Magiglo ARIA User, Installation & Servicing Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

ARIA
Fuel Effect Options:
Coal Effect – NG and LPG
Pebble Effect – NG and LPG
Control Options:
Manual BM Control
Upgradeable Manual Control
Remote Control
Optimum Control
Trim Switch Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE
(Dependent upon model)
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER
Models:
Aria 16"
Aria 18"
Total Control
Users,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARIA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Magiglo ARIA

Summary of Contents for Magiglo ARIA

  • Page 1 ARIA Models: Aria 16” Aria 18” Fuel Effect Options: Coal Effect – NG and LPG Pebble Effect – NG and LPG Control Options: Manual BM Control Upgradeable Manual Control Remote Control Optimum Control Trim Switch Control Total Control For use on Natural Gas (G20) at a supply pressure of 20mbar...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.

  • Page 3: Table Of Contents

      3.3. General Dimensions ....................26     3.4. Technical Data ......................26     3.4.1. 16” Aria (All Controls) ..................26     3.4.2. 18” Aria (All Controls) ..................26     3.5. Appliance Location ....................27    ...
  • Page 4     3.8.9. Commissioning ....................36     3.8.10. Checking for Spillage ..................37     3.8.11. Instructing the User .................... 37     Servicing Instructions ..................... 39     4.1. General Requirements ..................... 39     4.2. Servicing Instructions ....................39  ...

  • Page 5: General Information

    9. It is important for this fire to be serviced regularly. An annual service is recommended. Efficiency Declaration The efficiency of Aria 16” has been measured as specified in BS 7977: Part 1 and the result is 49.9%*. The gross calorific value of the fuel has been used for this efficiency calculation. The test data from which it has been calculated has been certified by Advantica Ltd.
  • Page 6 Ventilation Requirements 1. For Aria 16” models, normal adventitious ventilation is usually sufficient to satisfy the ventilation requirements of these appliances. In GB reference should be made to BS 5871 Part 3, and in IE reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.

  • Page 7: Important Note About Ods Pilot

    1.2. F ire Fret Dimensions All models can be used with the Burley Magiglo range of frets or any other fire fret that falls within the dimensions shown below Minimum opening (free air) in fire fret...
  • Page 8 This page is left intentionally blank Page 4...

  • Page 9: User Instructions

    2. U NSTRUCTIONS 2.1. L ighting Procedure Your fire will be fitted with one of the following different types of gas control valves. Identify the control system on your fire as shown and follow the appropriate operating instructions in the appropriate section.

  • Page 10: Lighting Procedure (Manual Bm Control)

    2.1.1. L ighting Procedure (Manual BM Control) 2 3 B 1. Ensure that the arrow on the control knob is pointing towards the OFF position as shown in F igure 2 . Press in the knob and slowly turn anti-clockwise until a click is heard.

  • Page 11: Lighting Procedure (Upgradeable Manual Control)

    2.1.2. L ighting Procedure (Upgradeable Manual Control) 2 4 B 1. Whilst pushing the IGNITION KNOB in (see F igure 6 ) , turn it anticlockwise to Ignition knob the pilot flame position as shown in F igure 7 . During this process, the spark ignition will have operated and lit the pilot flame.

  • Page 12: Lighting Procedure (Remote Control)

    2.1.3. L ighting Procedure (Remote Control) 2 5 B 1. Press the bottom button on the remote 9. The fire can safely be left in this position handset until clicking is heard on the times, however prevent valve, and the gas rate adjustment knob unauthorised or accidental use (say by is at the off position.

  • Page 13: Lighting Procedure (Optimum Control And Trim Switch Control)

    2.1.4. L ighting Procedure (Optimum Control and Trim Switch Control) 2 6 B 1. Ensure the main burner is off by pressing position turning degrees clockwise. To turn the pilot off, turn the the button on the trim marked IGNITION KNOB fully clockwise. (‘small flame/dot’) until clicking is heard on the valve (see F igure 12...

  • Page 14: Lighting Procedure (Total Control)

    2.1.5. L ighting Procedure (Total Control) 2 7 B 1. Ensure that gas is available at the valve and the ON/OFF switch in the ON ON/OFF Switch position (–). 2. Simultaneously press and hold the Manual Knob (red circle) and (large flame) buttons until a short acoustic signal confirms the start sequence has begun,...

  • Page 15: Manual Operation (Total Control)

    2.1.6. M anual Operation (Total Control) 2 8 B In emergency the appliance can be operated manually as follows: ON/OFF Switch 1. Turn the Gas Rate Adjusting knob fully Manual clockwise to the OFF position. A clicking Knob sound will be audible, but this is perfectly alright.

  • Page 16: Battery Replacement (Remote Control & Total Control)

    2.2. B attery Replacement (Remote Control & Total Control) 2.2.1. H andset 2 9 B 1. On the reverse of the handset remove the battery cover by pressing down at the top of the cover and sliding down. Press here and slide down 2.

