EON PLUS 16"
Fuel Effect Options:
Coal Effect
Pebble Effect
Beachcomber Effect
Shoreline Effect
All available on NG & LPG
Control Options:
Upgradeable Manual Control
Remote Control (Response-S)
Optimum Control
Trim Switch Control
Total Control
For use on Natural Gas (G20) at a supply pressure of 20mbar
or Propane (G31) at a supply pressure of 37mbar in GB and IE
(Dependent upon model)
Users,
Installation & Servicing
Instructions
MUST BE LEFT WITH THE USER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EON PLUS 16" and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Magiglo EON PLUS 16"

Summary of Contents for Magiglo EON PLUS 16"

  • Page 1 EON PLUS 16” Fuel Effect Options: Coal Effect Pebble Effect Beachcomber Effect Shoreline Effect All available on NG & LPG Control Options: Upgradeable Manual Control Remote Control (Response-S) Optimum Control Trim Switch Control Total Control For use on Natural Gas (G20) at a supply pressure of 20mbar or Propane (G31) at a supply pressure of 37mbar in GB and IE (Dependent upon model) Users,...
  • Page 2 Any claims under this warranty must be made through the retailer from whom the product was purchased. As the purchaser’s contract of sale is with the retailer, Burley Magiglo are unable to enter into discussions with the purchaser until the retailer has inspected any claim and deemed it to be valid.

  • Page 3: Table Of Contents

    Contents     ......................1 ENERAL NFORMATION     1.1. Important Note About ODS Pilot ................2     ......................3 NSTRUCTIONS     2.1. Lighting Procedure ..................... 3     2.1.1. Opening and Closing the Quartz Fascia .............. 4  ...
  • Page 4     3.9.10. Commissioning ....................40     3.9.11. Checking for Spillage ..................41     3.9.12. Instructing the User .................... 41     ....................43 ERVICING NSTRUCTIONS     4.1. General Requirements ..................... 43     4.2. Servicing Instructions ....................43  ...

  • Page 5: General Information

    Only approved imitation fuel, available from Burley Magiglo., should be used with this appliance. 3. It is recommended that a fire guard complying with BS 8423 be fitted for the protection of young children, the elderly or infirm.

  • Page 6: Important Note About Ods Pilot

    Under no circumstances should it be adjusted or put out of action by the installer or the user. In case the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.

  • Page 7: User Instructions

    2. U NSTRUCTIONS 2.1. Lighting Procedure Your fire will be fitted with one of the five different types of gas control. Identify the control system on your fire as shown and follow the appropriate operating instructions in the appropriate section. Control Valve Operation Control Type...

  • Page 8: Opening And Closing The Quartz Fascia

    2.1.1. Opening and Closing the Quartz Fascia 1. To gain access to the controls pull at the bottom left hand or right hand corner of the glass fascia (see Figure 1). bottom of the fascia will swing out and stay open. The controls should be accessed from under the glass fascia.

  • Page 9: Lighting Procedure (Upgradeable Manual Control)

    2.1.2. Lighting Procedure (Upgradeable Manual control) Whilst pushing the IGNITION KNOB in (see Figure 3), turn it anticlockwise to Ignition knob the pilot flame position as shown in Figure 4. During this process, the spark ignition will have operated and lit the pilot flame.

  • Page 10: Lighting Procedure (Remote Control)

    2.1.3. Lighting Procedure (Remote Control) 1. Press the bottom button on the remote 9. The fire can safely be left in this position handset until clicking is heard on the times, however prevent valve, and the gas rate adjustment knob unauthorised or accidental use (say by is at the off position.

  • Page 11: Lighting Procedure (Optimum Control And Trim Switch Control)

    2.1.4. Lighting Procedure (Optimum Control and Trim Switch Control) 1. Ensure the main burner is off by pressing position turning degrees clockwise. To turn the pilot off, turn the the button on the trim marked IGNITION KNOB fully clockwise. (‘small flame/dot’) until clicking is heard on the valve (see Figure 9/Figure 10).

  • Page 12: Lighting Procedure (Total Control)

    2.1.5. Lighting Procedure (Total Control) 1. Ensure that gas is available at the valve and the ON/OFF switch in the ON position (–). ON/OFF Switch 2. Simultaneously press and hold the Manual (red circle) and (large flame) Knob buttons until a short acoustic signal confirms the start sequence has begun, then release the buttons (see Figure 12).

