Magiglo ACCOLADE User, Installation & Servicing Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

ACCOLADE
Fuel Effect Options:
Coal Effect – NG and LPG
Pebble Effect – NG and LPG
Control Options:
Manual BM Control
Upgradeable Manual Control
Remote Control
Optimum Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE
(Dependent upon model)
Users,
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACCOLADE and is the answer not in the manual?

Questions and answers

Related Manuals for Magiglo ACCOLADE

Summary of Contents for Magiglo ACCOLADE

  • Page 1 ACCOLADE Fuel Effect Options: Coal Effect – NG and LPG Pebble Effect – NG and LPG Control Options: Manual BM Control Upgradeable Manual Control Remote Control Optimum Control For use on Natural Gas (G20) at a supply pressure of 20mbar...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.

  • Page 3: Table Of Contents

    Contents     General Information ......................1     1.1. Important Note About ODS Pilot ................2     1.2. Fire Fret Dimensions ....................3     User Instructions ....................... 5     2.1. Lighting Procedure ..................... 5     2.1.1.
  • Page 4     4.1. General Requirements ..................... 40     4.2. Servicing Instructions ....................40     4.3. Replacing Parts ......................41     4.3.1. Pilot Assembly Replacement ................41     4.3.2. Injector Replacement ..................41     4.3.3. Control Valve Replacement ................42  ...

  • Page 5: General Information

    Only approved imitation fuel, available from Burley Magiglo., should be used with this appliance. 5. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of young children, the elderly or infirm.

  • Page 6: Important Note About Ods Pilot

    Under no circumstances should it be adjusted or put out of action by the installer or the user. In case the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.

  • Page 7: Fire Fret Dimensions

    1.2. Fire Fret Dimensions All models can be used with the Burley Magiglo range of frets or any other fire fret that falls within the dimensions shown below The fireplace opening must be suitable in size to accommodate the fire being installed.
  • Page 8 This page is left intentionally blank Page 4...

  • Page 9: User Instructions

    2. U NSTRUCTIONS 2.1. Lighting Procedure Your fire will be fitted with one of the following different types of gas control valves. Identify the control system on your fire as shown and follow the appropriate operating instructions in the appropriate section. Control Valve Operation Control Type...

  • Page 10: Lighting Procedure (Manual Bm Control)

    2.1.1. Lighting Procedure (Manual BM Control) 1. Ensure that the arrow on the control arrow is in the OFF position, then knob is pointing towards the OFF release. position as shown in F igure 2 . Press in the knob and slowly turn anti-clockwise until a click is heard.

  • Page 11: Lighting Procedure (Upgradeable Manual Control)

    2.1.2. Lighting Procedure (Upgradeable Manual Control) Whilst pushing the IGNITION KNOB in (see F igure 7 ) , turn it anticlockwise to Ignition knob the pilot flame position as shown in F igure 8 During this process, the spark ignition will have operated and lit the pilot flame.

  • Page 12: Lighting Procedure (Remote Control)

    2.1.3. Lighting Procedure (Remote Control) 1. Press the bottom button on the remote valve. Release the button as soon as handset until clicking is heard on the the clicks are heard. valve, and the gas rate adjustment knob 10. The fire can safely be left in this position is at the off position.

  • Page 13: Lighting Procedure (Optimum Control)

    2.1.4. Lighting Procedure (Optimum Control) 1. Ensure the main burner is off by pressing 11. The fire can safely be left in this position times, however prevent the button on the trim marked unauthorised or accidental use (say by (‘small flame/dot’) until clicking is heard children) it is recommended to turn the on the valve (see F igure 13...

  • Page 14: Battery Replacement (Remote Control)

    2.2. Battery Replacement (Remote Control) 2.2.1. Handset 1. On the reverse of the handset remove the battery cover by pressing down at the top of the cover and sliding down. Press here and 2. Remove and unclip the old battery and slide down replace with a new PP3 9V battery.

  • Page 15: Battery Replacement (Optimum Control)

    2.3. Battery Replacement (Optimum Control) 1. The battery pack is mounted inside the wall-mounting box behind the wall switch plate. blue blue 2. To change the batteries remove the two brown small screws securing the wall plate brown HIGH using a small screwdriver. LOW/OFF SWITCH SWITCH...

  • Page 16: Fuel Effect Layout

    2.4. Fuel Effect Layout You fire has been supplied with either Coal or Pebble effect. Please refer to the relevant section for instructions on how to arrange the imitation fuels. Fuel Effect Tray Type Refer to Coal Effect Natural Gas & LPG Section 2 .4.1 Pebble Effect...

