Summary of Contents for Cerio ow-310n2
- Page 1 CERIO Corporation OW-310N2 1000mW eXtreme Power 11N 300Mbps Outdoor Access Point Quick Installation Guide...
- Page 2 Flow Bandwidth support 802.11n of up to 300Mbps(Tx), 300Mbps(Rx) link rate. And Build in lightning arrester (15kV ESD) OW-310N2 may connect to the WiFi mesh or WDS infrastructure and provides the subscriber with an Ethernet connection for a local access .to extend the range and increase the performance of our wireless network.
-
Page 3: Package Content
CD Manual Warranty Card 3. Panel Function Description There is several LED indicators on the front of the OW-310N2. Please refer to the definitions below : (1) The Ethernet connect of LAN Port (2) The LED indicator of LAN Port... - Page 4 Support IEEE802.1d Spanning Tree Integragted IGMP v1/v2/v3 snooping functions and Support Web management and SNMP MIB-II Built-in software interface allows for communicating with CERIO AM-Series AP Management WLAN Switch or Access Controller of network management servers. Networking ...
- Page 5 IEEE 802.11i Preauth (PMKSA Cache ) IEEE 802.11h - TPC(Transmission Power Control) IEEE 802.11d -Multi country roaming Channel Bandwidth setting : 20MHz or 20/40MHz HT Tx/Rx Stream selection : 1 or 2 Short Slot support Authentication/Encryption (Wireless Security) ...
-
Page 6: Software Configuration
IP Segment Set-up for Administrator's PC/NB Set the IP segment of the administrator's computer to be in the same range as OW-310N2 for accessing the system. Do not duplicate the IP Address used here with IP Address of OW-310N2 or any other device within the network. - Page 7 In “Local Area Connection Properties” window, select “Internet Protocol (TCP/IP)” and click on Properties button.
- Page 8 Select “Use the following IP address”, and type in Launch Web Browser Launch as web browser to access the web management interface of system by entering the default IP Address, http://192.168.2.254, in the URL field, and then press Enter.
- Page 9 System Login System Overview page will appear after successful login.
-
Page 10: Wizard Setup
The setup wizard is designed to be an 'easy to use' utility that allows quick modification of the OW-310N2 UI Web-based GUI interface settings . The wizard should take no longer than 5 minutes to use. Please be aware that the wizard doesn't give full access to all the setup options in OW-310N2 in/Outdoor PoE Bridge Router AP. - Page 11 2) LAN setup Here are the instructions for setup your OW-310N2 local LAN IP address and netmask. If you don’t want change the default OW-310N2 IP 192.168.2.254 address, please keep the default and go next setup. 3) DNS If you don’t know for your ISP correct DNS IP address, Please click “No...
- Page 12 4) Wireless Setup If you are not sure which setting to choose, Please then the default setting to best WiFi smart channel judgment for auto channel, and adjust the output power to level9 (100%) Extended service set ID indicated the SSID which the clients used to connect to the access point ESSID.
- Page 13 6) Finishing Wizard Click Finish button to save your setting . please wait till completion of the reboot process.
