SPECIFICATIONS

Type
Model name
Power source
Available voltage range
Starting current
Air flow rate
Fan
Type × Q'ty
Motor output
Sound pressure level
Heat exchanger type
Type × Q'ty
Compressor
Motor output
Refrigerant
Refrigerant oil
Enclosure
Net
Dimensions
( H × W × D)
Gross
Net
Weight
Gross
Size
Connection pipe Method
Max. length
Max. height difference
Operation range
Note :
Specifications are based on the following conditions.
Cooling : Indoor temperature of 27 °CDB / 19 °CWB.and outdoor temperature of 35 °CDB / 24 °CWB.
Heating : Indoor temperature of 20 °CDB / 15 °CWB.and outdoor temperature of 7 °CDB / 6 °CWB.
Pipe length : 5 m, Height difference : 0 m.(Outdoor unit - Indoor unit)
The maximum current is the maximum value when the operated within the operation range(temperature).
A
Cooling
3
m /h
Heating
W
Cooling
dB(A)
Heating
Dimensions (H × W × D)
mm
Fin pitch
Rows x Stages
Pipe type
Fin type
W
Type
Charge g
Type
Material
Colour
mm
kg(lb.)
Liquid
mm
Gas
m
Cooling
°C
Heating
- (02 - 01) -
INVERTER COOLING & HEATING
AOÛR09LKC
230V~ 50Hz
198-264V~ 50Hz
4.8
1,720
1,510
Propeller fan×1
40
45
45
650 × 504 × 18.2
1.3
1 × 24
Copper
Aluminium
Rotary×1
500
R410A
650
POE(VG74)
Steel
BEIGE
Approximate colour of MUNSELL 10YR 7.5/1.0
540 × 660 × 290
611 × 797 × 401
22(48)
25(55)
Φ6.35 (Φ 1/4 in.)
Φ9.52 (Φ 3/8 in.)
Flare
20 (chargeless:15)
15
18 to 43
-15 to 24
AOÛR12LKC
5.2
1,830
1,600
50
50
642 × 504 × 36.4
1.4
2 × 24
750
800
540 × 660 × 290
611 × 797 × 401
29(64)
32(71)