  • Page 13: Manual Operation (Total Control)

    2.1.6. Manual Operation (Total Control) In emergency the appliance can be operated ON/OFF Switch manually as follows: Manual Turn the Gas Rate Adjusting knob fully Knob clockwise to the OFF position. clicking sound will be audible, but this is perfectly alright. Turn the Manual knob clockwise to Gas Rate MAN position (see Figure 14).

  • Page 14: Battery Replacement (Remote Control & Total Control)

    2.2. Battery Replacement (Remote Control & Total Control) 2.2.1. Handset 1. On the reverse of the handset remove the battery cover by pressing down at the top of the cover and sliding down. Press here and 2. Remove and unclip the old battery and slide down replace with a new PP3 9V battery.

  • Page 15: Battery Replacement (Optimum Control)

    2.3. Battery Replacement (Optimum Control) 1. The battery pack is mounted inside the wall-mounting box behind the wall switch plate. blue blue 2. To change the batteries remove the two brown small screws securing the wall plate brown HIGH using a small screwdriver. LOW/OFF SWITCH SWITCH...

  • Page 16: Fuel Effect Layout

    2.5. Fuel Effect Layout You fire has been supplied with Coal, Pebble, Beachcomber or Shoreline effect fuel bed. Please refer to the relevant section for instructions on how to arrange the imitation fuels. It is recommended that the imitation fuel be left alone once the desired flame pattern has been achieved.

  • Page 17: Coal Effect Layout

    2.5.1. Coal Effect Layout This fire is supplied with different sizes of Rear matrix ceramic coal: Small Square Coals Medium Square Coals Middle Matrix Random Coals Small random coals Matrices Front Fuel Spikes Burner Board Proceed with the coal layout as follows: - 1.
  • Page 18 Random Coals Small Random Coals Figure 24 Figure 25 Page 14...

  • Page 19: Pebble Effect Layout

    2.5.2. Pebble Effect Layout Rear matrix The fire is supplied with ceramic pebble sets as follows:- Large Pebbles (A, B & K) Middle Matrix Medium Pebbles (C & D) Medium Pebbles (F) Front Pebbles (E/J) Front Fuel Spikes Burner Board Matrices NOTE: When placing pebbles on the burner Figure 26...
  • Page 20 Figure 31 Some sooting on the pebbles may be observed. This is perfectly normal. Periodically operating the Fire at various rates will burn this soot away. excessive sooting is observed, this is an indication that the pebbles are laid incorrectly – please refer to instructions. Page 16...

  • Page 21: Beachcomber Effect And Shoreline Effect Layout

    2.5.3. Beachcomber Effect and Shoreline Effect Layout The fire is supplied with ceramic pebble and driftwood set as follows: Pebbles Large Pebbles (A, B & K) Medium Pebbles (C, D & F) 5 Small Pebbles (E/J) Matrices Driftwood Figure 32 NOTE: When placing pebbles and driftwood on the burner tray, ensure that the lettering Rear matrix...
  • Page 22 5. Place the G and E driftwood pieces as shown in Figure 35 then place the C and D pebbles (G driftwood is not marked). 6. Next place the B, J & K driftwood pieces as in Figure 36. 7. Continue laying the pebbles and the driftwood pieces as shown in Figure 37 and Figure 38.

  • Page 23: Home Improvements

    2.6. Home Improvements WARNING: If after installation of this fire any home improvements (e.g. double glazing, secondary double glazing, draught proofing, fitting extractor fans, etc.) are carried out to the property it is essential to carry out a spillage test on the fire to ensure that the flue is still operating satisfactorily.

  • Page 24: Cleaning And Care Instructions

    2.7. Cleaning and Care Instructions CAUTION: Ensure that the appliance is off (including the pilot light) and has completely cooled (off for at least 2 hours) before carrying out any cleaning or maintenance. RCF Advice: This product may use Components (Coals, Pebbles, Driftwood & Ceramic backs) containing Refractory Ceramic Fibres (RCF), which are man-made vitreous silicate fibres.

  • Page 25: Cleaning The Pilot

    2.7.2. Cleaning the Pilot The oxygen depletion sensing pilot fitted to 2. With the aid of a small nozzle attachment your Burley Magiglo fire is a highly reliable on your vacuum cleaner, apply suction at safety device which causes the fire to shut the lint guard on the pilot.

  • Page 26: Painted Metal Surfaces

    Minor surface scuffs may be treated using a water based touch up stain available at Burley Magiglo fire retailers. Extreme care should be taken when handling and installing products containing ceramic interiors, so as not to cause damage.

  • Page 27: Installation Instructions

    3. I NSTALLATION NSTRUCTIONS Before installation, ensure that the local distribution conditions (identification of the type of gas and pressure and the adjustment of the appliance are compatible) 3.1. General Safety Requirements The installation of the fire in GB should follow the recommendations of the following current British Standards: BS 5871: Pt 2 Installation of Inset live fuel effect gas fires.

