Door Swing

For models that are installed adjacent to a wall, 1/4"
(6 mm) clearance is recommended from wall on hinge side
to allow the door to open 90°. Allow for additional space
for any knobs or pulls installed on the integrated panel/
frame.
Units have a zero clearance when installed adjacent to
cabinets.
Wall
1/4" (6 mm)
90°
Door Swing
Space Required
For any Knobs or Pulls