  • Page 17: Coal Effect Layout

    2.4.1. Coal Effect Layout This fire is supplied with different sizes of disintegrate and/or cause ceramic coals as follows: discolouration. Small Coals Large Rounded Coals LargeTriangular Coals Rear matrix Front matrix Proceed with the layout as follows: 1. Position the rear matrix behind the burner as shown in F igure 19 2.
  • Page 18 Forward Figure 25 Figure 27 WARNING: Do not touch the fire when it is alight. The fire will remain very hot for a while after extinguishing. Figure 26 Page 14...

  • Page 19: Pebble Effect Layout

    2.4.2. Pebble Effect Layout The fire is supplied with ceramic pebble sets as follows:- Large Pebbles (A, B, K, L & M) Small Pebbles (E & G) Rear Matrix Front Matrix NOTE: When placing pebbles on the tray ensure the lettering on them is facing down and into the fire.

  • Page 20: Fitting A Standard Trim (If Supplied)

    2.5. Fitting a Standard Trim (If supplied) 1. Most trims are coated with a protective film. This must be removed by peeling off before fitting the trim. 2. The trim is held on by four magnets. Magnets These will either be attached to the trim or supplied loose in a separate envelope.

  • Page 21: Home Improvements

    2.7. Home Improvements WARNING: If after installation of this fire any home improvements (e.g. double glazing, secondary double glazing, draught proofing, fitting extractor fans, laminate flooring etc.) are carried out to the property it is essential to carry out a spillage test on the fire to ensure that the flue is still operating satisfactorily.

  • Page 22: Cleaning And Care Instructions

    2.8. Cleaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components (Coals, Pebbles & Ceramic backs) containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.

  • Page 23: Cleaning The Pilot

    The oxygen depletion sensing pilot fitted to your Burley Magiglo fire is a highly reliable safety device which causes the fire to shut down in the unlikely event of a reduction of oxygen in the room where the fire is fitted.

  • Page 24: Brass Or Polished Surfaces

    Minor surface scuffs may be treated using a water based touch up stain available at Burley Magiglo fire retailers. Extreme care should be taken when handling and installing products containing ceramic interiors, so as not to cause damage.

  • Page 25: Installation Instructions

    3. I NSTALLATION NSTRUCTIONS Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure) and the adjustment of the appliance are compatible 3.1. General Safety Requirements Before commencing installation, ensure that the intended installation will comply with details in G eneral Information on Page...
  • Page 26 Existing Concrete Milner back 50mm Figure 35 - Masonry Flue Figure 37 – BS 715 Flue Box Fireplace Opening Size (mm) (Applies to all cases) H eight 5 4 B Width Depth Table 1 10mm Figure 36 - Pre Cast Flue to BS EN 1858 or BS 1289 Page 22...

  • Page 27: General Dimensions

    225mm above the floor; or the manufacturer’s instructions state that a hearth is not required. Burley Magiglo would recommend that a hearth or physical barrier be installed with this appliance. However, should you decide not to follow our recommendation and do not fit a hearth or subsequently decide to remove the hearth / physical barrier, then consideration as to the safety of the occupants of the room should be given.

  • Page 28: Floor Level And Raised Fireplace Openings

    3.4.1. Floor Level and Raised Fireplace Openings 540mm 575mm 5 5 B 365mm 465mm 5 6 B 115mm (min) 5 7 B A minimum of 150mm 5 8 B either side of any incandescent material Must project a minimum of 300mm in front of any naked flame or incandescent material...

  • Page 29: Physical Barrier

    3.4.2. Physical Barrier Any physical barrier should meet Must project a minimum of 150mm following requirements: either side of any naked flame or incandescent material Provide at least the equivalent level of Must project a minimum of 300mm warning to the approach of an open fire, in front of any naked flame or to that of a hearth.
  • Page 30 F igure 46 F igure 47 F igure 48 F igure 49 show examples of how the requirements for the physical barrier may be met. 50mm Figure 48 – Example of physical barrier Figure 46 – Example of physical barrier (dimensions as stated in T able 4 –...

  • Page 31: Ventilation

    3.5. Ventilation This model does not normally require any additional ventilation in the room that it is fitted in. However, if spillage is detected during spillage test additional ventilation may be required. In GB reference should be made to BS 5871 Part 2 and in IE reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.

  • Page 32: Contents Checklist

    3.8. Contents Checklist Before proceeding with installation of the fire check the contents as follows: Basic Kit (Applicable to all control options) Quantity Item Gas Fire Imitation Fuel – Coal (NG/LPG) or Pebble Set (NG/LPG) Trim (Optional) Fire Front Cable Fixing Kit, Length of Sealing Strip, Instruction booklet, 1 pack Isolating valve...

