frame. 5. Remove bolts holding metal Remove foam covering and tool kit frame to handlebar bracket.
  • Page 3 Handlebar Assembly 6. Install handlebars by handlebar clamp provided. Torque bolts to 25Nm (18.5ft.lb.)
  • Page 4 Gas and Oil 7. Fill engine with correct amount of oil. Refer to owners manual for oil types and quantity. 8. Fill gas tank as specified in owners manual. Oil Cap !!WARNING!! 9. Refer to owners manual for This motorcycle may be shipped with packing oil proper starting instructions.
