Magiglo Ekos 20 User, Installation & Servicing Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

EKOS 20"
Fuel Effect Options:
Coal Effect
Pebble Effect
Beachcomber Effect
Shoreline Effect
All available on NG & LPG
Control Options:
Manual BM Control
Upgradeable Manual Control
Remote Control (Response-S)
Optimum Control
Trim Switch Control
Total Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE
(Dependent upon model)
Users,
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ekos 20 and is the answer not in the manual?

Questions and answers

Related Manuals for Magiglo Ekos 20

Summary of Contents for Magiglo Ekos 20

  • Page 1 EKOS 20” Fuel Effect Options: Coal Effect Pebble Effect Beachcomber Effect Shoreline Effect All available on NG & LPG Control Options: Manual BM Control Upgradeable Manual Control Remote Control (Response-S) Optimum Control Trim Switch Control Total Control For use on Natural Gas (G20) at a supply pressure of 20mbar...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.

  • Page 3: Table Of Contents

    Contents     ......................1 ENERAL NFORMATION     1.1. Important Note About ODS Pilot ................2     1.2. Fire Fret Dimensions ....................3     ......................5 NSTRUCTIONS     2.1. Lighting Procedure ..................... 5     2.1.1. Lighting Procedure (Standard BM Control) ............
  • Page 4     3.9.11. Instructing the User .................... 39     ....................41 ERVICING NSTRUCTIONS     4.1. General Requirements ..................... 41     4.2. Servicing Instructions ....................41     4.3. Replacing Parts ......................42     4.3.1. Pilot Assembly Replacement ................42  ...

  • Page 5: General Information

    Only approved imitation fuel, available from Burley Magiglo., should be used with this appliance. 3. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of young children, the elderly or infirm.

  • Page 6: Important Note About Ods Pilot

    Under no circumstances should it be adjusted or put out of action by the installer or the user. If the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.

  • Page 7: Fire Fret Dimensions

    1.2. Fire Fret Dimensions All models can be used with the Magiglo range of frets or any other fire fret that falls within the dimensions shown below The fireplace opening must be suitable in size to accommodate the fire being installed.
  • Page 8 This page is intentionally left blank Page 4...

  • Page 9: User Instructions

    2. U NSTRUCTIONS 2.1. Lighting Procedure Your fire will be fitted with one of the five different types of gas control. Identify the control system on your fire as shown and follow the appropriate operating instructions in the appropriate section. Control Valve Operation Control Type...

  • Page 10: Lighting Procedure (Standard Bm Control)

    2.1.1. Lighting Procedure (Standard BM Control) 1. Ensure that the arrow on the control knob is pointing towards the OFF position as shown in Figure 2. Press in the knob and slowly turn anti-clockwise until a click is heard. The spark should now light the pilot.

  • Page 11: Lighting Procedure (Upgradeable Manual Control)

    2.1.2. Lighting Procedure (Upgradeable Manual Control) Whilst pushing the IGNITION KNOB in (see Figure 6), turn it anticlockwise to Ignition knob the pilot flame position as shown in Figure 7. During this process, the spark ignition will have operated and lit the pilot flame.

  • Page 12: Lighting Procedure (Remote Control)

    2.1.3. Lighting Procedure (Remote Control) 1. Press the bottom button on the remote 9. The fire can safely be left in this position handset until clicking is heard on the times, however prevent valve, and the gas rate adjustment knob unauthorised or accidental use (say by is at the off position.

  • Page 13: Lighting Procedure (Optimum Control And Trim Switch Control)

    2.1.4. Lighting Procedure (Optimum Control and Trim Switch Control) 1. Ensure the main burner is off by pressing position turning degrees clockwise. To turn the pilot off, turn the the button on the trim marked IGNITION KNOB fully clockwise. (‘small flame/dot’) until clicking is heard on the valve (see Figure 12/Figure 13).

