2. Select the saved program you want to load and press the
3. Select Load and press the
4. Press the CONNECT
Ad Hoc Dialing
1. If you haven't save the program but have entered the dialing numbers and other settings, press
the HOME
2. Press the
After dialing successfully "FRAMED" should illuminate on the CDQ Prima screen. Tieline codecs
also support 32kHz sampling.
Important Note: Configure ISDN Answer Config settings in the codec before attempting
to dial from the Equinox to the Tieline codec. Select the following settings in the Tieline
codec in one of the Configs (see
Making a Mono Call from the CDQ Prima Codec
1. Press the "Dial" button on the front panel of the codec.
2. Navigate right using the "Enter" button and select "1".
3. Enter the number to dial using the numeric keypad.
4. Press the "Enter" button (bottom arrow) and the screen will briefly display "Working", then
"Connect" and then the green "Framed" light should illuminate on the front panel.
Making a Stereo Call from the CDQ Prima Codec
1. Press the "Dial" button on the front panel of the codec.
2. Use the "Enter" button and select "Both".
3. Enter the first number to dial using the numeric keypad.
4. Press the "Enter" button (bottom arrow) and the screen will briefly display "Dialling line 1" and
then "Connect".
5. Enter the second number to dial using the numeric keypad and press the "Enter" button (bottom
arrow).
6. The screen will briefly display "Dialling line 2", then "Connect" and then the green "Framed" light
should illuminate on the front panel.
Important Note:
When connecting in stereo, the Prima expects both B channel dials to occur within 5
seconds. This can be performed by the Tieline codec.
It has also been noted that the CDQ Prima codec will not connect if no audio is present
when dialing. It may connect Prima > Tieline, but not Tieline > Prima. If audio is present,
the codec should connect and stay connected even if audio is removed subsequently. The
J-Stereo light on the Prima may also flash when in this mode.
Ideally, have audio connected when dialing and the codec will frame immediately after the
first dial and then dial the second B channel quickly afterwards.
© Tieline Pty. Ltd. 2015
button to load the program.
button to dial the ISDN program connections.
button to return to the Home screen and select Connect > ISDN > Connect.
button to dial using the settings previously entered.
· May bond.
· Sessionless.
· Algorithm: MP2 Mono, MP2 J-Stereo.
· Sample Rate: 48kHz
Merlin User Manual v1.5
button.
ISDN Answering Configuration
273
for more detail):
