Tieline Merlin User Manual page 277

3. Select Session Type [Sessionless] > Select Dial Route [None] > Number of B Channels
[Choose 1B or 2B] > Algorithm [Choose G.722 , MP2 Mono or MP2 Stereo (Note: select
48kHz sample rate for MP2)].
4. Navigate to a Destination (e.g. Dest 1 or Dest 2) and press the
turn. Enter the number for each B channel you want to dial and press the
which B channel will dial using that number and press the
5. Navigate down to Auto Reconnect and press the
Disabled. Note: This is normally enabled on the dialing codec only.
6. Navigate down to Save as Program and press the
program.
7. Navigate down to Module Configuration and press the
8. Select the ISDN module you want to configure and press the
9. Configure the following settings:
· Accept > Voice and Data
· Network > Check with your Telco (EU-ETSI in Australia; Europe & most countries outside
North America; [US Nat] is the most common in the US, but check with your Telco).
· Line Type > Check with your Telco and select either Point-to-Multi (point-to-multipoint) or
Point-to--Point (point-to-point).
· DN/MSN > Enter the "SPID" and "DN" numbers if required in your region, e.g. a SPID is
normally required in the US.
10. Navigate up to Apply Settings and press the
Dialing from the Tieline Codec
Program Dialing
1. If you have saved the ISDN program as previously instructed, press the HOME
return to the Home screen and select Connect > Programs.
2. Select the saved program you want to load and press the
3. Select Load and press the
4. Press the CONNECT
Ad Hoc Dialing
1. If you haven't save the program but have entered the dialing numbers and other settings, press
the HOME
© Tieline Pty. Ltd. 2015
button to load the program.
button to dial the ISDN program connections.
button to return to the Home screen and select Connect > ISDN > Connect.
Merlin User Manual v1.5
button to select each one in
button.
button to toggle between Enabled and
button to save these settings as a
button.
button.
button.
button.
277
button, then select
button to