  • Page 28: Installation Into A 125Mm (5") Class 2 Metal Flue System

    3.2.2. Installation into a 125mm (5”) Class 2 Metal Flue system The Burley Magiglo Eon Plus 16” may be installed into a flue system where the minimum dimension of the flue is 125mm, provided that the following criteria are met: 1.

  • Page 29: Installation Example Using Existing Builder's Opening

    3.2.3. Installation Example using Existing Builder’s Opening 125mm (5”) Flexible Liner Register Plate Fascia Mounting Frame Fireplace Opening Hearth Section through Masonry Chimney Figure 42 3.3. General Dimensions Dimensions 580mm 553mm C (Front) 393mm C (Rear) 308mm 253mm 485mm Table 1 Figure 43- Standard Box Dimensions (refer to Table 1) Page 25...

  • Page 30: Technical Data

    3.4. Technical Data Natural Gas Propane (LPG) Nominal maximum heat input 6.8 kW (gross) 6.8 kW (gross) Setting pressure (Cold) 15.5 mbar ±1.0 mbar 28.5 mbar ±1.0mbar Minimum heat Input 3.5 kW (gross) 3.5 kW (gross) Minimum setting pressure 4.5 mbar ±0.3 mbar 8.0 mbar ±0.5 mbar G20 (Natural Gas) G31 (Propane)

  • Page 31: Appliance Location

    Burley Magiglo would recommend that a hearth or physical barrier be installed with this appliance. However, should you decide not to follow our recommendation and do not fit a hearth or subsequently decide to remove the hearth / physical barrier, then consideration as to the safety of the occupants of the room should be given.

  • Page 32: Raised Fireplace Opening

    3.6.1. Raised Fireplace Opening Raised Fireplace Openings 565mm 430mm 280mm (min) Must project a minimum of 150mm either side of any naked flame or incandescent material Must project a minimum of 300mm in front of any naked flame or incandescent material Minimum 250mm above...

  • Page 33: Physical Barrier

    3.6.2. Physical Barrier Any physical barrier should meet following requirements: All models Must project a minimum of Provide at least the equivalent level of 150mm either side of any naked warning to the approach of an open fire, flame or incandescent material to that of a hearth.
  • Page 34 Figure 53, Figure 54, Figure 55 and Figure 56 show examples of how the requirements for the physical barrier may be met. 50mm Figure 55 – Example of physical barrier Figure 53 – Example of physical barrier (dimensions as stated in Table 3 – Protected Area) (dimensions as stated in Table 3 –...

  • Page 35: Ventilation

    3.7. Ventilation For this model normal adventitious ventilation is usually sufficient to satisfy the ventilation requirements. In GB reference should be made to BS 5871 Part 2, and in IE reference should be made to the current edition of I.S.813 which makes clear the conditions that must be met to demonstrate that sufficient ventilation is available.

  • Page 36: Installation Procedure

    3.9. Installation Procedure Before commencing installation, ensure that the intended installation will comply with details in General Information on Pages 1 and 23. Carefully unpack the contents of the carton and check them against the checklist given on the previous page. Make sure that the fireplace opening is suitable for the installation of the fire and prepare the fireplace to suit the dimensional requirements given in section 3.6 (i.e.

  • Page 37: Preparing The Fireplace Opening (All Models)

    3.9.2. Preparing the Fireplace Opening (all models) Prepare fireplace opening accordance with Section 3.2 and 3.6 ensuring that the surface around the opening is flat and level in all directions. Mark out, drill, plug and fit the four cable guide brackets onto the rear wall of the fireplace opening as shown in Centre Line...

  • Page 38: Installing The Firebox (All Models)

    3.9.3. Installing the Firebox (all models) With the firebox placed close to the fireplace opening feed the two cables through the matching eye screws (left cable through left hand set eyelets and the same for right hand cable) and then back into the holes at the bottom rear of cable the firebox (see Figure 60).

  • Page 39: Connecting The Gas Supply

    3.9.4. Connecting the Gas Supply The gas supply to the fire must be carried out using rigid or semi-rigid metal tubing. A service cock must be incorporated near the appliance to facilitate isolation of the fire during servicing. An isolating valve (with a pressure test point) has been supplied with this fire. Carry out the procedure below to prepare the gas supply to the isolating valve supplied: Cut a cross-slot in the rubber grommet...

