- Page 1 QUICK START GUIDE Modular 3000 Series 3018 CLR 115 V / 60 Hz • •...
- Page 2 1. U-Line Customer Care must be contacted immediately at +1.800.779.2547. 2. Service or repairs performed on the unit without prior written approval from U-Line is not permitted. If the unit has been altered or repaired in the field without prior written approval from U-Line, claims will not be eligible.
-
Page 3: Table Of Contents
QUICK START GUIDE u-line.com Contents Model List Safety and Warning Environmental Requirements Electrical Water Hookup Drain Door Swing General Installation Integrated Panel Installation Control Quick Guide First Use Sabbath Mode Warranty... -
Page 4: Model List
QUICK START GUIDE u-line.com Model List This guide provides the basics to get you started. Looking for more information? Visit u-line.com to view detailed User Guides for all U-Line products. Clear Ice Machines U-3018CLRS-00B U-3018CLRS-40B U-3018CLRINT-00B U-3018CLRINT-40B Visit http://www.u-line.com/product-literature/userguides or scan this... -
Page 5: Safety And Warning
QUICK START GUIDE u-line.com Safety and Warning Environmental Requirements This model is intended for indoor/interior applications only NOTICE and is not to be used in installations that are open/ Please read all instructions before installing, exposed to natural elements. operating, or servicing the appliance. -
Page 6: Electrical
QUICK START GUIDE u-line.com Electrical Water Hookup PREPARE PLUMBING WARNING Please use the braided stainless steel water supply line which comes attached. The water line is fitted with a SHOCK HAZARD — Electrical Grounding standard 1/4" (6.35 mm) compression fitting. - Page 7 QUICK START GUIDE u-line.com 4. Turn on water and check for leaks. CAUTION 5. Route water supply line in cable clamp and secure with Do not use any plastic water supply line. The line screw. is under pressure at all times. Plastic may crack or rupture with age and cause damage to your home.
-
Page 8: Drain
DRAIN CONNECTION CAUTION With Trap and Vent Proper Drain If your U-Line unit did not come with a factory installed drain pump you must use a gravity A gravity drain may be used if: style drain connection. For assistance in Drain line has at least a 1"... - Page 9 (Optional Hook-Up) requirements for a gravity drain, you may have ordered a pre-installed U-Line P60 drain pump. Waste If you need to install a P60 drain pump into your unit, see Valve DRAIN PUMP section in the User Manual.
-
Page 10: Door Swing
QUICK START GUIDE u-line.com Door Swing Wall For Integrated models that are installed adjacent to a wall, 1/4" (6 mm) 1/4" (6 mm) clearance is recommended from wall on hinge side to allow the door to open 90°. Allow for additional space for any knobs or pulls installed on the integrated panel/frame. -
Page 11: General Installation
QUICK START GUIDE u-line.com General Installation INSTALLATION 1. Plug in the power/electrical cord. 1. Use a level to confirm the unit is level. Level 2. Gently push the unit into position. Be careful not to should be placed along entangle the cord or water and drain lines. - Page 12 Clamp Integrated Panel Integrated Panel clamps. A robust tape may also be 11.Remove clamps from door. used. U-Line recommends the use of bar clamps NOTICE Door/Drawer to secure the panel If panel requires additional adjustment after to the door.
-
Page 13: Control Quick Guide
Service menu Press and hold for 5 seconds Press to scroll through menu. First Use All U-Line controls are preset at the factory. Initial startup ICE CUBE THICKNESS ADJUSTMENT requires no adjustments. NOTICE Ice thickness adjustment should only be made NOTICE one increment at a time. - Page 14 QUICK START GUIDE u-line.com The ice cube thickness is factory set for best overall performance. The factory setting “0” is designed to THINNER BRIDGE THICKER BRIDGE maintain an ice bridge of approximately 1/16" to 1/8" DEEPER DIMPLE SHALLOWER DIMPLE (1.6 mm to 3.2 mm) under normal conditions, resulting in a dimple of approximately 1/4"...
-
Page 15: Sabbath Mode
U-Line further warrants the sealed system (consisting of the compressor, condenser, evaporator, hot gas bypass valve, dryer, and connecting tube) in each U-Line product to be free from defects in materials and workmanship for a period of five years from the date of Select installation. - Page 16 ARE DISCLAIMED. U-Line’s sole liability, and your exclusive remedy, under this warranty is set forth in the paragraphs above. U-Line shall have no liability 5. U-Line products are designed to operate in ambient whatsoever for any incidental, consequential, or temperatures between 50°F and 100°F unless special damages arising from the sale, use, or otherwise noted in the product manual.