  • Page 33: Installation Procedure

    G eneral Information on Page The Burley Magiglo Accolade is designed to be inset into a 16” fireplace opening. Any surround that is to be installed with this fire must be rated at 150 Carefully unpack the contents of the carton and check them against the checklist given on the previous page.

  • Page 34: Fitting The Flue Restrictor

    3.9.2. Fitting the Flue Restrictor If fitting the appliance to a masonry chimney (Class I) fit the restrictor plate using the three screws supplied (see F igure 54 Restrictor Plate If the fire shows a tendency to spill during the spillage test this restrictor plate may have to be removed.

  • Page 35: Installing The Firebox

    3.9.4. Installing the Firebox With the firebox placed close to the fireplace opening feed the two cables through the matching cable brackets (left cable through left hand set of brackets and the same for right hand cable) and then back into the holes at the bottom rear of the firebox (see F igure 56 Remove the grommet from the gas inlet...

  • Page 36: Connecting The Gas Supply

    3.9.5. Connecting the Gas Supply The gas supply to the fire must be carried out using rigid or semi-rigid metal tubing. A service cock must be incorporated near the appliance to facilitate isolation of the fire during servicing. An isolating valve (with a pressure test point) has been supplied with this fire. Carry out the procedure below to prepare the gas supply to the isolating valve supplied: Cut a cross-slot in the rubber grommet...

  • Page 37: Continuation Of Installation - Remote Control Model

    3.9.6. Continuation of Installation - Remote Control Model 1. Unpack the box containing the Receiver and the Hand Set. 2. Fit four AA (1.5V) batteries into the receiver unit and the PP3 (9V) battery into the transmitter (hand set). 3. Feed the cable from the receiver unit heat shield to the spade terminals on the control valve, keeping the cable clear of the underside of the burner.

  • Page 38: Continuation Of Installation - Optimum Control Model

    3.9.7. Continuation of Installation - Optimum Control Model 1. Find a suitable position for the wall Any plaster/cement used to switch, a maximum of 5 metres of cable secure the wall box must be is supplied. completely cured (dry) before installing the batteries or fixing 2.

  • Page 39: Commissioning

    3.9.8. Commissioning 1. Turn on the gas supply to the fire and purge the gas line. Check all the gas joints for gas soundness. 2. Connect a pressure gauge to the pressure test point on the isolating valve on the appliance. 3.

  • Page 40: Checking For Spillage

    3.9.9. Checking for Spillage Smoke match applied 1. Close all doors and windows. 6 - 12mm inside and 25mm under the canopy. 2. Turn the fire on to its maximum setting and leave it burning for 5 minutes. 3. Test for spillage using a smoke match (in a ‘Blume tube’) at the top of the appliance opening at the centre, with the smoke match being approximately 6 -...

  • Page 41: Servicing Instructions

    4. S ERVICING NSTRUCTIONS 4.1. General Requirements All repairs and servicing must be carried out by a qualified registered gas installer (e.g. member of Gas Safe in GB) in accordance with the current Gas Safety (Installation and Use) Regulations and these instructions. Before any servicing is carried out ensure that the gas and electrical supply (where applicable) have been isolated.

  • Page 42: Replacing Parts

    4.3. Replacing Parts For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will need the model name i.e. model number, the gas type, the type of control and serial number. Only approved parts should be used. Ensure that the gas supply to the appliance has been isolated at the service tap before proceeding.

  • Page 43: Control Valve Replacement

    4.3.3. Control Valve Replacement 1. Disconnect the pilot feed pipe, the main gas feed pipe and the thermocouple connection from the back of the valve. 1. Pull out the HT lead connection from under the electrode and cut the cable tie wrap.

  • Page 44: Installation And Operational Troubleshooting

    4.4. Installation and Operational Troubleshooting The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 45 Remote Control and Optimum Control Models Symptom Cause Remedy Main burner will not Ignition knob incorrectly set Set the ignition knob at the come on when 9 o’clock position. required even though the drive motor is heard to be operating Motor not functioning Flat hand set battery Replace battery (1 X PP3)
  • Page 46 This page is left intentionally blank Page 42...
  • Page 47 This page is left intentionally blank Page 43...
  • Page 48 Burley Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Magiglo is a registered trademark of Burley Appliances Ltd. Burley Appliances Ltd, Lands End Way Oakham, Rutland, LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.magiglo.co.uk...
