- Page 1 2 0 1 7 D O M A N E E S E R V I C E M A N U A L...
- Page 3 2016 DOMANE Rear IsoSpeed cover drive side Pivot bolt Bearing 19mm x 10mm x 5mm Pivot locating washer Rear IsoSpeed cover non drive side m5 x .08 x 24mm Flat washer m5 x 10 x 1.0mm Button head screw m5 x 10 Curved washer m5 x 18od x 1.5thck x r11 Spring lock washer...
- Page 4 Front Isospeed lower cover Elliptical nut, m8 x1.0 x 6mm Front Isospeed decoupler Washer, 16od x 10.10id x 1.125 length Screw, m8 x 1.0 x 14mm, 4mm hex Pre-load spacer Headset bearing Headset compression ring Front Isospeed headtube cover Headset top cap...
- Page 5 Congratulations and mountain bikes in Trek’s lineup. If you’re reading this assembly manual, But Trek never stops developing. With the odds are you’re about to lay hands on the all-new Domane SLR, we set out to devise a smoothest, most efficient race bike Trek has solution that would both expand the range ever created.
-
Page 6: Table Of Contents
TABLE OF CONTENTS Introduction 1. IsoSpeed seat decoupler and seat mast How it works Installing the seat mast Installing the Adjustable Seatmast Slider and securing the seat mast. Adjusting the ride 2. Front IsoSpeed Installing the front IsoSpeed system 3. Installing the fork 4. Installing the Di2 5. Installing the shift cables Securing the rear derailleur Securing the front derailleur 6. Installing fenders Securing the rear fender... -
Page 7: Isospeed Seat Decoupler And Seat Mast
ISOSPEED SEAT DECOUPLER AND SEAT MAST TOOLS AND MATERIALS REQUIRED: • 4 mm Hex wrench • Torque wrench • 5 mm Hex Wrench • Grease • 6 mm Hex Wrench • Loctite 242 Rear IsoSpeed cover drive side Pivot bolt Bearing 19mm x 10mm x 5mm Pivot locating washer... -
Page 8: Installing The Seat Mast
INSTALLING THE ISOSPEED SEAT DECOUPLER AND SEAT MAST Align the bore holes in the seat mast with the Installing the seat mast opening in the frame. Apply grease to the bores of the seat mast as well as the bores on the frame. Pass a pivot bolt assembly from Step 3 through the bore [hole] and thread it into the IsoSpeed axle. - Page 9 INSTALLING THE ISOSPEED SEAT DECOUPLER AND SEAT MAST On the non-drive side, insert the other pivot bolt Repeat the tightening process with the torque assembly from step 3 through the bore hole and wrench on the non-drive side. thread into the axle. Insert 5mm hex wrenches into both pivot bolts and slowly turn each clockwise.
-
Page 10: Installing The Adjustable Seatmast Slider And Securing The Seat Mast
INSTALLING THE ISOSPEED SEAT DECOUPLER AND SEAT MAST Installing the Adjustable Seatmast Insert the m5 nut into the hole on the seat mast, making sure the vertical alignment of the head Slider and securing the seat mast. of the nut matches the vertical alignment of the hole in the seat mast. -
Page 11: Adjusting The Ride
INSTALLING THE ISOSPEED SEAT DECOUPLER AND SEAT MAST Place the curved washer onto the seat tube Once you have decided on the position of the (6a) and while holding the nut securely with a slider, tighten the cap screw using a torque key set finger (6b), insert the cap screw through the to a maximum of 5 Nm. -
Page 12: Front Isospeed
FRONT ISOSPEED TOOLS AND MATERIALS REQUIRED: Installing the front IsoSpeed system • 5 mm hex wrench • Grease • Torque wrench Apply grease to the bores on both sides of the Front IsoSpeed head tube as well as the inside face. lower cover Elliptical nut m8 x1.0 x 6mm... - Page 13 INSTALLING THE HEAD TUBE ISOZONE While pinching the front IsoSpeed decoupler Place a finger inside the decoupler and push the between two fingers to hold the washers, carefully screw towards the outside of the head tube. guide it into the cavity in the head tube. Stop when the holes in the decoupler are aligned with the holes in the frame.
- Page 14 INSTALLING THE HEAD TUBE ISOZONE Place one hand on the opposite side of the head To fully tighten, apply good pressure while tube (9a) and with the other, insert the torque key turning the torque key in the nut. This will into the nut and apply pressure with both hands prevent the bolt inside the decoupler from until the nut seats into head tube (9b).Then turn...
-
Page 15: Installing The Fork
INSTALLING THE FORK TOOLS AND MATERIALS REQUIRED: Install the front IsoSpeed lower cover by wrapping it around the head tube, starting on the left side • Fork • Compression plug and using your thumb to press it into place. • Headset •... -
Page 16: Installing The Di2
INSTALLING THE DI2 TOOLS AND MATERIALS REQUIRED: Feeding the connector in first, thread the wire into the downtube hole. • 5 torx screws • 2 m5 bolts • T8 Torx wrench • Downtube cover Place the Di2 battery into the bracket. Place the downtube cover over the hole. -
Page 17: Installing The Shift Cables
INSTALLING THE SHIFT CABLES TOOLS AND MATERIALS REQUIRED: Install housing caps onto cable housing. Insert the cable housing into the shifter cable stop. • Shift cables • Inline barrel adjuster • Housing • Housing cutters • Housing end caps • 4mm wrench •... - Page 18 INSTALLING THE SHIFT CABLES To create the correct amount of slack in the cable, Cut the cable at this mark. Clean the cable end and do not make it too loose (A) or too tight (B). install a cable stop. TIGHT LOOSE Thread shift cable through the housing and...
-
Page 19: Securing The Rear Derailleur
INSTALLING THE SHIFT CABLES Snap the frame housing stop into the frame. Ensure Securing the rear derailleur dropout cable sleeve is inserted in the frame. Thread the cables through the liners in the downtube until they exit at the bottom of the bike through the bottom bracket cable port. -
Page 20: Securing The Front Derailleur
INSTALLING THE SHIFT CABLES Securing the front derailleur Check the downtube opening to make sure cables are not interfering with each other. Pull on the front derailleur cable while viewing through this opening. Only front derailleur cable should move. Guide the front derailleur cable over the long end of the bottom bracket. -
Page 21: Installing Fenders
INSTALLING FENDERS Pass the fender through the rear brake (1a) and TOOLS AND MATERIALS REQUIRED: slide the bracket on until you reach the brake arch or seatstay bridge adapter. (1b) Secure with screw • 4mm hex wrench • 8mm open-end wrench (1c). -
Page 22: Securing The Front Fender
INSTALLING FENDERS Attach rear wheel. Adjust the struts to the Securing the rear fender appropriate length (6a) so that the fender has enough clearance over the tire to prevent rubbing (6b). Remove the front wheel. Remove the hidden fender mount set screws from the fork legs. (On a disc brake fork there will only be one set screw on the drive side fork leg) After finalizing the position of the fender, remove... - Page 23 INSTALLING FENDERS Install the top of the fender to the backside of the Reinstall the front wheel. Adjust the fender at the fork crown. Place the fender at its highest possible fork crown so that there is clearance between the setting.
-
Page 24: Installing Chain Keeper
INSTALLING CHAIN KEEPER TOOLS AND MATERIALS REQUIRED: • Chain keeper • m5 button head screw • Chain keeper washer • Wrench • 4mm Hex Wrench Securing the chain keeper Place the chain keeper washer and chain keeper onto the m5 button head screw. Note the curved surface on the frame and place the chain keeper along this surface and tighten until snug (2a). - Page 26 PN 543481...