  • Page 40: Installation Of Quartz Fascia Pack (Eon Plus)

    3.9.5. Installation of Quartz Fascia Pack (Eon Plus) 1. Unpack the contents of the Fascia Pack. Securing 2. Remove the fascia retaining bracket by Screw removing the fixing screw (see Figure Retaining Bracket 63). 3. Separate the fascia from the mounting frame by opening and sliding it off its hinges as shown in Figure 64.

  • Page 41: Continuation Of Installation - Remote Control Model

    fascia mounting frame must be flat and level in all directions when fitted. Failure to ensure this will result in Gas Spring poorly fitting fascia (door). Suitable material may be used behind the frame fixing points to level it. Wing Nut Figure 66 3.9.6.

  • Page 42: Continuation Of Installation - Optimum Control Model

    3.9.7. Continuation of Installation - Optimum Control Model 1. Find a suitable position for the wall Any plaster/cement used to switch, a maximum of 5 metres of cable secure the wall box must be is supplied. completely cured (dry) before installing the batteries or fixing 2.

  • Page 43: Continuation Of Installation - Trim Switch Control Model

    3.9.8. Continuation of Installation - Trim Switch Control Model 1. Unpack the battery pack and connect to the battery connection on the cable. 2. Fit the connectors on the cable to the drive motor ensuring correct polarity. The cable connectors must be matched to the appropriately sized spade connector.

  • Page 44: Commissioning

    3.9.10. Commissioning 1. Turn on the gas supply to the fire and purge the gas line. Check all the gas joints for gas soundness. 2. Remove the pressure test point screw located as shown in Section 3.5 - Pressure Test Point Locations and connect a pressure gauge.

  • Page 45: Checking For Spillage

    3.9.11. Checking for Spillage The imitation fuels must be laid accordance with instructions prior commencing the spillage test. 1. Close all doors and windows. 2. Turn the fire on to its full rate and leave it burning for 5 minutes. 3.
  • Page 46 This page is left intentionally blank Page 42...

  • Page 47: Ervicing Nstructions

    Under no circumstances should the pilot assembly be adjusted or put out of action by the installer. In case the pilot needs replacing, only the approved part (available from your supplier or Burley Magiglo.) should be fitted. Note: if any part of the pilot assembly becomes faulty the complete assembly will need replacing.

  • Page 48: Replacing Parts

    4.3. Replacing Parts For any spare parts that are required, please contact either your supplier or the manufacturer directly. You will either need the serial number or: a) model name; b) the gas type; c) the imitation fuel type; d) the type of control. Only approved parts should be used.

  • Page 49: Motor Replacement (Remote/Optimum/Trim Switch Control Models)

    4.3.4. Motor Replacement (Remote/Optimum/Trim Switch Control Models) The gas rate adjusting motor is replaceable in situ. 1. Remove the batteries from the receiver unit to prevent the risk of short circuit. 2. Remove the two motor connection tags from the valve. Valve Cover 3.

  • Page 50: Replacing Mertik Gv60 Valve (Total Control Model)

    4.3.5. Replacing Mertik GV60 Valve (Total Control Model) Referring to Figure 76:- Remove al the gas connections on the valve including the pilot feed pipe. Valve Remove the thermocouple connection securing from the interrupter block at the rear of Screw the valve.

  • Page 51: Replacing The Ceramic Back And Sides

    4.3.8. Replacing the Ceramic Back and Sides The ceramic back and sides are replaceable in situ. 1. Isolate and disconnect the gas supply from the burner tray. 2. Remove the burner tray fixing screws and withdraw the burner from the firebox.

  • Page 52: Installation And Operational Troubleshooting

    4.4. Installation and Operational Troubleshooting The table below is intended for problems related to the fire and its gas controls. It is a guide only and does not take into account every eventuality. Servicing must be carried out in accordance with the current Gas Safety (Installation and Use) Regulations, by a competent person.
  • Page 53 Remote Control, Trim Switch and Optimum Control & Total Control Models Symptom Cause Remedy Main burner will not Ignition knob incorrectly set Set the ignition knob at the come on when 9 o’clock position. required even though the drive motor is heard to be operating Motor not functioning Flat hand set battery...
  • Page 54 This page is intentionally left blank Page 50...
  • Page 55 This page is intentionally left blank Page 51...
  • Page 56 Burley Magiglo fires are protected by UK patents 2193802, 2240620 and 2256920 Other Patents Pending Magiglo is a registered trademark of Burley Appliances Ltd Burley Appliances Ltd, Lands End Way Oakham, Rutland, LE15 6RB Tel: 01572 725570 Fax: 01572 724390 www.magiglo.co.uk...