  • Page 14: Lighting Procedure (Total Control)

    2.1.5. Lighting Procedure (Total Control) 1. Ensure that gas is available at the valve and the ON/OFF switch in the ON position (–). ON/OFF Switch 2. Simultaneously press and hold the (red circle) and (large flame) Manual buttons until a short acoustic signal Knob confirms the start sequence has begun, then release the buttons (see Figure...

  • Page 15: Manual Operation (Total Control Model)

    2.1.6. Manual Operation (Total Control Model) In emergency the appliance can be operated ON/OFF Switch manually as follows: Manual 1. Turn the Gas Rate Adjusting knob fully Knob clockwise to the OFF position. A clicking sound will be audible, but this is perfectly alright.

  • Page 16: Battery Replacement (Remote Control & Total Control)

    2.2. Battery Replacement (Remote Control & Total Control) 2.2.1. Handset 1. On the reverse of the handset remove the battery cover by pressing down at the top of the cover and sliding down. Press here and 2. Remove and unclip the old battery and slide down replace with a new PP3 9V battery.

  • Page 17: Battery Replacement (Optimum Control)

    2.3. Battery Replacement (Optimum Control) 1. The battery pack is mounted inside the wall-mounting box behind the wall switch plate. blue blue 5. To change the batteries remove the two brown small screws securing the wall plate brown HIGH using a small screwdriver. LOW/OFF SWITCH SWITCH...

  • Page 18: Fuel Effect Layout

    2.5. Fuel Effect Layout You fire has been supplied with either Coal, Pebble, Beachcomber or Shoreline effect. Please refer to the relevant section for instructions on how to arrange the imitation fuels. It is recommended that the imitation fuel be left alone once the desired flame pattern has been achieved.

  • Page 19: Coal Effect Layout

    2.5.1. Coal Effect Layout This fire is supplied with different sizes of ceramic coal: LH Rear RH Rear Matrix Matrix Small Square Coals LH Middle RH Middle Random Coals Matrix Matrix Small random coals Fuel Burner Board Spikes Matrices Proceed with the coal layout as follows: - Figure 23 1.

  • Page 20: Pebble Effect Layout

    2.5.2. Pebble Effect Layout The fire is supplied with ceramic pebble sets as follows:- LH Rear RH Rear Matrix Matrix Large Pebbles (A, B & K) LH Middle RH Middle Medium Pebbles (C & D) Matrix Matrix Medium Pebbles (F) Fuel Burner Board Spikes...
  • Page 21 Some sooting on the pebbles may be observed. This is perfectly normal. Periodically operating the Fire at various rates will burn this soot away. excessive sooting is observed, this is an indication that the pebbles are laid incorrectly – please refer to instructions. Page 17...

  • Page 22: Beachcomber Effect & Shoreline Effect Layout

    2.5.3. Beachcomber Effect & Shoreline Effect Layout The fire is supplied with ceramic pebble and driftwood set as follows: Pebbles Large Pebbles (A, B & K) Medium Pebbles (C & D) Small Pebbles (E/J) Matrices Driftwood RH Rear LH Rear Matrix Matrix LH Middle...
  • Page 23 6. Next place the two J driftwood pieces and the K, D and C pebbles as in Figure 7. Continue laying the driftwood pieces and the pebbles as shown in Figure 40 to Figure 42. 8. After the appliance has been allowed to warm up, small adjustments (using a small pair of tongs) may be made to the top layer to achieve the desired flame...

  • Page 24: Fitting The Trim

    2.6. Fitting the Trim 1. Most trims are coated with a protective film. This must be removed by peeling off before fitting the trim. 2. The trim is held on by four magnets. These will either be attached to the trim or supplied loose in a separate envelope.

  • Page 25: Cleaning And Care Instructions

    2.8. Cleaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components (Coals, Pebbles, Driftwood & Ceramic backs) containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.

  • Page 26: Cleaning The Pilot

    2.8.2. Cleaning the Pilot The oxygen depletion sensing pilot fitted to 2. With the aid of a small nozzle attachment your Burley Magiglo fire is a highly reliable on your vacuum cleaner, apply suction at safety device which causes the fire to shut the lint guard on the pilot.