  • Page 17: Battery Replacement (Optimum Control)

    2.3. B attery Replacement (Optimum Control) 1. The battery pack is mounted inside the wall-mounting box behind the wall switch plate. blue blue 2. To change the batteries remove the two brown small screws securing the wall plate brown HIGH LOW/OFF using a small screwdriver.

  • Page 18: Fuel Effect Layout

    2.5. F uel Effect Layout You fire has been supplied with either Coal or Pebble effect. Please refer to the relevant section for instructions on how to arrange the imitation fuels. Fuel Effect Tray Type Refer to Coal Effect Natural Gas & LPG Section 2 .5.1 Pebble Effect...

  • Page 19: Coal Effect Layout

    2.5.1. C oal Effect Layout 3 1 B This fire is supplied with three different types of ceramic coals packed in separate bags as follows: - 16” 18” Medium square coals equally Random Coals spaced all Small Square Coals the way back Medium Square Coals (Quantities shown are pcs)
  • Page 20 7. Now place 5 more Random Coals on top of the Small Square Coals as shown in figure below ensuring that they are stable in position and do not topple over onto the burner or to the front. Place Small random them such that the flat surfaces are at coals the top and bottom.

  • Page 21: Pebble Effect Layout

    2.5.2. P ebble Effect Layout 3 2 B This fire is supplied with different types of ceramic pebbles packed in separate bags as follows: - 16” 18” Large Pebbles (A and B) Small Front Pebbles (E and J) Medium Flat Pebbles (H) Medium Pebbles (C and D) Small round Pebbles (F) (Quantities shown are pcs)
  • Page 22 7. Place 4 (for 16”) or 5 (for 18”) Small Round Pebbles at the back ensuring that the gaps left previously in step 2 are not blocked by the pebbles (see F igure 32 8. Put aside any pebbles left over for use as future replacements 9.

  • Page 23: Fitting The Trim

    2.6. F itting the Trim 2.6.1. E legance Trim (Preparation) 3 3 B Before fitting the trim, attach the fixing brackets enclosed to the pre-drilled holes, with the high temperature push fit rivets also enclosed. Top Fixing Brackets Rubber Seal Figure 34 –...

  • Page 24: Elegance Trim (Fitting)

    2.6.2. E legance Trim (Fitting) 3 4 B 1. Offer the trim to the front flange of the fire. TOP BRACKETS 2. Keeping the trim vertical, locate the holes at the bottom of the two sides onto the pins on the sides of the fire. 3.

  • Page 25: Cleaning And Care Instructions

    2.8. C leaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components (Coals, Pebbles & Ceramic backs) containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.

  • Page 26: Cleaning The Pilot

    C leaning the Pilot 3 7 B The oxygen depletion sensing pilot fitted to your Burley Magiglo fire is a highly reliable safety device which causes the fire to shut down in the unlikely event of a reduction of oxygen in the room where the fire is fitted.

  • Page 27: Brass Or Chrome Surfaces

    Minor surface scuffs may be treated using a water based touch up stain available at Burley Magiglo fire retailers. Extreme care should be taken when handling and installing products containing ceramic interiors, so as not to cause damage.
  • Page 28 This page is left intentionally blank Page 24...

  • Page 29: Installation Instructions

    3. I NSTALLATION NSTRUCTIONS Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure) and the adjustment of the appliance are compatible) 3.1. G eneral Safety Requirements 1 0 B Before commencing installation, ensure that the intended installation will comply with details in G eneral Information on Page...

  • Page 30: General Dimensions

    Table 1 TRIMS NOT SHOWN Figure 43 3.4. T echnical Data 1 3 B 3.4.1. 1 6” Aria (All Controls) 4 3 B Natural Gas (G20) Propane (G31) Nominal max. Heat Input 6.9 kW (gross) 6.9 kW (gross) Setting Press. (Cold) 16”...

  • Page 31: Appliance Location

    225mm above the floor; or the manufacturer’s instructions state that a hearth is not required. Burley Magiglo would recommend that a hearth or physical barrier be installed with this appliance. However, should you decide not to follow our recommendation and do not fit a hearth or subsequently decide to remove the hearth / physical barrier, then consideration as to the safety of the occupants of the room should be given.

  • Page 32: Ventilation

    V entilation 1 5 B 1. For Aria 16” models, normal adventitious ventilation is usually sufficient to satisfy the ventilation requirements of these appliances. In GB reference should be made to BS 5871 Part 3, and in IE reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.

  • Page 33: Installation Procedure

    3.8. I nstallation Procedure 1 7 B Before commencing installation, ensure that the intended installation will comply with details in G eneral Information on Page Carefully unpack the contents of the carton and check them against the checklist given on the previous page.

  • Page 34: Preparing The Fireplace Opening

    3. Remove the silicone rubber sealing strip from its bag and apply it around the rear of the fire flange after first removing the protective backing paper. 4. Unpack the firebox fixing cables from the bag and feed each cable through each hole on the side of the flue outlet slot.

