Tieline Merlin User Manual page 275

9. Configure the following settings:
· Accept > Voice and Data
· Network > Check with your Telco (EU-ETSI in Australia; Europe & most countries outside
North America; [US Nat] is the most common in the US, but check with your Telco).
· Line Type > Check with your Telco and select either Point-to-Multi (point-to-multipoint) or
Point-to--Point (point-to-point).
· DN/MSN > Enter the "SPID" and "DN" numbers if required in your region, e.g. a SPID is
normally required in the US.
10. Navigate up to Apply Settings and press the
Dialing from the Tieline Codec
Program Dialing
1. If you have saved the ISDN program as previously instructed, press the HOME
return to the Home screen and select Connect > Programs.
2. Select the saved program you want to load and press the
3. Select Load and press the
4. Press the CONNECT
Ad Hoc Dialing
1. If you haven't save the program but have entered the dialing numbers and other settings, press
the HOME
2. Press the
Important Note: If you select different algorithm settings on each codec and dial from the
Tieline codec, the connection will be unsuccessful and the CONNECTED LED on the front
panel of the Tieline codec will continuously flash. Adjust the algorithm settings and
attempt to reconnect.
Dialing from the Mayah Sporty
Important Note: Configure ISDN Answer Config settings in the Tieline codec before
attempting to dial from the Equinox to the Tieline codec. Select the following settings in
the Tieline codec in one of the Configs (see
detail):
1. Press "F4 ESC" to return to the home screen.
2. Press "F2 Codec", then "F1 Connect", then "F3 Direct".
3. Use the navigation buttons to select "dial" and press the "OK" button to dial all B-channels.
© Tieline Pty. Ltd. 2015
button to load the program.
button to dial the ISDN program connections.
button to return to the Home screen and select Connect > ISDN > Connect.
button to dial using the settings previously entered.
· May bond.
· Sessionless.
· Algorithm: G.722, MP2 Mono, MP2 Stereo, MP2 J-Stereo or E apt-X Mono or
Stereo.
· Sample Rate: 32kHz or 48kHz
Merlin User Manual v1.5
button.
button.
ISDN Answering Configuration
275
button to
for more