  • Page 27: Installation Instructions

    3. I NSTALLATION NSTRUCTIONS Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure and the adjustment of the appliance are compatible) 3.1. General Safety Requirements The installation of the fire in GB should follow the recommendations of the following current British Standards: BS 5871: Pt 2 Installation of Inset live fuel effect gas fires.

  • Page 28: General Dimensions

    3.3. General Dimensions Dimensions 580mm 553mm C (Front) 497mm C (Rear) 412mm 253mm 585mm Table 1 Figure 45 - Standard Box Dimension (refer to Table 1) 3.4. Technical Data Natural Gas Propane (LPG) Nominal maximum heat input 11.0 kW (gross) 10.0 kW (gross) Setting pressure (Cold) 14.0 mbar ±1.0 mbar...

  • Page 29: Burner Tray Layout

    Figure 47 - Ekos 20” with Mertik GV34 Valve (Upgradable Manual, Remote Control, Optimum Control, Trim Switch Control) Tray Tray Fixing Fixing Screw Screw pressure test Receiver point Valve Figure 48 – Ekos 20” with Mertik GV60 Valve (Total Control) Page 25...

  • Page 30: Appliance Location

    Burley Magiglo would recommend that a hearth or physical barrier be installed with this appliance. However, should you decide not to follow our recommendation and do not fit a hearth or subsequently decide to remove the hearth / physical barrier, then consideration as to the safety of the occupants of the room should be given.

  • Page 31: Floor Level And Raised Fireplace Openings

    3.6.1. Floor Level and Raised Fireplace Openings Floor Level Openings 565mm 510 - 570mm 280mm (min) Must project a minimum of 150mm either side of any naked flame or incandescent material Must project a minimum of 300mm in front of any naked flame or incandescent material Table 2 Raised Fireplace Openings...

  • Page 32: Physical Barrier

    3.6.2. Physical Barrier Any physical barrier should meet following requirements: All models Must project a minimum of 1. Provide at least the equivalent level of 150mm either side of any naked warning to the approach of an open fire, flame or incandescent material to that of a hearth.
  • Page 33 Figure 57, Figure 58, Figure 59 and Figure 60 show examples of how the requirements for the physical barrier may be met. 50mm Figure 59 – Example of physical barrier Figure 57 – Example of physical barrier (dimensions as stated in Table 4 – Protected Area) (dimensions as stated in Table 4 –...

  • Page 34: Ventilation

    3.7. Ventilation This appliance requires a minimum ventilation of 15cm for LPG models and 20cm for NG models in the room it is fitted in. In GB reference should be made to BS 5871 Part 2, and in IE reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.

  • Page 35: Installation Procedure

    3.9. Installation Procedure Before commencing installation, ensure that the intended installation will comply with details in General Information on Pages 1 and 27. Carefully unpack the contents of the carton and check them against the checklist given on the previous page. Make sure that the fireplace opening is suitable for the installation of the fire and prepare the fireplace to suit the dimensional requirements given in section 3.6 (i.e.

  • Page 36: Preparing The Fireplace Opening

    3.9.2. Preparing the Fireplace Opening 1. Prepare fireplace opening accordance with Sections 3.2 and 3.6. 2. Mark out, drill, plug and fit the four eye screws onto the rear wall of the fireplace opening as shown in Figure 63. Centre Line 3.

  • Page 37: Installing The Firebox

    3.9.3. Installing the Firebox 1. With the firebox placed close to the fireplace opening feed the two cables through the matching eye screws (left cable through left hand set of eyelets and the same for right hand cable) and then back into the holes at the bottom rear of the firebox (see Figure 64).

  • Page 38: Connecting The Gas Supply

    3.9.4. Connecting the Gas Supply The gas supply to the fire must be carried out using rigid or semi-rigid metal tubing. A service cock must be incorporated near the appliance to facilitate isolation of the fire during servicing. An isolating valve (with a pressure test point) has been supplied with this fire. Carry out the procedure below to prepare the gas supply to the isolating valve supplied: 1.