  • Page 35: Connecting The Gas Supply

    3.8.3. C onnecting the Gas Supply 4 7 B The gas supply to the fire must be carried out using rigid or semi-rigid metal tubing of 8 mm diameter. A service cock must be connected near the appliance to facilitate isolation of the gas supply during servicing.
  • Page 36 9. Roll up the excess cable and tuck it away in the corner. DO NOT cut the excess cable. 10. To further tension the cable, while gripping the tensioning screw tighten (turn clockwise) the wing nut. If after carrying out the above procedure the WING seal between the firebox flange and the CABLE...

  • Page 37: Continuation Of Installation - Remote Control Model

    3.8.5. C ontinuation of Installation - Remote Control Model 4 9 B 1. Unpack the box containing the Receiver 5. Test the operation of the drive motor and the Hand Set. using the hand set as per Users Instructions (Section 2 .1.3 L ighting 2.

  • Page 38: Continuation Of Installation - Optimum Control Model

    3.8.6. C ontinuation of Installation - Optimum Control Model 5 0 B 1. Find a suitable position for the wall Any plaster/cement used to switch, a maximum of 5 metres of cable secure the wall box must be is supplied. completely cured (dry) before installing the batteries or fixing 2.

  • Page 39: Continuation Of Installation - Trim Switch Control Model

    3.8.7. C ontinuation of Installation - Trim Switch Control Model 5 1 B 1. Unpack the battery pack and connect to the battery connection on the cable. 2. Fit the connectors on the cable to the drive motor ensuring correct polarity. The cable connectors must be matched to the appropriately sized spade connector.

  • Page 40: Commissioning

    3.8.9. C ommissioning 5 3 B 1. Turn on the gas supply to the fire and 9. Lay the fuel effect in accordance with the purge the gas line. Check all the gas instructions in the appropriate section for joints for gas soundness. the model.

  • Page 41: Checking For Spillage

    3.8.10. C hecking for Spillage 5 4 B 1. Close all doors and windows. 2. Turn the fire on at full rate and leave it burning for 5 minutes. 3. Test for spillage using a smoke match (in a ‘Blume Tube’) about 12mm under the centre of the top louvre on the ceramic fireback.
  • Page 42 This page is left intentionally blank Page 38...

  • Page 43: Servicing Instructions

    4. S ERVICING NSTRUCTIONS 4.1. G eneral Requirements 1 8 B All repairs and servicing must be carried out by a qualified registered gas installer (e.g. member of Gas Safe in GB) in accordance with the current Gas Safety (Installation and Use) Regulations and these instructions.
  • Page 44 Removing the Firebox:- 1. Referring to F igure 58 , unwind the two cables at the rear bottom of the firebox. 2. Unscrew both the thumbscrews and pull TENSIONING out the cable tensioning screws. SCREW 3. Remove the blanking plate from the gas inlet slot and gently pull the firebox CABLE forward.

  • Page 45: Replacing Parts

    4.3. R eplacing Parts 2 0 B For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will need the model name i.e. model number, the gas type, the type of control and serial number. Only approved parts should be used.

  • Page 46: Burner Board Replacement

    4.3.2. B urner Board Replacement 5 7 B 1. Follow instructions within the Servicing Instructions to remove the burner tray from the firebox. 2. Remove the four rear cover plate fixing screws and gently lift it off. 3. Loosen the four front fuel retaining bracket-fixing nuts lift...

  • Page 47: Control Valve Replacement (Bm Or Mertik Gv34))

    4.3.4. C ontrol Valve Replacement (BM or Mertik GV34)) 5 9 B 1. Remove the burner tray from the firebox. 7. Undo and remove the two gas outlet tubes on the control valve (8 mm and 4 2. Remove the pilot gas feed pipe nut at the mm tubes).

  • Page 48: Motor Replacement (Remote Control / Optimum Control Models / Trim Switch Models)

    4.3.5. M otor Replacement (Remote Control / Optimum Control Models 6 0 B / Trim Switch Models) The gas rate adjusting motor is replaceable in situ. 1. Remove the batteries from the receiver unit to prevent the risk of short circuit. 2.

  • Page 49: Control Valve Replacement (Total Control)

    4.3.1. C ontrol Valve Replacement (Total Control) 6 1 B Referring to F igure 64 1. Remove al the gas connections on the valve including the pilot feed pipe. 2. Remove the thermocouple connection Valve from the interrupter block at the rear of securing the valve.

  • Page 50: Installation And Operational Troubleshooting

    4.4. I nstallation and Operational Troubleshooting 2 1 B The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 51 Remote Control, Trim Switch, Optimum & Total Control Models Symptom Cause Remedy Main burner will not Ignition knob incorrectly set Set the ignition knob at the come on when 9 o’clock position. required even though the drive motor is heard to be operating Motor not functioning Flat hand set battery Replace battery (1 X PP3)

  • Page 52: Schematic Wiring Diagram (Trim Switch And Optimum Control)

    4.5. S chematic Wiring Diagram (Trim Switch and 2 2 B Optimum Control) Blue Brown ‘HIGH’ SWITCH ‘LOW/OFF’ SWITCH White Black 4-CORE CABLE Black White Black White BATTERY BOX Figure 67 Page 48...
