HEAT LAMP KIT INSTALLATION*
*IMPORTANT: Dual blower and heat lamps may only be used together in 36" and 42" models.
30" models will only accommodate one or the other, not both at the same time.
1. Remove nuts from each of the (4) screws
around the bottom panel. Remove bottom
panel.
3. Place heat lamp housings over the (4) pre-
threaded screw posts inside the hood. Attach
with screws provided.
5. Plug heat lamp wire from hood into wire from
heat lamp housing.
2. Replace bottom panel with heat lamp bottom
panel. Re-attach screws and nuts.
4. Install heat lamp wire cover over wire from heat
lamp housing and screw shut. Repeat for each
heat lamp housing.
Rocker Switches
6. Install heat lamp bulbs and operate heat lamps
using rocker switches located in each corner
behind the halogen bulbs.