  • Page 39: Continuation Of Installation - Remote Control Model

    3.9.5. Continuation of Installation - Remote Control Model 1. Unpack the box containing the Receiver and the Hand Set. 2. Fit four AA (1.5V) batteries into the receiver unit and the PP3 (9V) battery into the transmitter (hand set). 3. Feed the cable from the receiver unit heat shield to the spade terminals on the control valve, keeping the cable clear of the underside of the tray.

  • Page 40: Continuation Of Installation - Optimum Control Model

    3.9.6. Continuation of Installation - Optimum Control Model 1. Find a suitable position for the wall Any plaster/cement used to switch, a maximum of 5 metres of cable secure the wall box must be is supplied. completely cured (dry) before installing the batteries or fixing 2.

  • Page 41: Continuation Of Installation - Trim Switch Control Model

    3.9.7. Continuation of Installation - Trim Switch Control Model 1. Unpack the battery pack and connect to the battery connection on the cable. 2. Fit the connectors on the cable to the drive motor ensuring correct polarity. The cable connectors must be matched appropriately sized spade...

  • Page 42: Commissioning

    3.9.9. Commissioning 1. Turn on the gas supply to the fire and purge the gas line. Check all the gas joints for gas soundness. 2. Remove the pressure test point screw located as shown in Figure 46 – Figure 48 and connect a pressure gauge. 3.

  • Page 43: Checking For Spillage

    3.9.10. Checking for Spillage The imitation fuels must be laid accordance with instructions prior commencing the spillage test. 1. Close all doors and windows. 2. Turn the fire on to its full rate and leave it burning for 5 minutes. 3.
  • Page 44 This page is intentionally left blank Page 40...

  • Page 45: Ervicing Nstructions

    Under no circumstances should the pilot assembly be adjusted or put out of action by the installer. If the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.

  • Page 46: Replacing Parts

    4.3. Replacing Parts For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will either need the serial number or: a) model name; b) the gas type; c) the imitation fuel type; d) the type of control. Only approved parts should be used.

  • Page 47: Control Valve Replacement (Bm Or Mertik Gv34)

    4.3.3. Control Valve Replacement (BM or Mertik GV34) 1. Disconnect the pilot feed pipe, the main 4. Refit the new valve in reverse order gas feed pipe, gas outlet pipe and the ensuring that the valve spacers (on thermocouple connection from Mertik valve) are in place.

  • Page 48: Motor Replacement (Remote/Optimum/Trim Switch Control Models)

    4.3.4. Motor Replacement (Remote/Optimum/Trim Switch Control) The gas rate adjusting motor is replaceable in situ. 1. Remove the batteries from the receiver unit to prevent the risk of short circuit. 2. Remove the two motor connection tags from the valve. 3.

  • Page 49: Replacing Mertik Gv60 Valve (Total Control Model)

    4.3.5. Replacing Mertik GV60 Valve (Total Control) Referring to Figure 78:- 1. Remove al the gas connections on the valve including the pilot feed pipe. Valve 2. Remove the thermocouple connection securing from the interrupter block at the rear of Screw the valve.

  • Page 50: Replacing The Ceramic Back And Sides

    4.3.8. Replacing the Ceramic Back and Sides The ceramic back and sides are replaceable in situ. 1. Isolate and disconnect the gas supply from the burner tray. 2. Remove the burner tray fixing screws and withdraw the burner from the firebox. 3.

  • Page 51: Installation And Operational Troubleshooting

    4.4. Installation and Operational Troubleshooting The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 52 NOTE: For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will either need the serial number or: a) model name i.e. Ekos 20; b) the gas type; c) the imitation fuel type; d) the type of control.
  • Page 53 This page is intentionally left blank Page 49...
  • Page 54 This page is intentionally left blank Page 50...
  • Page 55 This page is intentionally left blank Page 51...
  • Page 56 Burley Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Magiglo is a registered trademark of Burley Appliances Ltd. Burley Magiglo, Lands End Way Oakham, Rutland, LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.magiglo.co.uk Email: info@magiglo.co.uk...
